The Schneider STBDDO3705 Basic Digital Output Module is a reliable and efficient device designed for use in industrial automation and control systems. This module provides multiple digital output channels, enabling it to interface seamlessly with various actuators, relays, and indicators in a control system. Its compact design and robust construction make it suitable for use in harsh industrial environments, ensuring stable and precise output performance.
The STBDDO3705 module integrates smoothly with Schneider’s broader automation product line, /fering flexibility for system expansion and upgrades. It supports fast switching speeds, high noise imm台y, and /fers diagnostic feedback to enhance maintenance and operational reliability. This digital output module is ideal for systems requiring discrete control signals with high accuracy and durability.
製品仕様
| Parameter | Specification |
|---|---|
| モデル | STBDDO3705 |
| Type | Basic Digital Output Module |
| Number / Outputs | 8 Channels |
| Output Type | Relay / Transistor (depending on variant) |
| Output Voltage | 24 V DC (typical) |
| Output Current | 0.5 A per channel |
| Response Time | ≤ 5 ms |
| Input Voltage Range | 20 – 30 V DC |
| Isolation | Optical isolation for output channels |
| Operating Temperature | -25°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Dimensions (WxHxD) | 13.9 x 70 x 128.3 mm |
| 重量 | 0.086 kg |
| Mounting | DIN Rail |
| Communication Protocol | Compatible with Schneider PLC platforms |
| Certification | CE, UL, RoHS |
Product Applications
-
Industrial Automation: Used to control actuators, solenoids, and indicator lights in automated manufacturing processes.
-
Building Automation: Controls lighting, HVAC systems, and access control devices.
-
Process Control: Interfaces with valves and other digital control devices in chemical, water treatment, and oil & gas industries.
-
Machine Control: Provides discrete output signals for machine operation sequencing and safety interlocks.
-
Energy Management Systems: Controls relays and contactors for power distribution and load management.
-
Transport and Infrastructure: Automation for railway signaling, traffic control, and automated gates.
Product Advantages
-
Compact and Space-Saving: Designed to fit in limited panel space with a slim DIN rail mounting pr/ile.
-
Robust Build: Durable construction ensures long service life even under harsh environmental conditions.
-
High Reliability: Optical isolation reduces interference and improves signal integrity.
-
Easy Integration: Seamless compatibility with Schneider’s PLC and automation systems simplifies system design.
-
Fast Response: Quick switching times enable high-speed control in critical applications.
-
Energy Efficient: Low power consumption reduces operational costs.
-
Diagnostics Capability: Provides status feedback and fault detection to facilitate troubleshooting.
-
Wide Operating Range: Suitable for a broad range / industrial environments with wide temperature and humidity tolerance.
-
Safety Certified: Complies with international safety and environmental standards.
-
Scalable: サポートs modular system expansion to meet growing automation needs.
FAQ
-
What is the maximum current per output channel?
The STBDDO3705 supports up to 0.5 A per output channel. -
Can this module be used with Schneider PLCs?
Yes, it is fully compatible with Schneider PLC platforms. -
What types / outputs does the module provide?
It provides relay or transistor outputs depending on the module variant. -
Is the module suitable for outdoor use?
The module is designed for industrial environments but requires enclosure protection for outdoor use. -
What is the operating temperature range?
The module operates reliably between -25°C and +60°C. -
How is the module mounted?
It is mounted on a standard DIN rail. -
Does the module provide any diagnostic feedback?
Yes, it /fers status and fault indication to aid maintenance. -
What kind / isolation does the module have?
It uses optical isolation on output channels for noise imm台y. -
Is the module compliant with safety standards?
Yes, it meets CE, UL, and RoHS certifications. -
Can this module handle high switching speeds?
Yes, it supports switching times less than or equal to 5 milliseconds.
Recommended Related モデルs (Same Series or Similar)
| モデル | Output Channels | Output Type | Dimensions (mm) | 重量 (kg) |
|---|---|---|---|---|
| STBDDO3710 | 16 | Digital Relay | 90 x 110 x 75 | 0.55 |
| STBDDO3706 | 8 | Transistor | 45 x 110 x 75 | 0.32 |
| STBDDO3712 | 12 | Relay | 70 x 110 x 75 | 0.45 |
| STBDDI3705 | 8 | Digital Input | 45 x 110 x 75 | 0.30 |
| STBDIO3707 | 16 | Digital I/O | 90 x 110 x 75 | 0.60 |
| STBDRO3704 | 4 | Relay Output | 30 x 110 x 75 | 0.25 |
Popular Schneider モデルs (Same ブランド)
| モデル | 説明 | Output Channels | Communication Protocol | 重量 (kg) |
|---|---|---|---|---|
| Modicon M221 | Compact PLC controller | Varies | Modbus TCP, Ethernet | 0.6 |
| Modicon M241 | Mid-range PLC | Varies | Ethernet/IP, Modbus | 1.1 |
| Harmony XB5 | Control and signaling devices | N/A | N/A | Varies |
| Telemecanique Sensors | Industrial sensors | N/A | N/A | Varies |
| Altivar ATV320 | Variable frequency drives | N/A | Ethernet/IP, Modbus | 2.0 |
| Lexium Servo Drives | Servo motor drives | N/A | Ethernet/IP | 1.8 |
