製品紹介
The Schneider Electric 140CPS52400 is a robust and high-capacity Power Supply Module engineered for the Modicon Quantum series / programmable logic controllers (PLCs). Designed to convert and deliver a stable 5 VDC regulated output from a 24 VDC input source, this module powers the Quantum PLC backplane and its associated CPU, I/O, and communication modules.
With a strong 11 A output capacity, this module is ideally suited for large-scale, high-density control systems. The 140CPS52400 ensures power continuity, electrical protection, and operational efficiency, all while complying with stringent industrial safety and environmental standards.
Built with rugged components for continuous duty in challenging environments, this power module is commonly used across energy, petrochemical, transportation, water treatment, and industrial automation sectors. It /fers natural convection cooling, integrated diagnostics, and LED indicators, ensuring quick monitoring and simplified maintenance.
製品仕様
| Parameter | Specification |
|---|---|
| モデル Number | 140CPS52400 |
| メーカー | Schneider Electric |
| Product Type | Power Supply Module |
| Platform | Modicon Quantum PLC |
| Input Voltage | 24 VDC |
| Input Voltage Range | 19 to 30 VDC |
| Input Current | Up to 6.5 A |
| Output Voltage | Regulated 5 VDC |
| Output Current | Up to 11 A |
| Power Output Capacity | Approx. 55 W |
| Cooling Method | Natural convection |
| Redundancy サポート | No (used in standalone configurations) |
| LED Indicators | Power OK, Status, Fault |
| Protection Features | Overload, overvoltage, short circuit, and thermal shutdown |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Tolerance | 5% to 95% non-condensing |
| Certifications | CE, UL, CSA, ATEX, IEC |
| Mounting Type | Rack-mounted (Modicon Quantum chassis) |
| Dimensions (W x H x D) | 103.9 × 40.3 × 250 mm |
| 重量 | 0.65 kg |
| Backplane Compatibility | All standard Modicon Quantum racks |
Applications
The 140CPS52400 Power Supply Module is designed for systems that require large current delivery and stable performance under continuous loads. It’s widely used in:
-
Oil & Gas Refineries
Supplies PLCs controlling burner management systems, pumps, and emergency shutdowns. -
Electric Power Generation Plants
Powers the control racks used in turbines, substations, and boiler systems. -
Municipal Water Treatment
サポートs SCADA-connected controllers managing filtration, chemical dosing, and pump operations. -
Transportation Systems
Ideal for use in railway signal control, airport automation, and intelligent traffic systems. -
Food & Beverage Processing
Provides stable, regulated power for critical processing, batching, and packaging equipment. -
Automotive Assembly Lines
Delivers high output to support I/O-dense racks in robotic and conveyor control.
Product Advantages
-
High Current Output (11 A)
サポートs high-density Quantum PLC configurations without requiring additional power supplies. -
Industrial-Grade Build Quality
Engineered for reliability in electrically noisy, high-vibration, or thermally variable environments. -
Protection Against Electrical Faults
Prevents system failures with overload, short-circuit, and overheat protections. -
Simple Integration with Quantum Racks
Rack-mounted form factor ensures seamless mechanical and electrical integration. -
Visual Diagnostics via LED
On-module LEDs provide clear status, operational, and fault indicators for quick diagnostics. -
Natural Cooling Mechanism
No fans required, reducing the risk / mechanical failure and simplifying maintenance. -
Schneider Reliability
サポートed by Schneider Electric’s extensive service network and long product lifecycle policies.
よくある質問 (FAQ)
-
What is the main function / the 140CPS52400?
It provides regulated 5 VDC at up to 11 A for Quantum PLC backplane modules from a 24 VDC input. -
Is it compatible with all Quantum racks?
Yes, it works with both standard and extended Modicon Quantum chassis. -
Can this power supply be used in a redundant configuration?
No, it’s designed for standalone configurations. For redundancy, use models like 140CPS12420C. -
What is the maximum power output?
The module can output approximately 55 W / power (5 VDC at 11 A). -
What environmental conditions can it operate in?
It operates between 0°C and +60°C with up to 95% non-condensing humidity. -
Is the module hot-swappable?
No, it must be installed or removed when the system is powered down to avoid damage. -
What protection features does it have?
It includes thermal shutdown, overvoltage, overload, and short-circuit protection. -
Does it require forced air cooling?
No, it relies on passive natural convection, which increases reliability. -
How can I monitor its status?
The module includes front-facing LED indicators for Power OK, Status, and Fault conditions. -
What industries typically use this module?
It’s commonly used in energy, oil & gas, water treatment, and manufacturing sectors.
Related or Compatible モデルs (Same Series)
| モデル | 説明 | Input Voltage | Output Current | Redundancy | Compatibility |
|---|---|---|---|---|---|
| 140CPS12420C | High-output DC power supply | 24 VDC | 8 A | Yes | Modicon Quantum |
| 140CPS11100 | AC input power supply module | 115/230 VAC | 5 A | No | Modicon Quantum |
| 140CPS11420 | Standard DC power supply | 24 VDC | 8 A | No | Modicon Quantum |
| 140CPS22400 | Universal input power supply | 24–125 VDC/AC | 8 A | Yes | Modicon Quantum |
| 140CPS21400 | Redundant AC power supply | 115/230 VAC | 5 A | Yes | Modicon Quantum |
| 140CPS51100C | Standard AC input, compact model | 115/230 VAC | 5 A | No | Modicon Quantum |
Popular Schneider Electric モデルs
| モデル | Type | Function | Platform |
|---|---|---|---|
| BMEP582040 | ePAC CPU Module | High-speed processor for advanced control | Modicon M580 |
| TM241CE40T | Logic Controller | Integrated PLC with Ethernet and I/O | Modicon M241 |
| BMXP342020 | CPU Module | Handles logic, I/O, and comms for medium apps | Modicon M340 |
| BMXAMO0410 | Analog Output Module | 4-channel analog output for process control | Modicon M340 |
| TSXDEY64D2K | Digital Input Module | 64-channel 24 VDC input, high-density | Modicon Premium |
| ABL8RPS24100 | DIN Rail Power Supply | 24 VDC regulated power supply for control panels | Universal Industrial Use |
