Product Introduction
The GE IC697CPU732 Central Processor Unit (CPU) is a high-performance processing module designed for the GE Series 90-70 PLC family. Engineered for precision control and reliable operation, it serves as the core of large-scale automation systems that demand consistent logic execution, data handling, and communication capability.
Operating at 12 MHz, the IC697CPU732 provides stable real-time control performance and supports both discrete and analog I/O operations. With expandable I/O capability, floating-point computation, and fixed 32K bytes of memory, this module ensures dependable control and excellent scalability. Its robust design and broad compatibility make it a key component in industries such as manufacturing, utilities, process automation, and energy systems.
Technical Specifications
| Parameter | Description |
|---|---|
| Model | GE IC697CPU732 |
| Type | Central Processor Unit |
| Series | GE Fanuc Series 90-70 |
| Processor Speed | 12 MHz |
| CPU Type | Floating-point CPU |
| User Memory | 32 KB fixed memory |
| I/O Capacity | 2K discrete I/O points (expandable) |
| Instruction Set | Boolean logic, timers, counters, arithmetic, data handling |
| Communication Ports | 1 × RS-232/RS-485 serial port |
| Scan Rate | Approx. 1 ms per 1K of ladder logic |
| Power Requirements | +5V DC, 1.1 A typical |
| Program Storage | Battery-backed RAM and Flash |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Vibration Resistance | 2 g, 57–150 Hz |
| Shock Resistance | 15 g, 11 ms duration |
| Mounting Type | Single-slot rack mount |
| Supported Software | Logicmaster 90-70 |
| Dimensions | 180 x 50 x 105 mm |
| Weight | 1.33 kg |
Applications
The IC697CPU732 is widely implemented in industrial environments requiring dependable control and data accuracy. Its versatility makes it suitable for a variety of automation and process control systems, including:
-
Process Industries: Chemical, petrochemical, and water treatment plants where reliability and continuous operation are vital.
-
Manufacturing Automation: Machine control, assembly lines, and packaging systems.
-
Power Generation: Supervisory control in turbines, substations, and energy management systems.
-
Material Handling: Conveyor systems, automated cranes, and robotics.
-
Building and Infrastructure Control: HVAC, lighting, and utility monitoring.
-
SCADA and Distributed Control Systems: Integration with remote I/O and field devices.
Product Advantages
The GE IC697CPU732 delivers multiple advantages that enhance automation performance and system reliability:
-
Stable High-Speed Operation – With a 12 MHz processor, it ensures deterministic control and fast logic execution.
-
Floating-Point Support – Provides precise computation for analog and mathematical applications.
-
Expandable I/O Architecture – Enables system scalability with additional I/O modules and communication interfaces.
-
Reliable Data Retention – Equipped with battery-backed memory to protect data during power loss.
-
Comprehensive Diagnostics – Integrated LED indicators and self-diagnostic features for system monitoring.
-
Flexible Communication – Supports standard serial interfaces for HMI and device networking.
-
Rugged Industrial Design – Built to operate reliably in environments with vibration, temperature fluctuation, and electrical noise.
-
Seamless Compatibility – Fully compatible with the GE Fanuc Series 90-70 ecosystem, ensuring easy expansion and migration.
FAQ
-
What programming tools can be used with the IC697CPU732?
The IC697CPU732 is compatible with Logicmaster 90-70 programming software, which supports configuration, ladder logic development, and real-time diagnostics. -
Does this CPU support floating-point operations?
Yes, it includes floating-point arithmetic support, allowing for high-precision control and mathematical calculations. -
Can the I/O capacity be expanded beyond 2K discrete points?
Yes, it supports I/O expansion through additional Series 90-70 I/O modules and distributed control systems such as IC660. -
What communication features are available?
The CPU provides one serial port (RS-232/RS-485) for device, HMI, or peer-to-peer communication. -
How does the module handle memory backup?
It uses battery-backed RAM, ensuring that user programs and critical data are preserved during power outages. -
What is the typical logic execution speed?
The CPU can process logic at approximately 1 millisecond per 1K of instructions, offering fast and deterministic performance. -
Is the IC697CPU732 backward compatible with older modules?
Yes, it is fully backward compatible with other Series 90-70 modules and I/O configurations. -
How can system faults be diagnosed?
Diagnostic LEDs and internal fault registers allow operators to identify, isolate, and correct system faults quickly. -
Can the IC697CPU732 operate in redundant control systems?
It can be integrated into redundant configurations when paired with compatible redundancy modules for high availability. -
What are the main control functions supported by this CPU?
It supports Boolean logic, arithmetic, timers, counters, PID control, and data handling, making it versatile for various automation applications.
