Product Overview
The Schneider Electric ATV630D18N4 is a high-performance variable speed drive from the Altivar Process ATV630 series, engineered for managing complex fluid and process control applications. This model supports 180 kW (240 HP) motors and operates on 3-phase 380–480 V AC input, delivering excellent performance in heavy-duty industrial environments.
Designed for intelligent energy management and operational efficiency, the ATV630D18N4 integrates advanced motor control features, robust protection, and built-in communication protocols, making it ideal for demanding industries such as water treatment, mining, HVAC, and more.
Key Features
-
180 kW (240 HP) rated motor power
-
3-phase 380–480 V AC input voltage
-
Advanced vector control and V/f motor control
-
Integrated EMC filtering for reduced harmonics
-
IP21/NEMA Type 1 enclosure for indoor installation
-
LCD graphical keypad with navigation dial
-
Built-in Ethernet, Modbus TCP, CANopen communication
-
Conformal coating on PCBs for harsh environments
-
Smart thermal and overload protection
-
Energy monitoring and process optimization tools
Technical Specifications
| Item | Specification |
|---|---|
| モデル Number | ATV630D18N4 |
| Series | Altivar Process ATV630 |
| Power Rating | 180 kW (240 HP) |
| Supply Voltage | 380–480 V AC, 3-phase |
| Frequency Range | 50/60 Hz ±5% |
| Output Frequency | 0.1 to 599 Hz |
| Output Current (Nominal) | 361 A |
| Motor Control Type | V/f, Sensorless Vector, Flux Vector |
| Enclosure Rating | IP21 (NEMA Type 1) |
| Communication Protocols | Modbus TCP, Ethernet/IP, CANopen |
| Display Interface | LCD graphical keypad with dial |
| Overload Capacity | 120% for 60 s, 150% for 60 s |
| EMC Filtering | Integrated C3 filter |
| Operating Temperature Range | -15°C to +50°C (no derating) |
| Cooling Method | Forced air |
| Mounting Type | Wall-mounted or enclosed cabinet |
| Dimensions | 211 x 546 x 232mm |
| 重量 | 14.2 kg |
| Certifications | CE, UL, CSA, EAC, RoHS, IEC/EN 61800-5-1 |
Industry Applications
The ATV630D18N4 is ideal for:
-
Municipal water and wastewater systems
-
Industrial pumping and irrigation
-
HVAC and building automation
-
Food and beverage processing
-
Chemical and petrochemical industries
-
Mining, aggregates, and material transport
-
Energy and infrastructure sectors
Advantages
-
High Reliability: Operates efficiently in demanding environments with durable design and thermal protection.
-
Optimized for Fluids: Tailored functions for pump, fan, and compressor control.
-
Energy Efficiency: Built-in monitoring tools help reduce energy consumption.
-
Simple Integration: サポートs major industrial networks with onboard Ethernet and fieldbus protocols.
-
Advanced Diagnostics: Real-time alerts and maintenance tools reduce downtime.
-
Flexible Mounting: Can be installed standalone or inside control panels.
-
User-Friendly: Navigation dial and graphical keypad simplify setup and operation.
-
Compliance & Safety: Certified to global safety and electromagnetic standards.
よくある質問 (FAQ)
-
What motor power is supported by ATV630D18N4?
It supports motors up to 180 kW (240 HP). -
Which communication protocols are supported?
It includes Modbus TCP, Ethernet/IP, and CANopen. -
Can this drive be used in HVAC systems?
Yes, it’s well-suited for HVAC fans, compressors, and chillers. -
Does it have built-in EMC filtering?
Yes, it includes a カテゴリー C3 EMC filter. -
What kind / enclosure does it come with?
It features an IP21/NEMA Type 1 enclosure suitable for indoor environments. -
What is the overload handling capability?
It can handle 150% overload for 60 seconds and 120% for 60 seconds. -
Is the keypad removable?
Yes, the keypad is detachable and supports remote mounting. -
Does it /fer energy monitoring?
Yes, it includes integrated energy consumption and efficiency monitoring features. -
Can it be used in dusty or humid environments?
Yes, conformal coating on PCBs provides extra protection in such environments. -
Is it compatible with existing PLCs?
Yes, thanks to standard communication interfaces, it integrates easily with most automation systems.
Related モデルs
| モデル Number | 説明 |
|---|---|
| ATV630D18N4 | 180 kW, 380–480 V, IP21, Altivar Process VSD |
| ATV630C22N4 | 220 kW, 380–480 V, IP21, Altivar Process VSD |
| ATV630C13N4 | 132 kW, 380–480 V, IP21, Altivar Process VSD |
| ATV630D11N4 | 110 kW, 380–480 V, IP21, Altivar Process VSD |
| ATV630C75N4 | 75 kW, 380–480 V, IP21, Altivar Process VSD |
| ATV630D90N4 | 90 kW, 380–480 V, IP21, Altivar Process VSD |
Popular Schneider Electric モデルs
| モデル Number | 説明 |
|---|---|
| ATV320U75N4B | Altivar Machine 320, 7.5 kW, 380–500 V |
| ATV930C13N4 | Altivar Process 930, 132 kW, advanced performance VSD |
| ATV212HU55N4 | Altivar 212, 55 kW, HVAC-specific drive |
| ATV12H075M2 | Altivar 12, 0.75 kW, compact VSD, single-phase input |
| ATV71HD75N4 | Altivar 71, 75 kW, high-performance drive |
