製品紹介
The Honeywell MU-PAIH02 51304489-100 High-Level Analog Input Module is a critical component / Honeywell’s TDC 3000 and TPS (TotalPlant Solution) Distributed Control Systems (DCS). Designed to interface with high-level analog signals from process field devices, the MU-PAIH02 /fers reliable, accurate, and noise-resistant input acquisition for control and monitoring functions in mission-critical environments.
As part / the Process Manager family, the MU-PAIH02 is engineered to handle analog inputs such as 4–20 mA and 1–5 V signals, typically originating from sensors, transmitters, and analyzers. With Honeywell’s signature emphasis on fault tolerance and diagnostic capability, this module supports advanced signal processing, system diagnostics, and integration with fault-tolerant I/O backplanes for maximum availability in continuous process industries.
製品仕様
| Parameter | 説明 |
|---|---|
| モデル Number | MU-PAIH02 |
| 型番 | 51304489-100 |
| Product Type | High-Level Analog Input Module |
| System Compatibility | TDC 3000 / TPS / Experion |
| Channels | 16 isolated analog input channels |
| Input Signal Types | 4–20 mA, 0–20 mA, 1–5 V, 0–5 V |
| Input Impedance | ≥ 250 Ohm for current, ≥ 1 MOhm for voltage |
| Resolution | 12-bit (typical), with digital filtering |
| Update Rate | 1 scan per channel every 500 ms |
| Accuracy | ±0.1% / span at 25°C |
| Isolation | Channel-to-channel and channel-to-ground isolation |
| Diagnostics | Signal loss, open loop detection, range check |
| Redundancy サポート | Yes, in fault-tolerant I/O chassis |
| Mounting Type | IOTA (I/O Terminal Assembly), backplane-mounted |
| Power Consumption | ≤ 7.5 W |
| Hot Swap Capability | サポートed when used with redundant architecture |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% RH (non-condensing) |
| Ingress Protection | IP20 (cabinet installation recommended) |
| Compliance | CE, UL, CSA, RoHS |
| Dimensions (H x W x D) | 250 x 30 x 175 mm |
| 重量 | 1.1 kg |
Product Applications
-
Chemical and Petrochemical Plants: For acquiring signals from pressure, level, temperature, and flow transmitters.
-
Power Generation Facilities: To collect analog data from turbine sensors, control valves, and process monitors.
-
Oil & Gas Refineries: Interfaces with field instruments for processing 台s, pipelines, and tank farms.
-
Pharmaceutical Manufacturing: Integrates analog signals from lab analyzers and batch control equipment.
-
Food & Beverage Automation: Acquires analog inputs in dosing, blending, and process verification stages.
-
Water Treatment Plants: Reads analog data from flow meters, pH sensors, and pressure transducers.
Product Advantages
-
High Channel Density: 16 analog inputs per module reduce system footprint and cost per point.
-
Multi-Signal Compatibility: サポートs both voltage and current signal types, simplifying inventory.
-
Enhanced Diagnostics: Built-in open loop detection, range validation, and module health status feedback.
-
Redundancy Ready: Integrates seamlessly into fault-tolerant I/O chassis to ensure zero downtime.
-
Accurate and Stable Readings: High precision even under varying load and temperature conditions.
-
Simplified Maintenance: Hot-swappable design reduces the need for system shutdowns during servicing.
-
Reliable Isolation: Galvanic isolation prevents ground loops and protects sensitive control circuits.
FAQ
-
What types / analog signals are supported by the MU-PAIH02 module?
The module supports 4–20 mA, 0–20 mA, 1–5 V, and 0–5 V input signal types. -
Is there electrical isolation between channels?
Yes, each channel is individually isolated to prevent cross-talk and ground loop interference. -
Can the module detect a broken sensor loop?
Yes, it has built-in diagnostics for open loop and out-/-range conditions. -
What is the resolution / each analog input?
The input resolution is typically 12-bit, providing fine signal granularity for control purposes. -
Does the module support HART communication?
No, MU-PAIH02 is designed for standard analog signals and does not natively support HART protocol. -
Can the module be replaced while the system is powered?
Yes, hot-swap is supported when used in a redundant or fault-tolerant I/O chassis. -
How frequently does the module update input values?
Input channels are typically scanned every 500 milliseconds. -
Is the module suitable for safety-critical systems?
It can be used in high-reliability environments, but safety integrity level (SIL) must be validated at the system level. -
Does the module require external power?
No, power is supplied through the IOTA/backplane connection. -
Can multiple MU-PAIH02 modules be used in a single system?
Yes, multiple modules can be installed to scale analog input capacity as required.
Related モデルs from the Same Series or カテゴリー
| モデル Number | 説明 | Channels | Signal Type | Notes |
|---|---|---|---|---|
| MU-PAIH03 | High-Density Analog Input Module | 32 | 4–20 mA | Higher channel count version |
| MU-PAIH01 | Analog Input Module | 16 | 1–5 V | Voltage-focused version |
| MU-PAIH04 | Universal Analog Input Module | 16 | mA/RTD/TC | Multi-signal support |
| MU-PAOH02 | Analog Output Module | 8 | 4–20 mA | For control signal output |
| MU-TDIO02 | Digital Input/Output Module | 32 | DI/DO | Often used in conjunction |
| MU-PAIN02 | Isolated Analog Input Module | 16 | 4–20 mA | Enhanced isolation and diagnostics |
Popular Honeywell モデルs in Automation Systems
| モデル Number | 説明 | System Compatibility | Function |
|---|---|---|---|
| CC-PAIH01 | Analog Input Module | Experion PKS | 16-channel AI, HART-enabled |
| MC-TAMR03 | AM Redundant Controller | TDC 3000 | Redundant control processor |
| CC-TDIL01 | Digital Input Module | ControlEdge / Experion | 24VDC DI module with diagnostics |
| CC-PAOH01 | Analog Output Module | Experion PKS | 16-channel AO module |
| 51204162-175 | Power Supply Module | TDC 3000 | Provides regulated power for I/O |
| 51309204-175 | IOTA for Analog Input | TDC 3000 | Field terminal interface for MU-PAIH02 |
