Product Overview
The Honeywell CC-PAOH51 51410070-276 is a high-performance HART Analog Output Module designed for seamless integration into industrial control systems. It facilitates precise conversion / digital signals to analog outputs, enabling accurate control / various field devices such as actuators, valves, and other instrumentation.
This module is an integral component / Honeywell’s Experion® Process Knowledge System (PKS) and the C300 controller family, ensuring reliable and efficient process automation across diverse industrial applications.
製品仕様
| Parameter | Details |
|---|---|
| メーカー | Honeywell |
| 型番 | CC-PAOH51 |
| Catalog Number | 51410070-276 |
| Module Type | HART Analog Output Module |
| Output Channels | 16 |
| Output Signal Range | 4-20 mA, 0-20 mA, 0-10 V (user configurable) |
| HART Protocol サポート | Yes |
| Accuracy | ±0.1% / full scale |
| Resolution | 16-bit |
| Isolation | Channel-to-channel: 500V; Channel-to-system: 1500V |
| Response Time | <20 ms |
| Output Ripple | <100 mV peak-to-peak at power line frequency, across 250 Ω load |
| Output Temperature Drift | 0.005% / Full Scale/°C |
| Output Readback Accuracy | ±4% / Full Scale |
| Output Current Linearity | ±0.05% / Full Scale nominal |
| Calibrated Accuracy | ±0.35% / Full Scale (25°C) including linearity |
| Directly Settable Output Current Range | 0 mA, 2.9 mA to 21.1 mA |
| Maximum Resistive Load | 800 ohms (with 24 V supply) |
| Power Supply | 24 VDC (18-30 VDC) |
| Power Consumption | 4W max |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Dimensions (H × W × D) | 63.5 x 124.46 x 307.34 mm |
| 重量 | 0.299 kg |
| Mounting | DIN rail or Honeywell Series C rack mounting |
| Certifications | CE, TUV, UL508, CSA |
Applications
The Honeywell CC-PAOH51 Analog Output Module is designed for a wide range / industrial applications requiring precise analog signal output and HART communication capabilities. Common applications include:
-
Process Control Systems: Regulating actuators, valves, and other control elements in industries such as oil and gas, chemical processing, and power generation.
-
Manufacturing Automation: Providing accurate control signals to machinery and production equipment.
-
Environmental Monitoring: Controlling devices in systems that monitor environmental parameters.
-
Utilities and Energy Management: Managing equipment in water treatment plants, electrical grids, and renewable energy installations.
-
Pharmaceutical Production: Ensuring precise control in sensitive manufacturing processes.
-
Food and Beverage Industry: Maintaining consistent quality through accurate process control.
Product Advantages
-
High Precision and Accuracy: Offers ±0.1% full-scale accuracy and 16-bit resolution for precise control.
-
HART Protocol サポート: Enables enhanced communication with field devices, allowing for diagnostics and configuration over the same wiring.
-
Multiple Output Ranges: Configurable for 4-20 mA, 0-20 mA, and 0-10 V signals to accommodate various devices.
-
Robust Isolation: Provides 500V channel-to-channel and 1500V channel-to-system isolation, ensuring signal integrity and safety.
-
Fast Response Time: Less than 20 ms response time for timely control actions.
-
Wide Operating Temperature Range: Suitable for extreme environments, operating reliably from -40°C to +70°C.
-
Compact and Modular Design: Facilitates easy integration into existing systems with minimal space requirements.
-
Low Power Consumption: Efficient operation with a maximum power consumption / 4W, reducing overall energy costs.
-
Reliable Performance: Designed for high availability and durability in industrial settings.
-
Seamless Integration: Fully compatible with Honeywell’s Experion® PKS and C300 controller systems, ensuring smooth system integration.
Recent News Headlines Featuring CC-PAOH51 or Related Honeywell Automation 製品
-
Honeywell Enhances Process Control with Advanced HART Analog Output Modules – Automation Today, March 2025
-
Case Study: Optimizing Chemical Plant Operations Using Honeywell CC-PAOH51 Modules – Industrial Automation News, February 2025
-
Honeywell’s Commitment to Precision: The Role / CC-PAOH51 in Modern Manufacturing – Control Engineering Review, January 2025
-
Integrating HART Protocol in Process Automation: Insights from Honeywell’s CC-PAOH51 Module – Process Control Weekly, December 2024
-
Energy Sector Adopts Honeywell’s CC-PAOH51 for Enhanced Control Capabilities – Energy Automation Journal, November 2024
-
Honeywell Introduces New Features in Series C Analog Output Modules – Industrial Tech Update, October 2024
-
Automation Evolution: Leveraging HART Communication with Honeywell’s CC-PAOH51 – Automation World, September 2024
-
Ensuring Signal Integrity in Harsh Environments: The Honeywell CC-PAOH51 Advantage – Control Systems Magazine, August 2024
-
Pharmaceutical Industry Benefits from High-Precision Analog Outputs with Honeywell Modules – PharmaTech News, July 2024
-
Honeywell’s CC-PAOH51: A Game-Changer in Process Automation – Manufacturing Insights, June 2024
FAQ
-
Q1: What is the main application / the CC-PAOH51 Analog Output Module?
A: This module is primarily used to generate analog control signals—typically 4-20 mA or 0-10 V—for actuating final control elements such as valves and variable speed drives in industrial automation systems. -
Q2: How many analog output channels does this module /fer?
A: The CC-PAOH51 provides 16 individually configurable analog output channels, each isolated for robust operation in demanding environments. -
Q3: Does the CC-PAOH51 support HART communication?
A: Yes, it supports the HART protocol, enabling digital communication with field devices over existing analog signal lines, useful for diagnostics and remote configuration. -
Q4: What type / signal accuracy can I expect?
A: It /fers high accuracy with typical deviation within ±0.35% / full scale, along with 16-bit resolution to support precise output control. -
Q5: Is this module compatible with the Honeywell C300 controller platform?
A: Absolutely. It is fully compatible with Honeywell’s Experion PKS architecture and designed for seamless integration into the C300 controller family. -
Q6: Can I use this module in high-temperature or harsh industrial environments?
A: Yes, the CC-PAOH51 is built for industrial environments, with an operating temperature range / -40°C to +70°C and humidity tolerance up to 95% non-condensing. -
Q7: What is the maximum load resistance supported on each output channel?
A: Each output channel can handle up to 800 ohms resistive load at 24 VDC power supply, which is suitable for most standard industrial analog field devices. -
Q8: Can the module be replaced while the system is running?
A: Yes, it supports hot-swapping, allowing for maintenance or replacement without interrupting system operations—a key feature for continuous process industries. -
Q9: How is the module mounted?
A: The module can be installed via standard DIN rail or mounted directly into Honeywell’s Series C racks, /fering flexibility depending on the system layout. -
Q10: What safety and compliance certifications does this module carry?
A: It complies with CE, TUV, UL508, and CSA certifications, ensuring safe use in international industrial settings.
