製品紹介
The Schneider Electric 140NOE77110 is a high-performance Ethernet communication module designed for the Modicon Quantum automation platform. It provides deterministic, high-speed Ethernet communications for critical industrial automation systems and supports open protocols such as Modbus TCP/IP. This module is engineered to ensure seamless integration between programmable logic controllers (PLCs), human-machine interfaces (HMIs), SCADA systems, and IT-level networks.
What distinguishes the 140NOE77110 is its support for advanced communication features such as web-based diagnostics, SNMP, and global data sharing. It serves as a key element in establishing secure, real-time control network architectures where performance, reliability, and accessibility are non-negotiable.
This module is especially well-suited for process automation, infrastructure, utilities, and manufacturing environments where scalability, availability, and remote management are essential.
製品仕様
| Parameter | Details |
|---|---|
| Product Type | Ethernet Communication Module |
| モデル Number | 140NOE77110 |
| メーカー | Schneider Electric |
| Product Family | Modicon Quantum |
| Communication Protocol | Ethernet TCP/IP, Modbus TCP, SNMP |
| Interface Type | RJ45 (10BASE-T/100BASE-TX) |
| Data Rate | 10/100 Mbps auto-sensing |
| サポートed Services | Modbus TCP/IP, Global Data, Web Server, SNMP |
| Backplane Current Consumption | 600 mA at 5 VDC |
| Operating Voltage | Supplied from Quantum rack backplane |
| Web Server サポート | Yes |
| Configuration Tool | ユニットy Pro, EcoStruxure Control Expert |
| Diagnostics | Embedded web diagnostics, SNMP traps |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity | 5% to 95% non-condensing |
| Shock Resistance | 30 g |
| EMC Compliance | IEC 61000-6-2, IEC 61000-6-4 |
| Mounting Type | Plug-in to Quantum rack |
| Dimensions (H x W x D) | 103.9 × 40.3 × 250 mm |
| 重量 | 0.345 kg |
| Firmware Upgradable | Yes, via Schneider tools |
Product Applications
The 140NOE77110 is used extensively in industries that require seamless, secure, and real-time communication over Ethernet. It is ideal for:
-
Process Automation: Integrating large-scale distributed control systems (DCS).
-
Water & Wastewater: Centralized data acquisition from treatment facilities.
-
Energy & Utilities: Power generation and distribution monitoring systems.
-
Oil & Gas: Real-time diagnostics and control / drilling and refining processes.
-
Manufacturing & Assembly Lines: Machine-to-machine communication and MES integration.
-
Transport & Infrastructure: Remote control and monitoring / railway and road systems.
Product Advantages
-
Reliable High-Speed Ethernet
Ensures deterministic communication with support for 10/100 Mbps networks. -
Robust Protocol サポート
サポートs Modbus TCP/IP, SNMP, and web diagnostics for flexible data exchange and monitoring. -
Embedded Web Server
Provides remote diagnostics and device status visibility without additional s/tware. -
Scalable System Integration
Works seamlessly with SCADA, HMI, and PLCs for system-wide connectivity. -
Plug-and-Play Compatibility
Designed for native integration with Modicon Quantum racks and s/tware environments. -
Secure and Remote Monitoring
Reduces maintenance costs and downtime through remote access and SNMP traps. -
High Environmental Resistance
Built to withstand industrial environments with temperature and EMC compliance.
よくある質問 (FAQ)
1. What type / Ethernet protocols does the 140NOE77110 module support?
The module supports Ethernet TCP/IP, Modbus TCP, and SNMP protocols. These enable communication with PLCs, SCADA systems, and network management tools.
2. Is the module equipped with a built-in web server for diagnostics?
Yes, it includes an embedded web server that allows users to view diagnostic information, communication statistics, and status through a standard web browser.
3. Can the 140NOE77110 be used for remote monitoring?
Absolutely. It supports SNMP and web access, which enables remote diagnostics and monitoring without requiring on-site access.
4. Which s/tware is required to configure this module?
The module can be configured using Schneider Electric’s ユニットy Pro or EcoStruxure Control Expert s/tware suites.
5. How do I physically install the 140NOE77110 module?
It is a plug-in module that mounts into any available slot in a Modicon Quantum rack. No additional wiring is required beyond network cabling.
6. What kind / data transmission speed does it support?
The module supports auto-sensing Ethernet speeds / 10 Mbps and 100 Mbps over an RJ45 connection.
7. Is this module suitable for critical industrial environments?
Yes. It complies with IEC standards for electromagnetic compatibility and operates in a wide industrial temperature range, making it ideal for demanding environments.
8. What diagnostics features are available on this module?
It provides built-in diagnostic tools accessible through the web interface, including link status, error counters, and network traffic monitoring.
9. How is the module powered when installed in a system?
Power is supplied via the Quantum rack backplane. The module consumes approximately 600 mA at 5 VDC.
10. Can the module be used to transfer data between multiple PLCs?
Yes, using its global data support and Modbus TCP/IP capabilities, it allows for real-time data exchange between multiple Quantum CPUs or third-party Ethernet-compatible devices.
Related モデルs from the Same Series
| モデル Number | 説明 | Communication | Key Feature |
|---|---|---|---|
| 140NOE77101 | Ethernet TCP/IP Module | Ethernet 10/100 Mbps | Basic web access and Modbus TCP |
| 140CPU65160 | Quantum CPU with Ethernet | Modbus TCP, Ethernet | High-performance PLC |
| 140CPS11420 | Power Supply Module | N/A | Quantum system power |
| 140CRP93100 | Remote I/O Head Module | RIO | Remote I/O networking |
| 140CHS11000 | Rack for Quantum Modules | N/A | Module installation base |
| 140DDO35300 | Discrete Output Module | N/A | Digital output expansion |
Popular モデルs from Schneider Electric
| モデル Number | 説明 | Application | Product Family |
|---|---|---|---|
| TM241CE40T | Compact PLC with Ethernet | Machine control | Modicon M241 |
| BMXNOE0100 | Ethernet Comm Module for M340 | Ethernet communication | Modicon M340 |
| TSXETY5103 | Ethernet TCP/IP Module | Factory network management | Modicon Premium |
| HMIGTO5310 | Touchscreen HMI 10″ | Operator interface | Magelis HMI |
| ATV630D22N4 | Variable Speed Drive | Motor control and energy savings | Altivar Process |
| LXM32MU60N4 | Servo Drive | High-precision motion control | Lexium 32 |
