製品紹介
The Schneider Electric ATV630D15N4 Variable Speed Drive belongs to the Altivar Process ATV600 series and is designed to power three-phase synchronous and asynchronous motors. It focuses on process optimization, energy efficiency, and asset management, making it suitable for demanding industrial environments.
Operating with a rated supply voltage / 380–480 V AC, this drive supports motors up to 15 kW / 20 HP for normal-duty applications and 11 kW / 15 HP for heavy-duty applications. Its built-in Start/Stop energy-saving function enables up to 30% energy savings during standby operation, without the need for additional components or configuration.
The ATV630D15N4 features three integrated RJ45 communication ports, one Ethernet port, and two serial communication ports, allowing seamless integration into modern automation networks. It is optimized for fluid management and energy efficiency, making it highly adaptable across multiple industrial sectors.
製品仕様
| Parameter | Specification |
|---|---|
| モデル Number | ATV630D15N4 |
| Product Series | Altivar Process ATV600 |
| Drive Type | Variable Speed Drive (VFD) |
| Motor Type サポートed | Three-phase synchronous and asynchronous motors |
| Rated Supply Voltage | 380–480 V AC |
| Normal Duty Power Rating | Up to 15 kW / 20 HP |
| Heavy Duty Power Rating | Up to 11 kW / 15 HP |
| Overload Capability (Normal Duty) | Up to 120% |
| Overload Capability (Heavy Duty) | Up to 150% |
| Integrated Communication | 3 × RJ45 ports, Ethernet, 2 × serial ports |
| Installation Type | Vertical wall mounting (±10°) |
| Energy Saving Function | Start/Stop energy optimization |
| Accessories 対応可能 | Fan kits, graphic terminal |
| Optional Modules | I/O expansion modules, communication modules, EMC input filters |
| Dimensions | 546 × 211 × 232 mm |
| 重量 | 13.6 kg |
Applications
• Water Treatment Systems: Optimized control / pumps and motors to improve energy efficiency.
• Wastewater Treatment Plants: サポートs continuous operation with dynamic load management.
• Mining and Minerals Processing: Provides stable speed control for conveyors and processing equipment.
• Oil and Gas Facilities: Ensures reliable motor control in energy-intensive process applications.
• Food and Beverage Production: Enables precise flow and speed regulation in hygienic environments.
• Industrial Fluid Handling: Designed for pumps, fans, and compressors with variable demand.
Advantages
• High Energy Efficiency: Start/Stop function reduces standby energy consumption by up to 30%.
• Advanced Network Integration: Built-in Ethernet and multiple RJ45 ports simplify system connectivity.
• Flexible Power Range: サポートs both normal-duty and heavy-duty motor applications.
• Process-Oriented Design: Enhances overall process performance and operational stability.
• Expandable Architecture: サポートs accessories and optional expansion modules.
• Lower Total Cost / Ownership: Reduces energy costs and improves asset utilization.
