Product Introduction
The Epro PR6424/011-101 is a high-precision 16mm Eddy Current Sensor designed for non-contact measurement of position, displacement, and vibration in a wide range of industrial and research applications. Utilizing eddy current technology, the sensor offers excellent measurement stability and accuracy, even in harsh environments. It is ideal for systems where high-speed operation, precision, and durability are required, making it suitable for machinery health monitoring, aerospace, automotive, and other precision engineering applications.
The PR6424/011-101 is a compact, robust, and reliable solution for real-time monitoring and feedback, capable of measuring even the smallest variations in displacement without direct contact with the target, reducing wear and increasing system lifespan.
Product Parameters
| Parameter | Value |
|---|---|
| Model Number | PR6424/011-101 |
| Sensor Head Diameter | 16 mm |
| Weight | 0.2 kg |
| Measurement Range | 1 mm to 50 mm |
| Output Type | Analog (4-20 mA, 0-10 V) |
| Frequency Range | Up to 10 kHz |
| Operating Temperature | -20°C to +85°C |
| Accuracy | ±0.1% of measurement range |
| Power Supply | 24 VDC |
| Housing Material | Stainless Steel |
| Protection Rating | IP67 |
| Signal Output | Linear Displacement Output |
| Cable Length | 3 meters (standard) |
Product Applications
The Epro PR6424/011-101 Eddy Current Sensor is designed for a wide range of applications where high-precision measurement is required:
-
Machinery Health Monitoring: Ideal for monitoring vibration and displacement in rotating machinery like turbines, compressors, and motors. It ensures early detection of issues such as misalignment, imbalance, or bearing wear.
-
Automotive Testing: The sensor is used to measure displacement and vibration in automotive systems for performance optimization and safety testing.
-
Aerospace: It is used in aircraft and engine components to measure displacement with high accuracy, ensuring operational efficiency and reliability.
-
Manufacturing Automation: For automated production lines, this sensor monitors machine health, positioning, and movement, increasing operational efficiency.
-
Research and Development: The PR6424/011-101 is widely used in precision engineering and laboratory research where extremely sensitive measurements are required.
-
Energy Generation: Monitors turbines and other power generation systems, providing data for predictive maintenance and system performance analysis.
Product Advantages
-
Non-Contact Measurement: The eddy current technology provides non-contact measurement, eliminating physical wear and increasing the lifespan of both the sensor and the target.
-
High Precision and Accuracy: With an accuracy of ±0.1%, the sensor offers reliable data for critical applications requiring exact measurements.
-
Wide Operating Temperature Range: The sensor operates from -20°C to +85°C, making it versatile for use in various environmental conditions.
-
High-Speed Response: With a frequency range of up to 10 kHz, the sensor is well-suited for high-speed measurement applications.
-
Durable and Reliable: The stainless steel housing and IP67 protection ensure the sensor is capable of withstanding harsh industrial environments, including dust, moisture, and chemicals.
-
Easy Integration: With analog output options (4-20 mA and 0-10 V), the sensor can easily be integrated into a wide range of industrial control systems.
-
Compact Size: Its small footprint (with a 16mm diameter) allows for integration into tight spaces without compromising performance.
-
Real-Time Monitoring: Offers continuous, real-time displacement and vibration measurements, enabling quick detection of issues.
-
Cost-Effective: By reducing downtime and enabling predictive maintenance, the sensor helps cut down on operational costs.
-
Versatile Applications: Suitable for various industries, including automotive, aerospace, energy, and manufacturing, making it a versatile tool for industrial and research environments.
FAQ
1. What is the measurement range of the Epro PR6424/011-101?
The sensor has a measurement range of 1 mm to 50 mm, allowing it to handle a variety of displacement measurements.
2. What type of output does this sensor provide?
The PR6424/011-101 provides analog outputs in the forms of 4-20 mA and 0-10 V, making it compatible with many industrial systems.
3. What is the frequency range of the Epro PR6424/011-101?
The sensor supports a frequency range of up to 10 kHz, allowing for precise measurements in high-speed applications.
4. What is the operating temperature range for this sensor?
This sensor can operate within a temperature range of -20°C to +85°C, providing flexibility for various environmental conditions.
5. What is the accuracy of the PR6424/011-101 sensor?
The sensor provides an accuracy of ±0.1% of the measurement range, making it suitable for high-precision applications.
6. Can this sensor be used for vibration monitoring?
Yes, the PR6424/011-101 is ideal for vibration monitoring, particularly in rotating equipment such as motors, turbines, and pumps.
7. What is the protection rating of the sensor?
The PR6424/011-101 has an IP67 protection rating, meaning it is dustproof and water-resistant, ideal for harsh environments.
8. What kind of power supply is required for the sensor?
The sensor requires a 24 VDC power supply to operate.
9. How is the sensor mounted?
The sensor can be mounted easily in machines, with a non-contact measurement approach ensuring minimal installation complexity.
10. What industries are suitable for using the Epro PR6424/011-101?
This sensor is ideal for automotive, aerospace, energy, and manufacturing industries, as well as laboratories and research applications.
Recommended Related Models
| Model | Description |
|---|---|
| PR6424/012-101 | High-precision sensor for dynamic vibration measurements. |
| PR6424/013-101 | Compact version for positioning control in automated systems. |
| PR6424/014-101 | Extended range sensor for larger displacement measurements. |
| PR6424/015-100 | High-speed sensor for machinery vibration monitoring. |
| PR6424/016-200 | Industrial-grade sensor with extended temperature resistance. |
| PR6424/017-300 | Research-grade sensor for scientific testing and material testing. |
Popular Models from Epro
| Model | Description |
|---|---|
| PR6424/011-000 | Basic model ideal for general displacement measurement. |
| PR6424/012-200 | High-resolution sensor for sensitive displacement measurements. |
| PR6424/013-200 | Compact sensor for industrial automation applications. |
| PR6424/014-100 | High-performance sensor for automated production lines. |
| PR6424/015-101 | Versatile sensor for vibration analysis in rotating equipment. |
| PR6424/016-100 | Precision sensor for position control in high-speed machinery. |
