The Schneider Electric ABE7R16T111 is a high-performance relay sub-base module designed for use in modular industrial control systems. Part / the Telemecanique Sensors ABE7 range, this model supports 16 channels and is equipped to host plug-in electromechanical relays, /fering an efficient and field-serviceable solution for automation and control.
Designed to interface between the control logic (such as a PLC or remote I/O) and field devices, the ABE7R16T111 allows operators to handle switching loads reliably through a centralized relay base. With its screw terminal connections and DIN rail mounting, this model is particularly favored in environments where ease / wiring, fast relay replacement, and robust electrical performance are required.
Ideal for complex and high-density control panels, the ABE7R16T111 significantly reduces wiring clutter, minimizes downtime, and ensures long-term reliability in harsh industrial environments.
製品仕様
| Parameter | Details |
|---|---|
| Product Name | Schneider Electric ABE7R16T111 |
| Product Type | Relay Sub-Base with Plug-In Relays |
| Series | ABE7 Remote I/O Interface |
| Relay Type サポートed | RXM Series (Plug-In Miniature Relays) |
| Number / Channels | 16 |
| Connection Type | Screw Terminal |
| Relay Mounting | Plug-In |
| Rated Control Voltage | 24 V DC |
| お問い合わせ Configuration | SPDT (Single Pole Double Throw) via relay |
| Mounting Type | DIN Rail 35 mm |
| Material | Flame-retardant thermoplastic housing |
| Insulation Resistance | ≥ 100 MΩ at 500 V DC |
| Operating Temperature | -5°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Shock Resistance | 15 g (11 ms duration) |
| Vibration Resistance | 2 g (10–150 Hz) |
| IP Degree / Protection | IP20 |
| Standards Compliance | IEC 60947-5-1, UL, CSA |
| RoHS Compliant | Yes |
| Dimensions (W x H x D) | 110 x 63 x 89 mm |
| 重量 | 0.6 kg |
Product Applications
The Schneider ABE7R16T111 is engineered to serve as a versatile I/O relay interface in a wide range / industrial control applications:
-
PLC Output Extension: Acts as an intermediary relay output module between a PLC and actuators.
-
Machine Automation: Facilitates signal routing for motors, valves, solenoids, and sensors.
-
Process Control Systems: Used in distributed systems for batch and continuous processes.
-
Building Automation: サポートs lighting, HVAC, and safety relay interfacing.
-
Material Handling Equipment: Controls conveyors, packaging machines, and robotic arms.
-
Energy Management and Monitoring: Integrates with power meters and smart panels.
Product Advantages
-
Modular and Serviceable Design: Plug-in relay slots enable fast replacement without rewiring.
-
Durability in Harsh 状態s: Engineered to handle industrial-grade shock, vibration, and thermal variations.
-
Simplified Installation: Standard DIN rail mount and clear terminal labeling reduce setup time.
-
Time-Saving Maintenance: No need to remove wires when servicing relays.
-
High Channel Density: サポートs 16 channels in one compact module, ideal for space-constrained panels.
-
Reliable Connections: Screw terminals provide secure and vibration-resistant wiring.
-
Standards-Compliant: Meets global safety and quality certifications.
-
Expandable Architecture: Compatible with Schneider’s full ABE7 interface system for scalable projects.
よくある質問 (FAQ)
-
Q: What relay series is compatible with the ABE7R16T111?
A: It is designed for RXM plug-in miniature relays from Schneider Electric. -
Q: Does the product come with relays pre-installed?
A: No, relays are ordered separately and plugged into the base during installation. -
Q: Can it be mounted in any orientation?
A: It should be mounted vertically on a 35 mm DIN rail to ensure optimal cooling and function. -
Q: What is the difference between ABE7R16T111 and ABE7R16S111?
A: The “T” version uses plug-in relays with screw terminals; the “S” version has soldered relay connections. -
Q: Is it suitable for 230V AC loads?
A: The sub-base itself operates at 24V DC; however, the relay contacts may switch higher voltages depending on the relay used. -
Q: Can relays be replaced without removing wires?
A: Yes, the plug-in design allows relay replacement without disturbing terminal wiring. -
Q: Is it RoHS and CE certified?
A: Yes, it complies with RoHS directives and CE marking. -
Q: What protection is provided against vibration?
A: It meets industrial vibration standards up to 2g (10–150 Hz). -
Q: What kind / screw terminals are used?
A: It uses cage clamp screw terminals for secure and easy wiring. -
Q: Is this product UL certified for North American use?
A: Yes, it has UL and CSA certifications for use in North America.
