Yokogawa YCB141-M020 製品紹介
The Yokogawa YCB141-M020 is a high-precision signal conditioner designed for industrial automation and process control applications. It provides reliable signal conversion, isolation, and amplification, ensuring accurate data transmission in harsh environments. This product is part / Yokogawa’s extensive lineup / signal conditioning solutions, known for their durability and performance.
Product Parameters
| Parameter | Specification |
|---|---|
| モデル | YCB141-M020 |
| Input Signal | 4-20 mA, DC |
| Output Signal | 4-20 mA, DC |
| Isolation | Input/Output/Power: 3-way isolation |
| Accuracy | ±0.1% / span |
| Power Supply | 24 VDC (±10%) |
| Operating Temperature | -20°C to +60°C |
| Cable length | 20 m |
| 重量 | 2 kg |
| Mounting | DIN rail mountable |
| Certifications | CE, UL, IEC 61010 |
Product Applications
The YCB141-M020 is widely used in industries requiring precise signal conditioning and isolation, including:
-
Oil & Gas: For monitoring and controlling pipeline pressures and flow rates.
-
Chemical Processing: Ensures accurate signal transmission in corrosive environments.
-
Power Generation: Used in turbine control and grid monitoring systems.
-
Water Treatment: Facilitates reliable signal conversion for pH and flow sensors.
-
Manufacturing: Integrates into PLC and DCS systems for automation control.
Product Advantages
-
High Accuracy: ±0.1% accuracy ensures reliable data transmission.
-
Robust Isolation: 3-way isolation protects against ground loops and noise interference.
-
Compact Design: DIN rail mounting saves space in control panels.
-
Wide Temperature Range: Operates reliably in extreme temperatures (-20°C to +60°C).
-
Certified Safety: Complies with CE, UL, and IEC 61010 standards for industrial use.
-
Easy Integration: Compatible with most PLCs and DCS systems.
よくある質問 (FAQ)
-
What is the input signal range / the YCB141-M020?
-
The input signal range is 4-20 mA DC.
-
-
Does this model support reverse polarity protection?
-
Yes, it includes reverse polarity protection for the power supply.
-
-
What is the isolation voltage between input and output?
-
The isolation voltage is 1500 VAC.
-
-
Can the YCB141-M020 be used in hazardous areas?
-
No, this model is not certified for hazardous areas.
-
-
What is the typical response time / the device?
-
The response time is less than 500 ms.
-
-
Is calibration required after installation?
-
Factory calibration is sufficient for most applications, but field calibration is possible if needed.
-
-
What is the maximum load resistance for the output?
-
The maximum load resistance is 550 Ω.
-
-
Does the device require external cooling?
-
No, it operates within its temperature range without additional cooling.
-
-
Can multiple 台s be mounted side by side?
-
Yes, the compact design allows for high-density mounting.
-
-
What is the warranty period for this product?
-
Yokogawa /fers a standard 1-year warranty.
-
Recommended Related モデルs
| Series/Related モデルs | 説明 |
|---|---|
| YCB141-M010 | 1-channel signal conditioner, 0-10V input |
| YCB141-M030 | 3-way isolator with HART communication |
| YCB142-M020 | Dual-channel version / YCB141-M020 |
| YCB145-M020 | High-temperature variant (-40°C to +70°C) |
| YCB146-M020 | Explosion-pro/ model for hazardous areas |
| YCB148-M020 | Advanced diagnostics and self-testing |
Popular Yokogawa モデルs in the Same ブランド
| モデル | 説明 |
|---|---|
| YTA510 | Temperature transmitter with HART protocol |
| EJX110A | Differential pressure transmitter |
| DPharp EJA110E | High-performance pressure transmitter |
| UTAdvanced | Ultrasonic flow meter |
| AQ6370 | Optical spectrum analyzer |
| WT3000E | Precision power analyzer |
