製品紹介
The Honeywell FS-TSHART-1620m is an Analog Input Field Termination Assembly (FTA) specifically designed for use with Honeywell’s Safety Manager and Fail Safe Controller (FSC) systems. This module provides the physical interface between field devices and the safety system’s analog input modules. It is a critical component in ensuring accurate and secure analog signal transmission from process instruments such as pressure transmitters, temperature sensors, and flow meters.
The FS-TSHART-1620m supports HART (Highway Addressable Remote Transducer) protocol, allowing for bidirectional digital communication on top / the traditional 4–20 mA analog signal. This capability enhances diagnostics and device configuration directly through the control system or asset management platform.
Its modular and robust design is suitable for industrial environments requiring high system availability, minimal downtime, and reliable analog signal processing. The assembly is mounted in the control panel and includes built-in circuitry for signal conditioning, surge protection, and wiring terminations.
製品仕様
| Parameter | 説明 |
|---|---|
| モデル Number | FS-TSHART-1620m |
| メーカー | Honeywell |
| Module Type | Analog Input Field Termination Assembly (FTA) |
| Channels サポートed | 16 Analog Inputs |
| Protocol サポート | 4–20 mA with HART |
| Compatibility | Compatible with Safety Manager / FSC AI HART input modules |
| Signal Type | Analog (Current loop 4–20 mA), HART overlaid |
| Wiring Connection | Screw terminal, labeled and field-device friendly |
| Built-in Protection | Surge protection and reverse polarity protection |
| Field Power Isolation | Yes, with individual channel isolation |
| System Communication | Through backplane or system I/O cable assembly |
| Operating Voltage | 24V DC |
| Operating Temperature Range | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5%–95% non-condensing |
| Mounting Type | DIN rail mount |
| Material | Industrial-grade thermoplastic housing |
| Ingress Protection | IP20 (panel installation recommended) |
| Dimensions (W x H x D) | 250 × 70 × 60 mm |
| 重量 | 0.9 kg |
Product Applications
-
Safety Instrumented Systems (SIS): Ideal for gathering analog input data in safety-critical processes.
-
Process Monitoring: Acquires pressure, temperature, level, and flow data from field instruments.
-
Asset Management: HART communication enables remote device diagnostics and calibration.
-
Chemical and Petrochemical Plants: Facilitates reliable and safe analog data collection.
-
Power Generation Facilities: Interfaces with turbine and boiler instrumentation.
-
Oil & Gas Industry: サポートs upstream and downstream analog sensing with HART-enabled transmitters.
Product Advantages
-
HART-Enabled: Allows simultaneous analog signal transmission and digital device communication, increasing visibility into field devices.
-
Compact Design: Accommodates 16 channels in a slim form factor, saving valuable panel space.
-
Simplified Wiring: Clearly labeled terminals improve installation efficiency and reduce wiring errors.
-
Field Isolation: Reduces the risk / signal disruption or system damage due to field-side faults.
-
Surge Protection: Protects critical analog inputs from electrical surges and transients.
-
Integrated with Honeywell SIS: Designed to work seamlessly with Safety Manager and FSC systems for high-integrity performance.
-
Robust Build Quality: Built for long-term industrial use under harsh conditions.
-
Maintenance-Friendly: Easy access to terminal points and standardized layout reduces downtime during servicing.
よくある質問 (FAQ)
-
What is the function / the FS-TSHART-1620m module?
It serves as the interface between field analog devices and the safety controller’s analog input cards, providing signal termination, conditioning, and HART communication. -
How many channels does this termination assembly support?
It supports up to 16 analog input channels. -
Does it support HART communication?
Yes, it fully supports HART protocol for field device diagnostics and configuration. -
Can this assembly be used with non-HART analog devices?
Yes, it supports standard 4–20 mA devices with or without HART overlay. -
Is this module hot-swappable?
The FTA itself is not hot-swappable. System power should be managed during installation or replacement. -
How is the FTA mounted?
It is designed for DIN rail mounting inside a control cabinet. -
Is it compatible with Safety Manager systems?
Yes, it is fully compatible with Honeywell Safety Manager and FSC analog input modules. -
Does the FS-TSHART-1620m include built-in surge protection?
Yes, each channel includes protection circuitry to guard against electrical surges. -
What are the module dimensions?
The 台 measures 250 × 70 × 60 mm. -
What is the operating temperature range for this assembly?
The assembly operates within -20°C to +60°C and can be stored from -40°C to +85°C.
Related モデルs (Same Series or Functionality)
| モデル Number | 説明 |
|---|---|
| FS-TSHART-1620 | Analog Input FTA, standard variant without enhanced features |
| FS-AI-1101 | Analog Input Module for use with FSC systems |
| FS-TSI-1616m | Digital Input FTA with 16 channels |
| FS-AO-1120 | Analog Output Module for FSC systems |
| FS-TSDO-1620m | Digital Output FTA with 16 channels |
| FS-PSU-0110 | Power Supply ユニット for Honeywell FSC system |
Popular Honeywell Modules (Same ブランド)
| モデル Number | 説明 |
|---|---|
| CC-PDIL01 | Digital Input Module for C300 Process Controllers |
| CC-PDOB01 | Digital Output Module for C300 Controllers |
| MC-PAIH03 | HART Analog Input Module for Experion PKS systems |
| MC-TAMR03 | Temperature Multiplexer Module |
| TC-PRR021 | Redundant Processor Module for TDC 3000 |
| 51403425-100 | Universal Analog Input Module |
