Product Overview
The Schneider TSXPSY1610 is a high-performance power supply module designed specifically for the Modicon Premium series / programmable logic controllers (PLCs). As a critical component / the automation architecture, the TSXPSY1610 ensures stable and regulated power to the CPU and I/O modules within the PLC rack. Engineered with Schneider’s industrial-grade design standards, it delivers both reliability and operational efficiency in demanding control applications.
This power module operates with a 100–240 VAC input and provides a regulated 5 VDC output necessary to power the entire PLC system. With overload and short-circuit protection built-in, the TSXPSY1610 supports safe operation and minimal downtime. Its compact form factor and modular installation make it an ideal solution for scalable automation environments.
Key Features
-
Wide input voltage range: 100 to 240 VAC
-
Regulated 5 VDC output for Premium PLC backplane
-
Maximum output current up to 3 A
-
Overload, short-circuit, and overvoltage protection
-
Modular rack mounting for quick installation
-
LED indicators for diagnostics and power status
-
Industrial temperature tolerance for harsh environments
-
Designed specifically for Modicon Premium automation systems
Technical Specifications
| Parameter | Specification |
|---|---|
| Input Voltage Range | 100 – 240 VAC, 50/60 Hz |
| Inrush Current | ≤ 30 A |
| Output Voltage | 5 VDC |
| Maximum Output Current | 3 A |
| Maximum Output Power | 15 W |
| Efficiency | ≥ 70% |
| Protection Functions | Overload, short-circuit, overvoltage |
| LED Status Indicators | Power ON (green), Fault (red) |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature | -25°C to +85°C (-13°F to 185°F) |
| Relative Humidity | 5% to 95%, non-condensing |
| Dimensions | Package size 55 ×180 ×260 mm |
| 重量 | 0.54 kg |
| Mounting Type | Rack-mounted (Modicon Premium backplane) |
| Compliance Certifications | CE, UL, CSA, RoHS |
Product Advantages
-
High Stability: Provides consistent 5 VDC output to ensure stable PLC operation.
-
Robust Design: Built to withstand industrial noise, voltage spikes, and harsh temperature ranges.
-
Built-in Protection: Safeguards both the power supply and the connected automation equipment.
-
Plug-and-Play Installation: Seamless integration into existing Modicon Premium racks.
-
Energy Efficient: Optimized internal design helps reduce energy consumption and heat output.
-
Status Indicators: Onboard LEDs /fer immediate visual feedback on module status.
-
Compact & Lightweight: 保存s space in dense control cabinets and simplifies maintenance.
Industry Applications
-
Industrial automation and process control
-
Machine control systems in manufacturing
-
Building management and automation infrastructure
-
Water and wastewater treatment plants
-
Power distribution and substation monitoring
-
Food and beverage production lines
-
Packaging and material handling systems
よくある質問 (FAQ)
-
Q: What PLC series is the TSXPSY1610 compatible with?
A: It is designed specifically for the Schneider Modicon Premium PLC system. -
Q: Can it be used with 24VDC input?
A: No, it only supports 100–240 VAC input voltage. -
Q: How much current can it provide?
A: The TSXPSY1610 delivers up to 3 A / output current at 5 VDC. -
Q: Does this power supply require external cooling?
A: No, it is designed for passive convection cooling under normal operating conditions. -
Q: Is this module hot-swappable?
A: No, it must be powered down before installation or replacement to ensure safety. -
Q: Are there LEDs for diagnostics?
A: Yes, it has Power ON (green) and Fault (red) status LEDs. -
Q: What type / mounting does it support?
A: It mounts directly onto the Modicon Premium PLC rack backplane. -
Q: Can it operate in high humidity environments?
A: Yes, it supports 5% to 95% non-condensing humidity. -
Q: What happens in case / output overload?
A: The power module has built-in protection and will shut down output safely. -
Q: What certifications does it meet?
A: It complies with CE, UL, CSA, and RoHS standards.
