製品紹介
The Schneider ABE7CPA02 is a high-performance connection sub-base designed for interfacing discrete input/output modules with field wiring in industrial automation environments. As part / the Telemecanique ABE7 series, this sub-base provides a compact, durable, and organized solution for simplifying wiring and ensuring consistent connectivity across programmable logic controllers (PLCs) and peripheral devices.
Engineered for ease / integration, the ABE7CPA02 /fers screw terminal connections for solid reliability and quick setup. It is compatible with a wide range / Schneider Electric I/O modules and is ideal for use in control cabinets and distributed I/O systems. Its robust construction makes it suitable for harsh industrial conditions, delivering exceptional mechanical strength and insulation properties.
製品仕様
| Parameter | Specification |
|---|---|
| Product Name | ABE7CPA02 |
| Series | Telemecanique ABE7 |
| Product Type | Connection Sub-Base |
| Connector Type | Screw terminal block |
| Number / Channels | 8 |
| Mounting Type | DIN rail |
| Compatibility | Compatible with discrete input modules |
| Insulation Resistance | >100 MΩ at 500 V DC |
| Maximum Voltage | 250 V AC or 60 V DC |
| Maximum Current per Channel | 2 A |
| Material | High-impact thermoplastic housing |
| IP Rating | IP20 |
| Operating Temperature | -5°C to +60°C |
| Storage Temperature | -40°C to +70°C |
| Dimensions (W x H x D) | 125 x 70 x 67 mm |
| 重量 | 0.29 kg |
| Certifications | CE, UL, CSA |
| RoHS Compliant | Yes |
Applications
The Schneider ABE7CPA02 connection sub-base is suitable for a wide variety / industrial and automation applications, including:
-
Manufacturing Automation
Facilitates efficient wiring between I/O modules and machine-level sensors or actuators. -
Process Control Systems
サポートs reliable signal interfacing in refineries, chemical plants, and food processing 台s. -
Building Automation
Enables easy integration / control components in HVAC and lighting control panels. -
Material Handling Systems
Used for control interfacing in conveyor systems, sorters, and robotic arms. -
Water Treatment Plants
Connects control modules to sensors and relays for monitoring flow, pressure, and chemical levels. -
Packaging and Assembly Lines
Simplifies wiring infrastructure for highly repetitive I/O configurations.
Product Advantages
-
Compact Design: Takes up minimal panel space, allowing for dense installation / multiple sub-bases.
-
Simplified Wiring: Screw terminals enable quick and secure wiring without the need for special tools.
-
High Compatibility: Fully compatible with Schneider discrete input modules, ensuring seamless integration.
-
DIN Rail Mounting: Easy and standardized installation on 35 mm DIN rails.
-
Robust Construction: Resistant to mechanical impact and suitable for industrial-grade environments.
-
Clear Channel Identification: Marked terminals ensure clarity during wiring, reducing errors.
-
Field-Friendly Design: Designed with field wiring challenges in mind—accessible, organized, and reliable.
-
Electrical Safety: IP20 rated and CE/UL compliant to ensure operator and equipment protection.
-
RoHS Compliant: Environmentally friendly and free from hazardous materials.
-
Cost-Effective: Provides reliable performance at an affordable price, minimizing control system costs.
よくある質問 (FAQ)
-
Q: What type / I/O modules is the ABE7CPA02 compatible with?
A: It is designed to work with Schneider discrete input modules from the ABE7 series. -
Q: How many channels does the ABE7CPA02 support?
A: The sub-base supports 8 channels for field connections. -
Q: Can this sub-base be mounted on a DIN rail?
A: Yes, it is DIN rail mountable for easy installation. -
Q: What is the IP rating / this product?
A: The ABE7CPA02 has an IP20 protection rating. -
Q: What type / terminal does it use?
A: It uses screw terminal connections for secure and easy wiring. -
Q: What are the dimensions / the ABE7CPA02?
A: 125 x 70 x 67 mm. -
Q: What is the operating temperature range?
A: It operates between -5°C and +60°C. -
Q: Is it RoHS compliant?
A: Yes, it is fully RoHS compliant. -
Q: What is the maximum current per channel?
A: Each channel can handle up to 2 A / current. -
Q: Is it certified for international use?
A: Yes, it is CE, UL, and CSA certified for global compliance.
Related ABE7 Series モデルs
| モデル | 説明 | Channels | Connector Type | Mounting |
|---|---|---|---|---|
| ABE7CPA03 | Connection sub-base with 12 channels | 12 | Screw terminals | DIN rail |
| ABE7CPA04 | Sub-base for analog modules | 8 | Screw terminals | DIN rail |
| ABE7CPA31 | Pre-wired sub-base with removable terminal | 8 | Removable terminal | DIN rail |
| ABE7CPS400 | Connection base for solid-state output modules | 8 | Spring terminals | DIN rail |
| ABE7CPA220 | High-voltage compatible sub-base | 8 | Screw terminals | DIN rail |
| ABE7CPA02U | Universal variant / ABE7CPA02 | 8 | Screw terminals | DIN rail |
Popular Schneider Electric モデルs
| モデル | 説明 | Series | Function | Mounting |
|---|---|---|---|---|
| TM221CE16R | Modicon M221 Logic Controller | Modicon M221 | PLC Controller | DIN rail |
| BMXDDO1602 | Discrete Output Module (16-channel) | Modicon X80 | Digital Output | Rack mount |
| ATV320U22N4B | Variable Speed Drive (2.2 kW) | Altivar 320 | Motor Drive | Panel Mount |
| ZB5AA2 | Pushbutton Head – Green | Harmony XB5 | Human-Machine Interface | Panel Mount |
| NSX100F | Compact NSX Circuit Breaker | Compact NSX | Circuit Protection | Panel Mount |
| XB4BD33 | Double Pushbutton – Black/White | Harmony XB4 | Control Interface | Panel Mount |
