The Yokogawa AFV30D-S41251 S2 Duplexed Field Control ユニット (FCU) is a high-reliability control platform developed for Yokogawa’s CENTUM VP distributed control system. This model builds upon the proven AFV30D architecture with S2 enhancements, /fering stronger redundancy, improved processing capabilities, and advanced fault tolerance.
The FCU is specifically designed for large-scale, mission-critical process industries where downtime and process interruptions are unacceptable. With duplexed CPUs, redundant power supplies, and dual communication paths, the AFV30D-S41251 S2 ensures continuous operation even if critical hardware fails. Its hot-swappable design allows maintenance while the system is live, minimizing plant downtime.
製品仕様
| Parameter | 説明 |
|---|---|
| モデル | AFV30D-S41251 S2 |
| Type | Duplexed Field Control ユニット (FCU) |
| System Compatibility | Yokogawa CENTUM VP |
| Processor | High-speed 32-bit RISC processor (duplexed configuration) |
| Memory Capacity | 128 MB SDRAM, 32 MB Flash memory |
| I/O Capacity | Up to 1,000 I/O points (expandable with multiple 台s) |
| Redundancy | Duplex CPU, power supply, and Vnet/IP communication modules |
| Communication Protocols | Vnet/IP, Ethernet, FOUNDATION Fieldbus, HART |
| Control Cycle Time | 50 ms typical |
| Diagnostics | Built-in self-diagnostics with error logging |
| Operating Temperature | 0 to 55 °C |
| Storage Temperature | -20 to 70 °C |
| Power Supply | 24 V DC (redundant input supported) |
| Power Consumption | Approx. 45 W |
| Mounting | Rack-mounted configuration |
| Dimensions (W × H × D) | 207 × 265.9 x 482.6 mm |
| 重量 | 8 kg |
| Certification | CE, UL, CSA, ATEX certified for hazardous areas |
Product Applications
The AFV30D-S41251 S2 is used in continuous and batch process industries requiring maximum system availability:
-
Oil & Gas: Supervisory control for drilling rigs, LNG facilities, and refinery 台s.
-
Power Generation: Boiler and turbine control systems in thermal and nuclear power plants.
-
Petrochemical & Chemical Plants: High-precision control / cracking, polymerization, and distillation processes.
-
Pharmaceuticals: Batch control with stringent compliance to regulatory requirements.
-
Water & Wastewater: Large treatment plants with complex pumping and filtration systems.
-
Metals & Mining: Automation / high-temperature and heavy industrial processes.
Product Advantages
-
Duplexed Reliability: Redundant CPU, communication, and power modules ensure fault-tolerant operation.
-
Fast Response: 50 ms cycle time delivers real-time control and quick response to process fluctuations.
-
Enhanced Diagnostics: Advanced self-diagnostics and system monitoring reduce troubleshooting time.
-
Hot-Swappable Modules: Maintenance can be performed without system shutdown.
-
Backward Compatibility: Smooth integration with existing Yokogawa CS 3000 and earlier CENTUM systems.
-
Scalable Design: サポートs large I/O counts and can be expanded for bigger installations.
-
Industrial Security: Includes access control, secure communication, and audit trail for cyber protection.
-
Proven Stability: Built for long-term use in demanding, hazardous industrial environments.
FAQ
-
What is the typical control cycle time for the AFV30D-S41251 S2?
The 台 operates on a 50 ms control cycle, providing fast loop response. -
How does the duplex CPU system manage failover?
When the primary CPU fails, the backup CPU immediately takes over without interrupting control. -
Does the 台 support FOUNDATION Fieldbus and HART integration?
Yes, it supports both FOUNDATION Fieldbus and HART communication protocols. -
Can configuration updates be applied online?
Yes, online configuration changes are supported without halting plant operations. -
What type / redundancy is available for power input?
It accepts dual 24 V DC inputs, ensuring uninterrupted power supply through redundancy. -
How is communication redundancy implemented?
The FCU uses Vnet/IP with dual network paths to eliminate single-point failures. -
Are the hardware modules hot-swappable?
Yes, critical components such as CPUs and communication cards are hot-swappable. -
What is the maximum number / I/O points supported?
The 台 supports up to 1,000 I/O points, expandable with additional 台s. -
How does the system handle error detection?
It employs built-in self-diagnostics with detailed error logging for quick recovery. -
What cybersecurity features are included?
The 台 includes encrypted communication, user authentication, and system audit trail functions.
