Product Introduction
The ABB TK801V003 3BSC950089R1 is a sophisticated industrial operator panel designed to meet the demanding visualization and control needs in process automation environments. Belonging to the renowned ABB Symphony Plus family, this model delivers dependable performance and user-friendly functionality, bridging the gap between process systems and human operators. With its robust construction, advanced display capabilities, and high adaptability, the TK801V003 has become an essential part of modern distributed control systems (DCS), especially in applications that prioritize both reliability and precision.
Technical Specifications
| Item | Specification |
|---|---|
| Model | TK801V003 |
| Part Number | 3BSC950089R1 |
| Display Type | TFT LCD |
| Display Size | 10.4 inches |
| Interface | Touchscreen |
| Cable length | 0.3m |
| Weight | 0.155kg |
| Supply Voltage | 24 V DC |
| Operating Temperature | 0°C ~ +50°C |
| Storage Temperature | -20°C ~ +70°C |
| Protection Class | Front IP65 (dust and water splash resistant) |
| Communication Ports | Ethernet, RS-232, USB |
| Mounting Method | Panel mounting |
| Certifications | CE, RoHS |
Product Applications
The ABB TK801V003 operator panel is widely applied in industries requiring reliable visualization and control, such as:
-
Power generation (thermal, hydro, renewable energy plants)
-
Oil and gas (refining, transportation, offshore platforms)
-
Chemical and petrochemical plants
-
Water and wastewater treatment facilities
-
Pulp and paper manufacturing
-
Pharmaceutical production lines
Its compatibility with ABB Symphony Plus and other ABB automation systems ensures seamless integration in existing and new projects alike.
Product Advantages
-
Robust Design: Engineered to endure harsh industrial environments with high vibration and temperature variations.
-
User-Friendly Interface: Large, clear touchscreen simplifies process monitoring and operation.
-
Flexible Connectivity: Multiple communication ports facilitate integration with various controllers and networks.
-
Space-Saving Build: Compact panel mounting helps save valuable cabinet space.
-
High Reliability: Proven ABB quality reduces risk of downtime and maintenance cost.
-
Long Service Life: Designed for continuous 24/7 operation over many years.
Frequently Asked Questions (FAQ)
Q1: What is the main function of the TK801V003?
A1: It serves as a human-machine interface (HMI), allowing operators to monitor, control, and interact with automated systems in real-time.
Q2: Can this panel be used outdoors?
A2: While the front panel is IP65 rated, it is recommended for indoor industrial environments or protected enclosures.
Q3: Is it compatible with non-ABB PLCs?
A3: Primarily optimized for ABB systems, but can communicate with other controllers via standard protocols like Modbus.
Q4: What is the recommended power supply?
A4: A stable 24 V DC power supply is required for optimal performance.
Q5: How is it typically mounted?
A5: The TK801V003 is designed for secure panel mounting.
Q6: Does it support remote access?
A6: Remote access depends on system configuration; it can be enabled through networking and secure gateways.
Q7: How often does it require maintenance?
A7: Minimal maintenance; regular inspection of connections and cleaning the touchscreen is usually sufficient.
Q8: Can firmware updates be performed on-site?
A8: Yes, updates can be done through USB or network upload depending on configuration.
Q9: What type of screen technology does it use?
A9: It uses a TFT LCD touchscreen for clear visualization.
Q10: Where can spare parts be sourced?
A10: Directly from ABB service centers or authorized distributors worldwide.
Recommended Models from the Same Series / Related Models
-
ABB TK801V002
-
ABB TK802V001
-
ABB TK803V002
-
ABB TK804V001
-
ABB TP830
-
ABB TP857
These models offer various screen sizes, resolutions, and functionalities tailored for different industrial needs.
Popular ABB Models (Same Brand) with Key Specifications
| Model | Part Number | Display Size | Dimensions (mm) | Weight | Voltage |
|---|---|---|---|---|---|
| TP830 | 3BSE042245R1 | 10.4″ | 310 x 245 x 70 | 2.9 kg | 24 V DC |
| TP857 | 3BSE066490R1 | 15″ | 385 x 305 x 80 | 4.5 kg | 24 V DC |
| TK802V001 | 3BSC950089R2 | 12.1″ | 320 x 250 x 70 | 3.1 kg | 24 V DC |
| TK803V002 | 3BSC950090R2 | 15″ | 390 x 310 x 80 | 4.4 kg | 24 V DC |
| CP651 | 3BSE003832R1 | Controller | 190 x 150 x 55 | 1.8 kg | 24 V DC |
| CI854AK01 | 3BSE030220R2 | Communication | 120 x 70 x 35 | 0.4 kg | 24 V DC |
| PM866AK02 | 3BSE050198R1 | CPU | 160 x 140 x 40 | 0.8 kg | 24 V DC |
| CI862 | 3BSE092690R1 | Communication | 130 x 80 x 35 | 0.5 kg | 24 V DC |
