Product Overview
The Yokogawa CP471-00 Processor Module is a key component in the CENTUM VP R6.05 or later series / integrated production control systems. Designed to be mounted on CENTUM field control 台s such as the AFV30, AFV40, A2FV50, and A2FV70, the CP471-00 enables robust, efficient, and high-performance field control operations. It is capable / dual-redundant operation to ensure system reliability and uninterrupted processing in critical applications.
Technical Specifications
| Item | Specification |
|---|---|
| モデル | CP471-00 |
| Function | Processor Module for CENTUM Field Control ユニットs |
| Applicable Systems | AFV30, AFV40, A2FV50, A2FV70 |
| OS Compatibility | CENTUM VP R6.05 or later |
| Configuration サポート | サポートs dual-redundant operation |
| Replaceable モデルs | Replaces CP461 (with restrictions and service engineer only) |
| Dimensions (W x H x D) | 199.5 x 149 x 32.8 mm |
| 重量 | Approx. 0.7 kg (700 g) |
| Installation Compatibility | EC401 ESB Bus Coupler Module (Style S3 or later) |
| Explosion Protection Versions | CP471-01, CP471-10, CP471-11 available |
| Enhanced RFI Option | 対応可能 with “/ERFI” option code |
| Maintenance | Hot-swappable in dual-redundant configuration |
| Operating Environment | Installed in CENTUM field 台s under standard conditions |
Product Applications
The CP471-00 module is widely used in mission-critical automation environments including:
-
Oil & Gas Processing Plants
-
Petrochemical and Chemical Plants
-
Power Generation Facilities
-
Water and Wastewater Treatment Plants
-
Pharmaceutical Manufacturing
-
Pulp & Paper Mills
-
Food & Beverage Processing
It is ideal for any application requiring high reliability, continuous operation, and advanced process control.
Key Advantages
-
High System Reliability: Dual-redundant support ensures uninterrupted system availability during processor failure.
-
Advanced Processing Capability: サポートs CENTUM VP R6.05 and higher for complex control logic and high-speed processing.
-
Hot-Swappable Maintenance: CP471-00 can be replaced online without shutting down the system in dual-redundant configurations.
-
Compact Design: Space-saving form factor suitable for dense installations.
-
Backward Compatibility: Enables upgrade from legacy CP461 modules (requires authorized service).
-
Industrial Compliance: Conforms to relevant standards through its use in compliant field control 台s.
-
Scalability: Modular design allows easy integration into expanding process control systems.
-
Environmental Robustness: Optional ISA G3 and Enhanced RFI (ERFI) options for harsh industrial environments.
よくある質問 (FAQ)
Q1: Can CP471-00 be used in systems earlier than CENTUM VP R6.05?
A1: No, CP471-00 requires CENTUM VP R6.05 or later for operation.
Q2: Is the CP471-00 hot-swappable?
A2: Yes, it supports online replacement when used in dual-redundant mode.
Q3: What modules does CP471-00 replace?
A3: It replaces CP461 modules, but the replacement must be performed by Yokogawa-authorized personnel.
Q4: Can CP471-00 be installed in systems requiring explosion protection?
A4: The CP471-00 itself does not provide explosion protection. Use CP471-01, CP471-10, or CP471-11 for such environments.
Q5: What type / systems can CP471-00 be installed in?
A5: It can be installed in AFV30, AFV40, A2FV50, and A2FV70 field control 台s.
Q6: Is CP471-00 compatible with all ESB bus coupler modules?
A6: Only with EC401 bus coupler modules / style code S3 or later.
Q7: What is the Enhanced RFI option?
A7: It provides improved resistance to radio frequency interference, suitable for noisy industrial environments.
Q8: Can CP471-00 and CP461 work together in a dual-redundant system?
A8: No, mixing CP471 and CP461 in a dual-redundant configuration is not allowed.
Q9: What is the weight / CP471-00?
A9: Approximately 0.7 kg.
Q10: Is any accessory included with the CP471-00?
A10: Yes, it includes a modification history label (品番. T9044AR).
Recommended Related モデルs (Same Series / Functional Compatibility)
| モデル | 説明 | Dimensions (mm) | 重量 |
|---|---|---|---|
| CP471-01 | With explosion protection | 199.5 x 149 x 32.8 | 0.7 kg |
| CP471-10 | FM NI Explosion Protection (n=0 台s) | 199.5 x 149 x 32.8 | 0.7 kg |
| CP471-11 | FM NI Explosion Protection (n=1 台s) | 199.5 x 149 x 32.8 | 0.7 kg |
| CP461 | Predecessor Processor Module (to be replaced) | 199.5 x 149 x 32.8 | 0.7 kg |
| EC401-S3 | ESB Bus Coupler Module (S3 style or later) | 130 x 100 x 40 | 0.5 kg |
| AFV30D-A*** | Duplexed Field Control ユニット for CP471 | Custom Assembly | Varies |
