製品紹介
The Honeywell TC-RPSC03 is a high-performance pressure sensor designed for industrial and commercial applications. It provides accurate and reliable pressure measurement, making it suitable for demanding environments such as HVAC systems, hydraulic systems, and process control. Built with robust materials, this sensor ensures long-term durability and precise readings under varying conditions.
製品仕様
| Parameter | Value |
|---|---|
| モデル | Honeywell TC-RPSC03 |
| Pressure Range | 0–100 psi (adjustable range) |
| Accuracy | ±0.5% Full Scale |
| Output Signal | 4–20 mA, 0–5 VDC, 0–10 VDC |
| Power Supply | 12–30 VDC |
| Operating Temperature | -40°C to +85°C (-40°F to +185°F) |
| Electrical Connection | 5-pin M12 connector |
| Housing Material | Stainless Steel |
| Protection Rating | IP67 |
| Dimensions | 22 x 124 x 126 mm |
| 重量 | 0.1 kg |
| Media Compatibility | Air, Water, Hydraulic Fluids |
| Long-Term Stability | ≤±0.2% FS/year |
Product Applications
The Honeywell TC-RPSC03 is widely used in industries requiring precise pressure monitoring, including:
-
HVAC Systems – Ensures optimal pressure control in heating and cooling systems.
-
Industrial Automation – Integrates with PLCs for real-time pressure feedback.
-
Hydraulic & Pneumatic Systems – Monitors fluid pressure to prevent system failures.
-
Water Treatment Plants – Measures pump and pipeline pressure for efficient operations.
-
Oil & Gas – Used in pipelines and refineries for safe pressure management.
Product Advantages
-
High Accuracy – Delivers precise measurements with minimal deviation.
-
Robust Construction – Stainless steel housing resists corrosion and mechanical stress.
-
Wide Operating Range – Functions reliably in extreme temperatures.
-
Multiple Output Options – Compatible with analog and digital control systems.
-
Easy Installation – Compact design and standard M12 connector simplify setup.
-
Long-Term Stability – Minimal drift ensures consistent performance over time.
よくある質問 (FAQ)
1. What is the pressure range / the TC-RPSC03?
The standard range is 0–100 psi, but custom ranges are available upon request.
2. Can this sensor measure both gas and liquid pressures?
Yes, it is compatible with air, water, and most non-corrosive hydraulic fluids.
3. What is the operating voltage?
The sensor requires a 12–30 VDC power supply.
4. Is the TC-RPSC03 suitable for outdoor use?
Yes, its IP67 rating ensures protection against dust and water ingress.
5. How do I calibrate the sensor?
Calibration requires a reference pressure source and adjustment via the signal output.
6. What is the expected lifespan / this sensor?
With proper maintenance, it can last over 10 years in typical industrial conditions.
7. Does it support digital communication protocols?
No, it provides analog outputs (4–20 mA, 0–5/10 VDC) only.
8. Can it withstand high-vibration environments?
Yes, its rugged design ensures stable performance in high-vibration applications.
9. What is the response time / the sensor?
Less than 5 milliseconds for most pressure changes.
10. How long is the warranty period?
The standard warranty is 1 years, subject to proper usage and conditions.
Recommended Related & Popular モデルs
Same Series / Related モデルs
| モデル | Key Feature | Pressure Range | Output |
|---|---|---|---|
| TC-RPSC01 | Basic analog output | 0–50 psi | 0–5 VDC |
| TC-RPSC05 | High-pressure variant | 0–500 psi | 4–20 mA |
| TC-RPSC10 | Digital output (RS485) | 0–200 psi | Modbus RTU |
| TC-RPSC15 | Submersible design | 0–100 psi | 4–20 mA |
| TC-RPSC20 | Explosion-pro/ certification | 0–300 psi | 0–10 VDC |
| TC-RPSC25 | Ultra-compact size | 0–30 psi | 0–5 VDC |
Popular Honeywell Pressure Sensors
| モデル | Key Feature | Pressure Range | Output |
|---|---|---|---|
| HSC Series | High-accuracy, digital interface | 0–150 psi | I2C/SPI |
| PPT Series | Industrial-grade, high durability | 0–1000 psi | 4–20 mA |
| 26PCB Series | Miniature board-mount sensor | 0–15 psi | Analog Voltage |
| TSC Series | Temperature-compensated precision | 0–200 psi | 0.5–4.5 VDC |
| MLH Series | Medical & low-pressure applications | 0–5 psi | Analog/Digital |
| ASDX Series | OEM-optimized, cost-effective | 0–60 psi | 4–20 mA |
