The Schneider TSXAEY1614 is a versatile analog input module designed for the Modicon TSX Micro automation system. It serves as a critical component in industrial control applications, facilitating the acquisition and processing / various analog signals from external sensors and devices. Known for its reliability and precision, the TSXAEY1614 supports multiple signal types, including voltage, current, and temperature sensors.
This module /fers 16 input channels, enabling extensive data gathering capabilities within compact automation racks. It is engineered for smooth integration with Schneider Electric’s TSX Micro programmable logic controllers (PLCs), making it a popular choice for process automation, manufacturing systems, and retr/it projects in legacy environments.
The TSXAEY1614 is favored in industries that demand precise measurement, high durability, and consistent operation under a range / environmental conditions.
Technical Specifications
| Parameter | Details |
|---|---|
| モデル Number | TSXAEY1614 |
| Module Type | Analog Input Module |
| Number / Channels | 16 |
| Input Signal Types | Voltage, Current, RTD, Thermocouples |
| Voltage Input Range | ±10 V |
| Current Input Range | 0-20 mA, 4-20 mA |
| Temperature Inputs | サポートs multiple thermocouples and RTDs |
| Resolution | 12-bit ADC |
| Input Impedance | >1 MΩ for voltage inputs |
| Sampling Rate | 15 ms per channel |
| Communication Protocol | UNI-TELWAY (RS-485) |
| Power Supply | Powered through backplane (5 V typical) |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -25°C to 70°C (-13°F to 158°F) |
| Humidity | 5% to 95%, non-condensing |
| Protection Rating | IP20 |
| Dimensions (W x H x D) | 55 x 180 x 260 mm |
| 重量 | 0.35 kg |
| Certifications | CE, UL, CSA, GOST |
Applications
The TSXAEY1614 Analog Input Module is employed in various sectors requiring reliable analog data acquisition and control, such as:
-
Industrial Process Automation: Capturing analog data like temperature, pressure, and flow from sensors in chemical, pharmaceutical, and food processing plants.
-
Energy and Utilities: Monitoring analog signals in power generation and distribution systems to ensure stable operations.
-
Water and Wastewater Management: Measuring levels, turbidity, and chemical dosing through analog sensors.
-
Building Automation: Managing HVAC systems by monitoring temperature and humidity signals.
-
Manufacturing Automation: サポートing assembly lines with precise sensor data acquisition for quality control.
-
OEM Equipment: Integration into custom machinery that requires multi-channel analog inputs.
Advantages
-
High Channel Count: With 16 input channels, the TSXAEY1614 /fers extensive analog data gathering within a single module.
-
Multi-Signal サポート: Compatible with voltage, current, thermocouples, and RTD inputs for versatile sensor integration.
-
Accurate Measurements: 12-bit ADC ensures reliable and precise signal conversion.
-
Robust Design: Suitable for industrial environments with wide temperature and humidity tolerances.
-
Simple Integration: Seamlessly fits into the TSX Micro system using UNI-TELWAY communication.
-
Legacy System サポート: Ideal for existing TSX Micro installations and retr/it projects.
-
Compact Form Factor: Allows efficient use / panel space despite high channel density.
よくある質問 (FAQ)
-
How many analog inputs does the TSXAEY1614 module support?
It supports 16 individual analog input channels. -
What types / sensors can be connected?
The module supports voltage, current, RTDs, and thermocouple sensors. -
What is the resolution / the analog inputs?
The module uses a 12-bit analog-to-digital converter. -
Can the module measure temperature directly?
Yes, it can interface directly with RTDs and various types / thermocouples. -
Is the TSXAEY1614 compatible with modern Schneider PLCs?
It is designed for TSX Micro systems and may not be compatible with newer Modicon lines. -
What is the power requirement for this module?
The module receives power from the TSX Micro backplane, typically 5 VDC. -
What communication protocol does the module use?
It communicates via the UNI-TELWAY protocol over RS-485. -
Is it possible to hot-swap the TSXAEY1614?
No, the module should be installed or removed only when the system is powered down. -
What are the environmental limits for operating this module?
It operates within 0°C to 60°C and humidity levels / 5% to 95%, non-condensing. -
Are there any certifications for this product?
Yes, it holds CE, UL, CSA, and GOST certifications for safety and compliance.
Related モデルs (Same Series or Function)
| モデル Number | 説明 |
|---|---|
| TSXAEY1600 | 8-channel analog input module for TSX Micro |
| TSXAEY1610 | 16-channel analog input module with enhanced filtering |
| TSXAEY1615 | Analog input/output hybrid module for TSX Micro |
| TSXAEY1620 | High precision voltage input module |
| TSXAEY1602 | 4-20 mA current input module |
| TSXAEY1604 | Temperature input module specialized for RTDs and thermocouples |
Popular Schneider モデルs (Same ブランド)
| モデル Number | 説明 |
|---|---|
| TM221C24T | Modicon M221 controller with 24 I/O transistor outputs |
| TM241CE40T | Modicon M241 controller with Ethernet and CANopen |
| BMXP342020 | Modicon M340 CPU module with advanced processing capabilities |
| TSXPSY2600 | Power supply for TSX Micro controllers |
| TM251MESE | Modicon M251 controller with networking capabilities |
| BMXAMO0500 | Analog input module for Modicon M340 series |
