The HIMA Z7138/3330/C10/P2 Cable Plug represents a high-quality, precision-engineered connector designed for demanding safety and automation systems. Manufactured by HIMA, a global pioneer in functional safety technology, this cable plug ensures a reliable and secure connection in critical control environments. Its design combines ruggedness with precision to deliver consistent performance even in the most challenging industrial settings.
This particular model, Z7138/3330/C10/P2, is tailored for applications that require stable and fail-safe connectivity. It is widely used in safety instrumented systems (SIS), emergency shutdown systems (ESD), and process control operations where cable integrity and signal accuracy are paramount. Built to withstand harsh environmental conditions, it protects against mechanical stress, moisture ingress, and electrical interference.
製品仕様
| Parameter | Specification |
|---|---|
| モデル Number | HIMA Z7138/3330/C10/P2 |
| Connector Type | Circular multi-pin cable plug |
| Number / Pins | 10 |
| Housing Material | High-strength plastic with metal reinforcement |
| お問い合わせ Material | Gold-plated copper |
| Operating Temperature | -40°C to +85°C |
| Ingress Protection | IP67 (dustpro/ and water-resistant) |
| Cable Length | 10 meters |
| 重量 | 0.15 kg |
| Cable Diameter Range | 7 mm to 13 mm |
| Electrical Rating | 250 V, 5 A nominal |
| Mounting Style | Panel mount and cable mount options |
| Standards Compliance | IEC 61508, IEC 61511, SIL certified |
| Additional Features | Vibration resistant, locking mechanism for secure connection |
Product Applications
-
Safety Instrumented Systems (SIS): Essential in connecting safety sensors, actuators, and controllers with uncompromising reliability.
-
Emergency Shutdown Systems (ESD): Facilitates secure cabling in emergency control panels ensuring fast and dependable system responses.
-
Process Automation: Connects instrumentation in automated manufacturing or processing lines where safety and accuracy are critical.
-
Industrial Machinery: Used for ruggedized cable connections on heavy machinery and factory automation equipment.
-
Energy Sector: Common in power plants, oil and gas platforms, and renewable energy installations where environmental conditions can be harsh.
-
Transportation Systems: Suitable for control and signaling equipment in railways, subways, and other mass transit systems.
Product Advantages
-
Robust and Durable Design: The plug withstands extreme temperatures, vibrations, dust, and water exposure, ensuring long service life.
-
Certified for Safety Use: Complies with strict safety standards including IEC 61508 and IEC 61511, certified for SIL-rated safety systems.
-
High Electrical Reliability: Gold-plated copper contacts reduce resistance and provide excellent corrosion protection.
-
Secure Locking Mechanism: Prevents accidental disconnection even under intense mechanical vibration or movement.
-
Flexible Installation: Suitable for both panel and cable mounting, simplifying integration into various system designs.
-
Wide Cable Compatibility: サポートs a broad range / cable diameters from 7 mm to 13 mm.
-
Compact Yet Powerful: Despite its compact dimensions, it supports multiple pins and high electrical loads.
-
IP67 Rating: Dust-tight and waterpro/ for outdoor and harsh industrial applications.
-
Low Maintenance: Designed for minimal wear and tear, reducing system downtime and maintenance costs.
よくある質問 (FAQ)
-
What is the maximum cable diameter supported by the Z7138/3330/C10/P2?
It supports cables with diameters ranging from 7 mm to 13 mm. -
Is this cable plug suitable for outdoor use?
Yes, its IP67 rating guarantees protection against dust and water immersion up to 1 meter. -
How many pins does this cable plug have?
This model features 10 pins, allowing multiple connections within a single plug. -
What temperature range can the Z7138/3330/C10/P2 operate in?
It operates reliably from -40°C to +85°C. -
Is the plug compatible with other HIMA system components?
Yes, it is designed for seamless integration with a broad range / HIMA safety systems. -
What kind / electrical rating does this plug have?
The plug is rated for 250 V and 5 A nominal. -
Does it feature any locking mechanism?
Yes, it has a robust locking mechanism to ensure secure connections. -
Can the plug withstand industrial vibrations?
Yes, it is vibration resistant, suitable for heavy industrial environments. -
Is it certified for safety-critical applications?
Yes, it complies with IEC 61508 and IEC 61511 standards and is SIL certified. -
What materials are used in the contacts?
The contacts are made / gold-plated copper to ensure conductivity and corrosion resistance.
Related or Same-Series モデルs (HIMA)
| モデル Number | Number / Pins | IP Rating | Dimensions (L x W x H) (mm) | 重量 (g) | Key Feature |
|---|---|---|---|---|---|
| HIMA Z7138/3320/C8 | 8 | IP67 | 78 x 42 x 42 | 135 | Compact with 8-pin configuration |
| HIMA Z7138/3340/C12 | 12 | IP67 | 90 x 48 x 48 | 165 | Higher pin count for complex systems |
| HIMA Z7138/3350/C6 | 6 | IP67 | 70 x 38 x 38 | 115 | Smaller footprint for limited space |
| HIMA Z7139/3330/C10 | 10 | IP68 | 85 x 45 x 45 | 155 | Waterpro/ rating IP68 |
| HIMA Z7140/3330/C10 | 10 | IP67 | 87 x 44 x 44 | 150 | Improved locking for secure fit |
| HIMA Z7150/3330/C10 | 10 | IP68 | 85 x 45 x 45 | 160 | Heavy duty with waterpro/ sealing |
Popular モデルs from HIMA ブランド
| モデル Number | Number / Pins | IP Rating | Dimensions (L x W x H) (mm) | 重量 (g) | Application Area |
|---|---|---|---|---|---|
| HIMA Z7200 | 16 | IP67 | 85 x 50 x 50 | 160 | Advanced SIS connectivity |
| HIMA Z7210 | 20 | IP66 | 90 x 52 x 52 | 175 | Large pin count systems |
| HIMA Z7225 | 8 | IP67 | 70 x 40 x 40 | 125 | Standard cable plug |
| HIMA Z7230 | 12 | IP67 | 75 x 45 x 45 | 140 | Control cabinet wiring |
| HIMA Z7245 | 4 | IP68 | 65 x 35 x 35 | 105 | Compact and waterpro/ |
| HIMA Z7250 | 10 | IP67 | 74 x 43 x 43 | 135 | Medium pin count control |
