Product Overview – Schneider Electric 140MMD10200
The Schneider Electric 140MMD10200 is a high-performance motion control module designed for use in the Modicon Quantum automation platform. This module enables precise control / motion systems, supporting multi-axis control and /fering deterministic and synchronized performance suitable for demanding industrial automation applications. Integrated with advanced diagnostics and real-time processing capability, the 140MMD10200 is ideal for manufacturing processes that require accuracy, speed, and robust data communication.
The 140MMD10200 is engineered to communicate with servo drives, stepper motors, and other motion devices over a deterministic network, typically via SERCOS or other compatible industrial fieldbus protocols. It integrates seamlessly with ユニットy Pro or EcoStruxure Control Expert s/tware, ensuring easy configuration and commissioning.
Technical Specifications – Schneider 140MMD10200
| Parameter | 説明 |
|---|---|
| Product Type | Motion Control Module |
| Series | Modicon Quantum |
| 型番 | 140MMD10200 |
| Function | Multi-axis motion controller |
| Bus Type | Quantum backplane |
| サポートed Axes | Up to 2 synchronized motion axes |
| Communication Protocol | Typically SERCOS or equivalent |
| Update Time | ≤1 ms (for deterministic synchronization) |
| Programming S/tware | ユニットy Pro / EcoStruxure Control Expert |
| Power Supply | From Quantum backplane (5 VDC nominal) |
| Current Consumption | 850 mA at 5 VDC |
| Diagnostics | Embedded real-time fault and status reporting |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity Tolerance | 5% to 95% non-condensing |
| Mounting | Rack-mounted in Quantum main chassis |
| Dimensions | 127 × 127 × 51 mm |
| 重量 | 2.3 kg |
Product Applications
The Schneider 140MMD10200 is used in automation systems requiring coordinated and precise motion control. Key application domains include:
-
Robotics and Material Handling: Precise synchronization / axes in pick-and-place operations.
-
Packaging Machines: High-speed, high-accuracy motion for sealing, cutting, and boxing.
-
Printing and Converting Lines: Tight tolerance motion for web tension control.
-
CNC and Machining Centers: Interpolated axis control for tool movement.
-
Automotive Assembly Lines: Precise conveyor and robot coordination.
-
Semiconductor Equipment: Clean motion control for wafer processing.
Product Advantages
-
Deterministic Control
サポートs high-speed synchronized motion using dedicated motion networks with real-time control loop updates. -
Seamless Integration
Works natively with Modicon Quantum architecture and Schneider’s automation s/tware. -
Diagnostic Capabilities
Offers real-time status, fault monitoring, and recovery feedback for minimal downtime. -
Flexibility
Programmable with ユニットy Pro/EcoStruxure Control Expert, supporting various motion pr/iles and user-defined logic. -
Scalability
Suitable for systems with 1 to 2 axes now, with upgrade paths using coordinated modules for larger installations. -
Proven Stability
Designed for 24/7 industrial environments with rigorous performance testing.
よくある質問 (FAQ)
Q1: What type / motors can be controlled with the 140MMD10200?
A1: It can control servo and stepper motors compatible with the supported motion bus (typically SERCOS).
Q2: How many axes are supported?
A2: The module supports up to two synchronized motion axes.
Q3: Does it support closed-loop control?
A3: Yes, it supports both open-loop and closed-loop (feedback-based) motion control.
Q4: What s/tware is required for configuration?
A4: ユニットy Pro or EcoStruxure Control Expert is used for programming and setup.
Q5: Can it be used in high-vibration environments?
A5: Yes, it meets industrial standards for vibration and temperature.
Q6: Is this module hot-swappable?
A6: No, it requires the system to be powered down before insertion or removal.
Q7: Does it require an external power supply?
A7: No, it draws power directly from the Quantum backplane.
Q8: Is the firmware upgradeable?
A8: Yes, firmware updates can be done via s/tware tools provided by Schneider.
Q9: Can the module detect motion faults?
A9: Yes, it includes fault detection features like over-speed, following error, and encoder fault.
Q10: What is the installation position?
A10: The module must be installed vertically in a standard Modicon Quantum rack.
Recommended Related モデルs (Same Series / Functionality)
| モデル Number | 説明 |
|---|---|
| 140MMD10100 | Motion controller module, 1-axis |
| 140MMD20200 | Motion controller module, 2-axis, SERCOS |
| 140CPU67160 | Quantum CPU for motion coordination |
| 140DDO35300 | Digital Output Module – 32 pts |
| 140DAI55300 | Analog Input Module – 16 pts |
| 140DDI84100 | Digital Input Module – 32 pts |
Popular モデルs from Schneider Electric (Same ブランド)
| モデル Number | 説明 |
|---|---|
| BMXDDO1602 | Modicon X80 Digital Output Module |
| BMXDRA0815 | Modicon X80 Relay Output Module |
| TSXDEY64D2K | Discrete Input Module |
| 140CPU65160 | Quantum Series High-Performance CPU |
| BMEP584040 | Modicon M580 PAC Processor |
| BMXPRA0100 | Communication Adapter for Remote I/O |
