製品紹介
The Yokogawa AIP571-S2 is an advanced Electrical Transceiver module designed for use within Yokogawa’s Remote I/O (RIO) system architecture. This module serves as a critical communication interface between the central control system and remote field devices. The AIP571-S2 is engineered to provide robust, noise-resistant data transmission over long distances through electrical signaling on twisted-pair cabling.
It supports reliable communication within Yokogawa’s CENTUM VP and other RIO-based distributed control systems, facilitating seamless integration for large-scale industrial automation networks. Its design emphasizes durability, operational stability, and ease / maintenance, making it well-suited for harsh industrial environments where consistent performance is essential.
製品仕様
| Parameter | Specification |
|---|---|
| モデル Number | AIP571-S2 |
| Module Type | Electrical Transceiver RIO I/O Module |
| Communication Protocol | RIO (Remote I/O) |
| Transmission Type | Electrical (twisted pair cable) |
| Maximum Communication Distance | Up to 1200 meters (approximately 4000 feet) |
| Data Transfer Rate | 1 Mbps |
| Power Supply Voltage | 24 V DC |
| Operating Temperature Range | 0°C to 55°C (32°F to 131°F) |
| Storage Temperature Range | -20°C to 70°C (-4°F to 158°F) |
| Relative Humidity | 10% to 95% (non-condensing) |
| Dimensions (WxHxD) | 150 x 120 x 50 mm |
| 重量 | 0.408 kg |
| Mounting Type | Rack-mounted / DIN rail compatible |
| Standards Compliance | IEC 61131-2, CE, UL |
Product Applications
-
Process Control Systems: Enables long-distance and reliable communication for remote I/O in chemical, petrochemical, and refining plants.
-
Power Generation: Facilitates control and monitoring / distributed equipment in power plants.
-
Water and Wastewater Treatment: サポートs remote data acquisition and control in large-scale water management systems.
-
Oil & Gas Industry: Used for upstream and downstream field control instrumentation.
-
Manufacturing Automation: Enables integration / remote sensors and actuators on assembly lines and processing equipment.
-
Infrastructure and Utilities: Provides connectivity for building automation and large infrastructure control networks.
Product Advantages
-
Reliable Long-Distance Communication: サポートs up to 1200 meters / cable length with stable electrical signaling, reducing the need for repeaters.
-
Robust Against Electrical Noise: Designed to operate in electrically noisy industrial environments with minimal data corruption.
-
Compact and Durable: Small physical footprint paired with a rugged design suitable for harsh plant conditions.
-
High-Speed Data Transfer: Maintains a consistent 1 Mbps communication rate for timely data exchange.
-
Flexible Mounting Options: サポートs rack mounting and DIN rail installation for versatile cabinet setups.
-
Energy Efficient: Low power consumption minimizes operating costs and heat generation.
-
Easy Integration: Seamlessly interfaces with Yokogawa CENTUM VP and other RIO-compatible systems.
-
Advanced Diagnostics: Features built-in diagnostics to facilitate preventive maintenance and reduce downtime.
-
Wide Environmental Tolerance: Operates effectively across a broad temperature and humidity range.
-
Industrial Compliance: Meets key industry standards for safety and reliability.
よくある質問 (FAQ)
-
What role does the AIP571-S2 module serve in a control system?
It functions as an electrical transceiver for Remote I/O communications, connecting field devices with the control system. -
What is the maximum communication distance supported by this module?
The AIP571-S2 supports up to 1200 meters (around 4000 feet) over twisted pair cable. -
Which communication protocol does the module use?
It operates using Yokogawa’s Remote I/O (RIO) protocol. -
What operating temperature range does the module support?
The module works within 0°C to 55°C (32°F to 131°F). -
Is this module compatible with Yokogawa CENTUM VP?
Yes, it is designed for full compatibility with CENTUM VP systems. -
What is the power requirement for the AIP571-S2?
It requires a 24 V DC power supply. -
How does this module handle electrical noise in industrial environments?
It incorporates noise-resistant design features to ensure stable communication. -
Can the module be installed on standard DIN rails?
Yes, it supports both rack mounting and DIN rail installation. -
What diagnostic features are available?
The module includes built-in diagnostics for communication status and fault detection. -
What are the dimensions and weight / the AIP571-S2?
Dimensions are 150 x 120 x 50 mm, and it weighs 0.408 kg.
Recommended Related モデルs (Same Series / Similar Function)
| モデル Number | 説明 | Communication Type | Max Distance (m) | Dimensions (WxHxD mm) | 重量 (g) |
|---|---|---|---|---|---|
| AIP571-S1 | Electrical Transceiver RIO Module | Electrical | 1200 | 45 x 160 x 130 | 600 |
| AIP571-P1 | Optical Transceiver RIO Module | Optical Fiber | 10,000 | 45 x 160 x 130 | 650 |
| AIP571-P2 | High-Speed Electrical Transceiver | Electrical | 1200 | 45 x 160 x 130 | 600 |
| AIP571-S3 | Electrical Transceiver Extended Temp | Electrical | 1500 | 45 x 160 x 130 | 630 |
| AIP571-E1 | Extended Distance Optical Transceiver | Optical Fiber | 20,000 | 45 x 160 x 130 | 680 |
| AIP572-S1 | Redundant Electrical Transceiver | Electrical | 1200 | 45 x 160 x 130 | 650 |
Popular Yokogawa モデルs (Same ブランド)
| モデル Number | 説明 | Type | Channels/Input/Output | Dimensions (WxHxD mm) | 重量 (g) |
|---|---|---|---|---|---|
| CENTUM VP | Integrated Control System | Control System | N/A | Varies | Varies |
| ADV771-M01 | Controller Module | Controller | N/A | 150 x 250 x 200 | 7000 |
| ADV890-M02 | Communication Interface Module | Communication | N/A | 30 x 150 x 180 | 500 |
| AIP571-P1 | Optical Transceiver RIO Module | Optical Fiber Transceiver | N/A | 45 x 160 x 130 | 650 |
| ADV761-M03 | Analog Input Module | Analog I/O | 16 Inputs | 30 x 150 x 180 | 450 |
| ADV761-M04 | Analog Output Module | Analog I/O | 16 Outputs | 30 x 150 x 180 | 470 |
