Product Overview
The Schneider TSXPCX3030 is a high-performance USB programming cable designed to provide a reliable connection between a PC and Schneider Electric programmable logic controllers (PLCs), including the Modicon TSX Micro and Premium series. This versatile cable allows engineers and maintenance personnel to perform diagnostics, programming, firmware updates, and system configuration without the need for legacy serial ports.
Built with robust industrial-grade materials, the TSXPCX3030 enables seamless and fast communication through the USB 2.0 interface, and it emulates a COM port on the host computer for compatibility with legacy programming software. The cable includes an embedded converter that handles USB-to-RS485/RS232 signal conversion automatically, supporting data transmission at high speeds with strong interference immunity.
Key Features
-
Direct USB-to-PLC communication without external power supply
-
USB 2.0 compatible, plug-and-play operation
-
Built-in signal conversion from USB to RS485/RS232
-
LED indicators for communication and power status
-
Compatible with Schneider TSX Micro and Premium series
-
COM port emulation for software compatibility
-
Suitable for industrial environments with durable shielding
Technical Specifications
| Parameter | Specification |
|---|---|
| Interface Type | USB 2.0 (Type A) to RS485/RS232 |
| Supported PLC Models | Schneider TSX Micro, TSX Premium series |
| Emulated COM Ports | COM1–COM256 (assignable by user/system) |
| Cable Length | 3 meters (approx. 9.8 feet) |
| Data Transmission Rate | Up to 115.2 kbps |
| Power Supply | Powered directly through USB port |
| Status Indicators | TX, RX LEDs |
| Driver Support | Windows XP/7/8/10/11 (32-bit and 64-bit) |
| Operating Temperature | 0°C to +50°C (32°F to 122°F) |
| Storage Temperature | -20°C to +70°C (-4°F to 158°F) |
| Humidity Tolerance | 10% to 90% RH, non-condensing |
| Dimensions | Length:2.5m |
| Weight | 0.3 kg |
Product Advantages
-
Universal Compatibility: Designed to work with Schneider’s most popular PLC series, ensuring wide application flexibility.
-
No External Power Required: Operates entirely off USB power, eliminating the need for extra adapters or power sources.
-
Ease of Use: Plug-and-play setup with automatic COM port assignment makes it ideal for both field engineers and integrators.
-
Software Integration: Compatible with Schneider Unity Pro, PL7, and Concept software via virtual COM port.
-
Industrial Grade Durability: Reinforced shielding and robust connectors ensure reliable performance in demanding environments.
-
Portability: Lightweight and compact, ideal for field servicing and onsite diagnostics.
-
High-speed Communication: Supports rapid data transfer, minimizing programming and debugging time.
-
Clear Diagnostics: Built-in LED indicators provide real-time communication and status feedback.
Industry Applications
-
Industrial automation and PLC programming
-
Process control systems in manufacturing
-
Water and wastewater management systems
-
Power generation and energy monitoring
-
Building automation systems
-
OEM machine integration and diagnostics
-
Maintenance and troubleshooting operations
Frequently Asked Questions (FAQ)
-
Q: Is the TSXPCX3030 compatible with Windows 11?
A: Yes, it supports Windows XP through Windows 11, including both 32-bit and 64-bit editions. -
Q: Which PLC models are supported?
A: It supports Schneider TSX Micro and TSX Premium series PLCs. -
Q: Do I need to install a driver?
A: Yes, a USB driver must be installed. It is typically included with Schneider’s programming software or downloadable from their official site. -
Q: Does the cable support Unity Pro software?
A: Yes, it supports Unity Pro, PL7, and Concept by emulating a virtual COM port. -
Q: Can I use this cable on a Mac?
A: The TSXPCX3030 is officially supported on Windows OS. Mac usage may require a Windows virtual machine. -
Q: What is the maximum length of the cable?
A: The cable is 3 meters long (approximately 9.8 feet), suitable for most programming scenarios. -
Q: Are there LED indicators on the cable?
A: Yes, there are LEDs for transmit (TX) and receive (RX) data status. -
Q: Can this cable be used for firmware updates?
A: Yes, it supports full communication with the PLC for firmware upgrades. -
Q: What happens if the COM port conflicts with existing ports?
A: The port number can be manually reassigned via Device Manager in Windows. -
Q: Is it safe to use this cable in high EMI environments?
A: Yes, it features industrial-grade shielding for EMI resistance.
Related or Compatible Models (Same Series or Functionality)
| Model | Description |
|---|---|
| TSXPCX1031 | USB to RS232/RS485 converter for Modicon TSX series |
| TSXCUSB485 | USB to RS485 converter cable for Modicon PLCs |
| TSXPCX3030-R | Ruggedized version of TSXPCX3030 for harsh environments |
| TSXPCX1010 | RS232 serial interface cable for TSX series |
| TSXCUSB232 | USB to serial RS232 converter for Modicon TSX and others |
| TCSMCNAM3M002P | Modbus RS485 communication cable with integrated interface |
