製品紹介
The Yokogawa ADM11 is a 16-channel contact input module designed for seamless integration into Yokogawa’s CENTUM CS and CENTUM VP distributed control systems (DCS). This module facilitates the monitoring / discrete signals from field devices such as switches, pushbuttons, and relays, ensuring accurate and reliable data acquisition for process control applications.
Technical Specifications
| Parameter | Details |
|---|---|
| モデル Number | ADM11 |
| Module Type | お問い合わせ Input Module |
| Number / Input Channels | 16 |
| Input Voltage Range | 4 to 32 V DC |
| Input Type | Dry contact |
| Response Time | ≤ 5 ms |
| Isolation | Galvanic isolation between channels and system |
| Power Supply Voltage | 24 V DC |
| Power Consumption | Low power consumption |
| Operating Temperature Range | 0°C to 60°C |
| Storage Temperature Range | -25°C to 70°C |
| Humidity | 5% to 95% RH (non-condensing) |
| Mounting Type | DIN rail mountable |
| Dimensions (W x H x D) | 125 x 130 x 248 mm |
| 重量 | 0.14 kg |
| Certifications | CE, RoHS |
Product Applications
The ADM11 module is engineered for a wide range / industrial applications requiring reliable contact input monitoring:
-
Process Automation: Monitoring the on//f status / field equipment such as valves, pumps, and motors.
-
Manufacturing Control: Supervising machinery and systems in manufacturing plants to ensure smooth operation.
-
Building Automation: Controlling HVAC, lighting, and security systems for optimal building performance.
-
Energy Management: Monitoring circuit breakers, switches, and other electrical components in power distribution systems.
-
Water Treatment Facilities: Tracking the status / pumps, filters, and other equipment in water and wastewater treatment plants.
-
Transportation Systems: Monitoring signals and switches in railway and other transportation control systems.
Product Advantages
-
High Channel Density: 16 input channels in a compact module reduce space requirements and simplify wiring.
-
Fast Response Time: Quick detection / input signal changes ensures timely system responses.
-
Robust Isolation: Galvanic isolation between channels and the system enhances safety and prevents signal interference.
-
Wide Voltage Range: サポートs a broad input voltage range, accommodating various field devices.
-
Energy Efficient: Low power consumption contributes to overall system efficiency.
-
Easy Integration: Seamlessly integrates with Yokogawa’s CENTUM CS and CENTUM VP systems.
-
Durable Design: Built to withstand harsh industrial environments with a wide operating temperature range.
-
Compliance: Meets international standards for safety and environmental compliance.
よくある質問 (FAQ)
-
What is the input voltage range / the ADM11 module?
-
The module accepts input voltages ranging from 4 to 32 V DC.
-
-
How many input channels does the ADM11 have?
-
It features 16 discrete input channels.
-
-
What type / inputs does the ADM11 support?
-
The module is designed for dry contact inputs, suitable for monitoring switches, pushbuttons, and similar devices.
-
-
Is the ADM11 module isolated?
-
Yes, it provides galvanic isolation between input channels and the system to prevent interference and enhance safety.
-
-
What is the response time / the ADM11?
-
The module has a fast response time / ≤ 5 milliseconds.
-
-
Can the ADM11 operate in harsh environments?
-
Yes, it operates within a temperature range / 0°C to 60°C and humidity levels / 5% to 95% RH (non-condensing).
-
-
What is the power supply requirement for the ADM11?
-
The module requires a 24 V DC power supply.
-
-
How is the ADM11 mounted?
-
It is designed for DIN rail mounting, facilitating easy installation in control panels.
-
-
What are the dimensions and weight / the ADM11?
-
Dimensions: 125 x 130 x 248 mm; 重量: 0.14 kg.
-
-
Is the ADM11 compatible with Yokogawa’s DCS systems?
-
Yes, it is compatible with CENTUM CS and CENTUM VP distributed control systems.
-
Related モデルs (Same Series or Related Functionality)
| モデル | Function | Channels | Signal Type | Remarks |
|---|---|---|---|---|
| ADM11C | お問い合わせ Input Module | 16 | Dry contact | Connector type variant / ADM11 |
| ADM11T | お問い合わせ Input Module | 16 | Dry contact | Terminal type variant / ADM11 |
| ADM12 | お問い合わせ Input Module | 32 | Dry contact | Higher channel count for larger applications |
| ADM12T | お問い合わせ Input Module | 32 | Dry contact | Terminal type variant / ADM12 |
| ADM11 S3 | お問い合わせ Input Module | 16 | Dry contact | Enhanced version with improved specifications |
| ADM12C S1 | お問い合わせ Input Module | 32 | Dry contact | Connector type variant / ADM12 |
Popular Yokogawa モデルs (Same ブランド Recommendations)
| モデル | Type | Function | Signal Type | Typical Application |
|---|---|---|---|---|
| AAI143-S00 | Analog Input Module | 4–20 mA Input | Current | Process transmitters (flow, pressure) |
| AAI543-S00 | Analog Output Module | 4–20 mA Output | Current | Final control elements (valves, actuators) |
| ADV151-P03 | Digital Output Module | Relay/Transistor Switching | Digital | Alarms, indicator lights |
| AAR181-S00 | RTD Input Module | Temperature Input | RTD | Biotech and HVAC systems |
| ANB11D | Node Interface Module | DCS Network Interface | Vnet/IP | Communication integration |
| AMN11 | Main Controller Module | Logic and Process Control | CPU | Core system logic processing |
