製品紹介
The Honeywell 8C-TDIL11 (型番: 51306858-175) is a rugged and high-density digital input module used within Honeywell’s Experion PKS control systems, particularly the C300 controller platform. It is designed to monitor and collect 32 discrete field input signals from on-site devices such as contact switches, safety interlocks, proximity sensors, and other binary output equipment.
Tailored for critical industrial applications, the module operates using a 24V DC nominal signal and /fers channel-level isolation to ensure protection and signal integrity across harsh environments. Each input point is clearly monitored through diagnostic features and LED indicators for easy identification / real-time signal states. The 8C-TDIL11 is widely implemented in continuous process industries where operational reliability and signal accuracy are essential.
製品仕様
| Parameter | 説明 |
|---|---|
| モデル Number | 8C-TDIL11 |
| 型番 | 51306858-175 |
| Input Channels | 32 Digital Inputs |
| Input Signal Type | 24V DC (Sourcing) |
| Input Current | ~5 mA typical @ 24V DC |
| Input Impedance | Approx. 4.7 kΩ |
| Debounce Time | Configurable (default 4 ms) |
| Channel Status LEDs | Yes, per channel |
| Internal Diagnostics | Yes (short/open detection, module health) |
| Power Supply Voltage | Supplied via I/O chassis |
| Power Consumption | Approx. 4.8 W |
| Isolation Voltage | 1500 V RMS (Channel to Backplane) |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature | -40°C to +85°C (-40°F to 185°F) |
| Humidity Range | 5% to 95% RH, non-condensing |
| Mounting Type | DIN Rail (Modular Chassis Mount) |
| Redundancy サポート | Yes (in redundant system configurations) |
| System Compatibility | C300 Controller, Experion PKS |
| Dimensions (H × W × D) | 51 x 267 x 178 mm |
| 重量 | 0.5 kg |
| Certifications | CE, UL, CSA, ATEX-compliant (system dependent) |
Applications
The Honeywell 8C-TDIL11 module is a versatile solution used across multiple industrial sectors:
-
Oil & Gas Refineries – Interfaces with limit switches and valve feedback devices in hazardous zones.
-
Chemical Processing Plants – Tracks binary sensor signals in reaction and batch 台s.
-
Metals & Mining – Captures operational status / heavy equipment, conveyors, and safety systems.
-
Food & Beverage Industry – Monitors machine door sensors, emergency buttons, and bin full indicators.
-
Power Plants – Used for turbine control, relay status inputs, and protection system interfacing.
-
Pharmaceutical Manufacturing – Ensures precision in automated batch controls and cleanroom applications.
Product Advantages
-
High Channel Density: サポートs up to 32 inputs, helping reduce rack space and simplify installation.
-
Robust Signal Integrity: Built-in isolation and diagnostics protect against electrical noise and signal failures.
-
System-Wide Integration: Seamlessly connects with Honeywell’s Experion PKS architecture, minimizing engineering efforts.
-
Fault Detection: Features diagnostics for channel health, allowing proactive maintenance.
-
Redundant Compatibility: Works in redundant setups to support uninterrupted operation.
-
Compact Design: Space-saving format suitable for large-scale I/O deployments.
-
Field Troubleshooting サポート: LED status indicators for each channel enable quick issue identification without special tools.
よくある質問 (FAQ)
-
Q: What is the maximum number / inputs supported by the 8C-TDIL11?
A: The module supports 32 discrete digital inputs. -
Q: What type / signal is required for input?
A: It requires a nominal 24V DC signal for operation. -
Q: Can this module detect wiring faults like shorts or opens?
A: Yes, it has internal diagnostic capabilities for fault detection. -
Q: Is the module hot-swappable?
A: Yes, in systems designed with redundancy and appropriate safety configurations. -
Q: Are channel status indicators available?
A: Yes, each channel has an associated LED for signal status display. -
Q: Can this module be used in a hazardous environment?
A: Yes, provided the entire system meets the necessary ATEX or safety standards. -
Q: How is the module mounted in a system?
A: It is installed on a DIN rail within a compatible I/O chassis. -
Q: What is the minimum operating temperature / the module?
A: The minimum operating temperature is 0°C. -
Q: Is it compatible with older Honeywell controllers?
A: It is designed for use with the C300 controller and newer Experion PKS environments. -
Q: How much does the module weigh?
A: 0.5 kg.
Related モデルs (Same Series or Functionality)
| モデル Number | 説明 | Channels | Signal Type | System Compatibility |
|---|---|---|---|---|
| 8C-TDIL01 | Digital Input Module (Standard) | 32 | 24V DC | C300 / Experion PKS |
| 8C-TDOD51 | Digital Output Module | 32 | 24V DC | C300 / Experion PKS |
| 8C-PAIH51 | Analog Input Module | 16 | 4–20 mA | C300 / Experion PKS |
| 8C-PAONA1 | Analog Output Module | 8 | 4–20 mA | C300 / Experion PKS |
| 8U-TDILA1 | Fail-Safe Digital Input Module | 16 | 24V DC (Fail-safe) | Safety Manager Systems |
| 8C-TAIX61 | Thermocouple Input Module | 16 | TC Inputs | C300 / Experion PKS |
