The Yokogawa F9340GN Gasket is a high-performance sealing component made from fluorinated rubber (FKM), designed specifically for capsule assemblies in industrial instrumentation and process control systems. Fluorinated rubber provides exceptional chemical resistance, thermal stability, and mechanical durability, making it ideal for harsh industrial environments.
This gasket is engineered for precision sealing in pressure transmitters, flow meters, control valves, and analytical instruments. The F9340GN ensures leak-pro/ performance under high-pressure, high-temperature, and chemically aggressive conditions. Its robust construction and dimensional stability allow for reliable, long-term operation, reducing maintenance requirements and ensuring accurate measurements in critical industrial applications.
Technical Specifications
| Parameter | Specification |
|---|---|
| モデル | F9340GN |
| Material | Fluorinated Rubber (FKM) |
| Hardness | 75 ± 5 Shore A |
| Temperature Range | -20 °C to 200 °C |
| Chemical Resistance | Resistant to acids, bases, oils, hydrocarbons, and most solvents |
| Pressure Rating | Up to 25 MPa |
| Outer Diameter | 38 mm |
| Inner Diameter | 28 mm |
| Thickness | 2.5 mm |
| 配送 重量 | 3 kg |
| Application | Capsule assemblies in industrial instruments |
| Compliance | RoHS, CE |
Applications
The F9340GN Gasket is suitable for a wide range / industrial applications, particularly in capsule assemblies, including:
-
Pressure transmitters in chemical, oil, gas, and petrochemical plants
-
Flow meters requiring high-reliability, leak-pro/ sealing
-
Control valve assemblies in high-pressure or high-temperature environments
-
Analytical instruments exposed to aggressive chemicals
-
Industrial processes requiring high-performance sealing
-
Capsule assemblies in instrumentation requiring both chemical and thermal stability
The gasket provides excellent sealing under static and dynamic conditions, ensuring stable performance and reducing the risk / leakage or process disruption.
Advantages
The F9340GN /fers several operational benefits:
-
High Chemical Resistance: Resistant to acids, bases, oils, hydrocarbons, and most solvents.
-
Wide Temperature Range: Operates reliably from -20 °C to 200 °C.
-
High Pressure Capability: Maintains sealing up to 25 MPa.
-
Dimensional Stability: Fluorinated rubber ensures consistent compression and sealing.
-
Durable Material: FKM construction provides long-lasting mechanical and thermal integrity.
-
Easy Installation: Precisely machined to fit capsule assemblies without additional tools.
-
Reliable Long-Term Performance: Reduces maintenance needs and risk / leakage.
-
Versatile Applications: Suitable for static and dynamic sealing in capsule assemblies.
-
Regulatory Compliance: Meets RoHS and CE standards.
-
Enhanced Safety: Fluorinated rubber maintains integrity in harsh chemical environments, reducing operational risk.
FAQ
-
What material is the F9340GN Gasket made from?
It is made from fluorinated rubber (FKM), providing chemical and thermal resistance. -
What is the operating temperature range?
The gasket operates from -20 °C to 200 °C. -
What is the maximum pressure it can withstand?
It is rated for pressures up to 25 MPa. -
Is the gasket resistant to aggressive chemicals?
Yes, it resists acids, bases, oils, hydrocarbons, and most solvents. -
What are the dimensional specifications / the gasket?
Outer diameter: 38 mm, inner diameter: 28 mm, thickness: 2.5 mm. -
Which applications is this gasket suitable for?
Capsule assemblies, pressure transmitters, flow meters, control valves, and analytical instruments. -
Can it be used in static and dynamic sealing applications?
Yes, the F9340GN performs reliably in both static and dynamic applications. -
How durable is it under repeated pressure or temperature cycles?
The FKM material maintains dimensional stability and sealing performance under repeated cycles. -
Does it meet industrial compliance standards?
Yes, it meets RoHS and CE requirements. -
Why is fluorinated rubber preferred for this gasket?
Fluorinated rubber provides superior chemical resistance, thermal stability, and mechanical durability in harsh industrial environments.
Related モデルs (Same Series or Compatible)
| モデル | 説明 |
|---|---|
| F9340GE | PTFE gasket for capsule assemblies |
| F9340GF | Degreased PTFE gasket |
| F9340GH | High-temperature gasket |
| F9340GJ | Chemical-resistant gasket |
| F9340GK | Flow meter capsule gasket |
| F9340GL | Pressure transmitter capsule gasket |
Popular モデルs (Same ブランド)
| モデル | 説明 |
|---|---|
| F9300 Series | O-Rings for industrial instrumentation |
| F9310 Series | Capsule assembly sealing components |
| F9320 Series | High-performance gaskets for chemical applications |
| F9330 Series | Pressure transmitter gaskets |
| F9340 Series | Flow meter and control valve gaskets |
| F9350 Series | High-temperature gaskets |
