Product Introduction
The Allen Bradley 1756-IC16 ControlLogix Digital Input Module is a 16-point DC input module designed for high-voltage DC applications within ControlLogix automation systems. Supporting a 30–60 VDC input range, it provides reliable monitoring of field devices such as sensors, switches, and discrete inputs.
The module includes a communication status and module health display, allowing operators to quickly verify connectivity and module condition. Its chassis-mounted design ensures secure installation and integration into ControlLogix systems.
Product Specifications
| Parameter | Specification |
|---|---|
| Product Type | Digital DC Input Module |
| Manufacturer | Allen Bradley |
| Series | ControlLogix |
| Model / Part Number | 1756-IC16 |
| Number of Input Points | 16 |
| Input Voltage | 30–60 VDC |
| Status Indicators | Input status, communication status, module health display |
| Mounting Type | Chassis mount |
| Control Platform | ControlLogix backplane |
| Industrial Application Level | High-voltage DC input monitoring |
| Dimensions | 145.2 × 34.6 × 139.6 mm |
| Weight | 0.118 kg |
Applications
• High-Voltage DC Signal Acquisition
Monitors sensors and devices operating on 30–60 VDC for process control and automation.
• Machine-Level Monitoring
Provides real-time input status for operational verification and control.
• Process Automation Systems
Captures discrete signals to ensure reliable automation in high-voltage DC environments.
• Diagnostics and Status Monitoring
The built-in status and health indicators allow operators to quickly detect faults or communication issues.
• Distributed I/O Architectures
Integrates with other ControlLogix modules for scalable digital input networks.
• Industrial Automation Integration
Supports applications requiring high-voltage DC monitoring with robust system feedback.
Advantages
• High-Voltage DC Compatibility
Designed for input ranges of 30–60 VDC, suitable for a wide range of industrial devices.
• Module Health and Status Indicators
Built-in displays enable easy monitoring of module and communication status.
• Compact Design
16 digital input points in a chassis-mounted module save cabinet space.
• Seamless ControlLogix Integration
Directly mounts in the ControlLogix chassis and communicates via the backplane.
• Reliable Industrial Operation
Supports continuous monitoring in standard industrial environments.
• Efficient System Monitoring
Provides accurate input acquisition for diagnostics, alarms, and control applications.
