製品紹介
The ABB Bailey NTRO02-A is a high-performance Relay Output Board designed to provide discrete output control for field devices in INFI 90, Net90, and Symphony Distributed Control Systems (DCS). Engineered for industrial automation applications, the NTRO02-A interfaces with the system’s logic processors and outputs control signals to external equipment such as motors, pumps, alarms, solenoids, and other actuators.
Each relay channel is isolated and independently controlled, making the NTRO02-A suitable for applications requiring robust, fail-safe operation. With its rugged construction, long relay life, and excellent compatibility with ABB control systems, this board ensures reliable performance in harsh industrial environments.
Technical Specifications
| Parameter | 説明 |
|---|---|
| モデル | NTRO02-A |
| Product Type | Relay Output Module |
| System Compatibility | ABB INFI 90, Net90, Symphony |
| Output Channels | 16 discrete relay outputs |
| Relay Type | Form A (SPST), electromechanical |
| お問い合わせ Rating | 2 A @ 30 VDC / 0.5 A @ 125 VAC |
| Output Voltage | Relay contact closure (dry contact) |
| Isolation | Channel-to-channel and channel-to-ground isolation |
| Power Supply | Supplied via I/O backplane |
| Status Indication | Individual LED indicators for each channel |
| Mounting Type | Rack-mounted (DIN-compatible) |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5% to 95% non-condensing |
| Protection Rating | IP20 (when mounted in cabinet) |
| Certifications | CE, UL, CSA |
| Dimensions (W x H x D) | 32.8 x 149 x 199.5 mm |
| 重量 | 0.7 kg |
Applications
The ABB NTRO02-A relay output module is ideally suited for a wide range / discrete output control applications in critical industrial systems. Some typical applications include:
-
Power Generation Plants: Controls motor starters, fans, pumps, alarm beacons, and solenoid valves.
-
Chemical and Petrochemical Industries: Manages output signals for process interlocks, shutdown circuits, and valve actuators.
-
Oil & Gas Facilities: Controls fire suppression systems, ESD actuators, and local control room indicators.
-
Water & Wastewater Treatment: Outputs control for valve actuators, dosing pumps, and overflow alarms.
-
Pulp and Paper Mills: Interfaces with conveyors, pressure release valves, and emergency stop relays.
-
Pharmaceutical Plants: Sends control signals for batch equipment, environmental alarms, and containment door locks.
Product Advantages
-
Reliable and Isolated Relay Outputs
Provides high-integrity signal switching with galvanic isolation to ensure safe, noise-free operation in complex environments. -
Built for Industrial Use
Rugged design, high contact rating, and resistance to vibration and temperature variations make it suitable for critical control rooms and field enclosures. -
Visual Status Feedback
On-board LEDs for each relay output allow for quick diagnostics and verification / output status. -
System Compatibility
Seamlessly integrates with ABB INFI 90, Net90, and Symphony control platforms, minimizing engineering time and system integration efforts. -
High Channel Density
Offers 16 relay outputs in a compact footprint, ideal for space-constrained control cabinets. -
Long Relay Life
High-quality relays rated for thousands / operations, supporting extended system uptime. -
Ease / Maintenance
Modular, rack-mounted design allows quick replacement and minimal downtime during service or upgrade.
よくある質問 (FAQ)
-
What is the main function / the NTRO02-A module?
It provides 16 discrete relay outputs for controlling field devices like motors, alarms, and solenoids. -
Does the NTRO02-A support both AC and DC loads?
Yes, it supports both, within its rated contact capacity (0.5 A @ 125 VAC or 2 A @ 30 VDC). -
Is the module hot-swappable?
番号 It should be powered down before installation or removal to ensure safety and prevent damage. -
How is each relay output isolated?
Each channel features galvanic isolation to prevent noise and protect against electrical faults. -
Can it be used in safety-critical systems?
Yes, it is commonly deployed in ESD (Emergency Shutdown) and interlock circuits, provided it meets your system’s safety design requirements. -
What is the lifetime / the relay contacts?
The relays are industrial-grade and rated for tens / thousands / switching cycles under nominal load conditions. -
How are the relays controlled?
Each relay is individually actuated based on signals from the logic processor or controller via the system backplane. -
Is there any diagnostic capability?
Yes, the module has individual LEDs to show the status / each output relay in real-time. -
What happens if a relay fails?
The relay is non-repairable at the component level; the entire module should be replaced for continued reliability. -
Does it require external power?
No, it draws required power directly from the control system’s I/O backplane.
Related or Same-Series ABB Bailey モデルs
| モデル | 型番 | 説明 |
|---|---|---|
| NTRO01-A | NTRO01-A | Relay output module with 8 channels |
| NTCL01 | NTCL01 | Termination 台 for logic controller signals |
| INLPM01 | INLPM01 | Logic processor module for discrete control |
| NTLS01 | NTLS01 | Logic station termination panel |
| NTRS01 | NTRS01 | Relay station output panel |
| NTRZ01 | NTRZ01 | Output relay zero crossover panel for high inrush loads |
Popular ABB Industrial Automation モデルs
| モデル | 型番 | Function |
|---|---|---|
| AC500 PM595-4ETH | 1SAP190100R0001 | High-end modular PLC with quad Ethernet ports |
| DCS880-S | 3AXD50000034501 | DC industrial drive for precision motor applications |
| AI830A | 3BSE008518R1 | Analog input module with 8 channels for process signals |
| CI840A | 3BSE041882R1 | Communication interface module for S800 I/O |
| TU849 | 3BSE042558R1 | Redundant termination 台 for AC800M systems |
| PM864AK01 | 3BSE018161R1 | High-speed controller for ABB’s 800xA control system |
