The Yokogawa ANT401-50 S1 Optical ESB Bus Repeater Master Module is a high-performance communication module designed to enhance system connectivity within large-scale distributed control systems (DCS). Serving as the master 台 in the ESB (Extension Serial Bus) optical repeater system, it ensures seamless communication between remote nodes and the central controller across extended distances. This module plays a crucial role in improving system scalability, reliability, and noise imm台y in industrial environments where electromagnetic interference (EMI) and long-distance data transfer are major challenges.
By using advanced optical communication technology, the ANT401-50 S1 supports high-speed data transmission over fiber-optic links, minimizing latency and ensuring deterministic performance for mission-critical processes. The module adheres to strict industrial standards, making it suitable for applications in oil & gas, petrochemical plants, power generation facilities, and other process automation sectors requiring robust and redundant network architecture.
製品仕様
| Parameter | 説明 |
|---|---|
| モデル | ANT401-50 S1 |
| Function | Optical ESB Bus Repeater Master Module |
| サポートed Network | ESB Bus Optical |
| Transmission Medium | Fiber Optic (Single-Mode/Multimode) |
| Communication Speed | Up to 1 Gbps |
| Number / Ports | 2 Optical Ports (TX/RX) |
| Power Supply | 24 VDC (±10%) |
| Power Consumption | Approx. 10 W |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% RH (Non-condensing) |
| Mounting Method | DIN Rail or Panel Mount |
| Dimensions (W × H × D) | 142.5 x 130 x 32.8 mm |
| 重量 | 0.3 kg |
| Compliance | CE, RoHS, IEC Standards |
Product Applications
The Yokogawa ANT401-50 S1 Optical ESB Bus Repeater Master Module is widely applied in industrial environments where long-distance, high-speed, and interference-free communication is essential. Common application areas include:
-
Process Automation Systems: Acts as a backbone for extending ESB bus connectivity between remote I/O nodes and control systems in large plants.
-
Oil & Gas Facilities: サポートs reliable communication in refineries, /fshore platforms, and pipeline monitoring.
-
Power Generation: Ensures stable data transmission across large-scale power stations, including thermal and nuclear facilities.
-
Petrochemical Plants: Provides robust communication links in environments with high EMI and hazardous conditions.
-
Pharmaceutical and Food Industries: Facilitates compliance with strict operational standards by maintaining deterministic communication.
Product Advantages
-
High-Speed Fiber-Optic Communication: Enables fast and reliable data transfer with minimal latency.
-
優良 EMI Imm台y: Optical technology eliminates electrical interference, ensuring stable system performance.
-
Long-Distance Connectivity: Capable / extending communication up to several kilometers without signal degradation.
-
Robust Redundancy サポート: Enhances system availability by supporting redundant communication paths.
-
Compact and Durable Design: Optimized for industrial environments, /fering easy installation and maintenance.
-
Wide Temperature and Humidity Range: Suitable for harsh and challenging operational conditions.
FAQ
-
What fiber type does the ANT401-50 S1 support, single-mode or multimode?
It supports both single-mode and multimode fibers, depending on the required distance. -
What is the maximum distance achievable with fiber-optic communication using this module?
Typically up to 15 km with single-mode fiber, depending on system configuration. -
Does the ANT401-50 S1 support redundant communication paths?
Yes, it supports redundant optical paths for high system availability. -
What is the maximum number / nodes that can be connected to the ESB bus via this module?
Up to 64 nodes can be connected, depending on network design. -
What protocols are supported over the ESB bus using this module?
It supports Yokogawa’s proprietary ESB protocol for real-time process communication. -
Can the ANT401-50 S1 operate in hazardous areas?
It can be installed in certified enclosures for hazardous environments, complying with relevant standards. -
What diagnostic features are available for fault detection?
It provides LED status indicators, built-in diagnostics, and alarm outputs for link monitoring. -
Is hot-swapping supported for this module?
Yes, it can be replaced without shutting down the entire system when configured properly. -
How does the module handle synchronization across multiple nodes?
It uses time-synchronized data exchange mechanisms to ensure deterministic communication. -
What measures are in place to handle data transmission errors?
The module uses CRC error detection and automatic retransmission for error correction.
