製品紹介
The Yokogawa ADM12-S4 is a contact output I/O card developed as part / Yokogawa’s high-reliability industrial automation systems. This output module is designed to be used with Yokogawa’s CENTUM series / distributed control systems (DCS), including the CENTUM CS 3000/VP series. It is engineered to provide isolated contact outputs for controlling external devices such as relays, solenoids, and signal lamps.
Built to support critical process control operations, the ADM12-S4 provides stable and dependable operation in environments where system availability and safety are crucial. It features robust contact output points and integrates seamlessly into large-scale control architectures, making it suitable for a wide array / industrial applications.
製品仕様
| Parameter | 説明 |
|---|---|
| モデル Number | ADM12-S4 |
| メーカー | 横河電機 Corporation |
| Product Type | お問い合わせ Output I/O Card |
| Output Type | Relay contact output |
| Number / Output Channels | 12 channels |
| お問い合わせ Type | Form A (SPST-NO) |
| お問い合わせ Rating | 24 VDC / 2 A (resistive load) |
| Isolation | Optically isolated per channel |
| Response Time | ≤ 10 ms |
| Power Supply Voltage | 5 VDC / Supplied via I/O base |
| Module Connection | Mounted on N-IO baseplate |
| LED Indicators | Yes (Per channel for output status) |
| Operating Temperature Range | 0°C to 50°C |
| Storage Temperature Range | -20°C to +70°C |
| Relative Humidity | 5% to 95% RH (non-condensing) |
| Certifications | CE, CSA, UL, and RoHS compliant |
| Dimensions (W x H x D) | 150 x 50 x 80 mm |
| 重量 | 0.74 kg |
Applications
The Yokogawa ADM12-S4 is suitable for a wide variety / industrial automation and process control scenarios, particularly where safe and reliable actuation / external devices is essential:
-
Chemical and Petrochemical Plants
Controlling pumps, valves, and alarms with high reliability. -
Oil & Gas Facilities
Used in safety systems and remote I/O applications for field devices. -
Power Generation Plants
Integration into turbine control and balance-/-plant operations. -
Water and Wastewater Treatment
Actuating solenoids and level switches for fluid management. -
Pharmaceutical Manufacturing
Automation / cleanroom systems and environmental monitoring. -
Pulp and Paper Industry
Managing paper machinery outputs and drying systems.
Product Advantages
-
High Channel Density: 12 output channels in a single module reduce the need for multiple cards, optimizing cabinet space.
-
お問い合わせ Reliability: Gold-plated contact relays ensure long service life and minimal contact resistance.
-
Electrical Isolation: Optically isolated channels enhance system safety and prevent signal interference.
-
Seamless Integration: Fully compatible with Yokogawa’s CENTUM VP/CS 3000 DCS platforms.
-
Diagnostic Indicators: Built-in LEDs provide instant channel output status for quick troubleshooting.
-
Proven Durability: Industrial-grade design ensures stable performance in harsh environments.
-
Global Certifications: Certified for use in global markets, supporting diverse regulatory needs.
-
Modular Design: Easy installation and replacement without disturbing adjacent modules.
よくある質問 (FAQ)
-
What system platforms is the ADM12-S4 compatible with?
The ADM12-S4 is compatible with Yokogawa’s CENTUM CS 3000 and CENTUM VP systems. -
How many contact output channels are available on the ADM12-S4?
This model provides 12 individual contact output channels. -
What type / devices can be controlled using this card?
Devices such as relays, alarms, signal lamps, and solenoids can be controlled. -
Does the ADM12-S4 provide electrical isolation for each channel?
Yes, each output channel is optically isolated to ensure signal integrity and protection. -
Is there a way to visually confirm output status on the module?
Yes, each channel has an individual LED status indicator. -
Can the module operate in outdoor environments?
It is designed for indoor, cabinet-mounted environments with temperature and humidity control. -
How is the ADM12-S4 installed?
It is installed on a dedicated I/O baseplate within the Yokogawa control system rack. -
What safety certifications does this module carry?
CE, CSA, UL, and RoHS certifications are included for international compliance. -
What is the expected service life / the relays used?
Typically rated for over 100,000 operations under standard loads. -
Does the card support hot-swap or live insertion?
No, power must be /f during insertion or removal to ensure safety and prevent damage.
Related モデルs (Same Series or Functionality)
| モデル | 説明 | Output Type | Channels | Remarks |
|---|---|---|---|---|
| ADM11-S4 | Digital output card with 8 channels | Relay お問い合わせ | 8 | Lower channel count variant |
| ADV151-P03 | Digital output module (transistor) | Transistor (sink type) | 32 | Suitable for high-speed operations |
| ADM51-S2 | Digital output module with mechanical relays | Mechanical relay | 16 | General-purpose contact output |
| ADV551-P00 | Transistor output module | Transistor | 32 | Compatible with FIO systems |
| ADM52-S3 | Relay output module for safety applications | Safety-rated relay | 8 | Enhanced safety features |
| ADM61-S4 | Mixed I/O card with input and output functions | お問い合わせ (mixed) | 6 in / 6 out | Suitable for compact I/O applications |
Popular Yokogawa モデルs (Same ブランド – High Demand)
| モデル | 説明 | カテゴリー | Key Feature |
|---|---|---|---|
| CPU50S | Processor module for CENTUM VP systems | Controller CPU | High-speed processing |
| FIO100 | Field I/O Node for N-IO system | Remote I/O | Modular and scalable I/O |
| PW482-10 | Power supply module for system racks | Power Supply | High reliability and long life |
| ADV151-P03 | High-density digital output module | Digital Output | Transistor outputs, 32 ch |
| AAI543-H00 | Analog input module with HART | Analog Input | 16-channel with HART communication |
| AAR145-S00 | Analog output module with high resolution | Analog Output | 8-channel, 16-bit resolution |
