Product Overview
The GE IS220PDIAH1B is a discrete input I/O pack used in the Mark VIe control system for gas and steam turbines. It is designed to interface with field contact signals, providing reliable detection / digital status across industrial applications. The I/O pack includes signal conditioning, termination, diagnostics, and communication in one compact module.
Technical Specifications
| Parameter | 説明 |
|---|---|
| Module Type | Discrete Input I/O Pack |
| Channels | 24 digital inputs |
| Input Voltage | 24 VDC (Nominal) |
| Input Type | Dry contact or wetted contact |
| Input Isolation | Optical isolation per channel |
| Status Indication | Individual channel status LEDs |
| Communication | Ethernet (Dual RJ45 or fiber) |
| Redundancy サポート | Yes |
| Operating Temperature | -30°C to +65°C |
| Storage Temperature | -40°C to +70°C |
| Protection Class | IP20 |
| Dimensions (W×H×D) | 226 × 107 × 30 mm |
| 重量 | 0.8 kg |
Applications
-
Gas turbine control systems
-
Steam turbine automation
-
Power generation plants
-
Industrial process control
-
Oil & gas monitoring systems
-
High-reliability digital signal interfacing
Advantages
-
Integrated diagnostics and status monitoring
-
Compact form factor ideal for panel installations
-
Ethernet-based communication for fast data transfer
-
Field proven in harsh environments
-
サポートs redundant configurations for high availability
-
Easy integration into Mark VIe systems
よくある質問 (FAQ)
Q1: What type / signals does the IS220PDIAH1B support?
A1: It supports 24 VDC digital input signals from dry or wetted contacts.
Q2: Can this module be used in redundant applications?
A2: Yes, it supports redundancy to ensure continuous operation.
Q3: Is it compatible with other Mark VIe I/O modules?
A3: Yes, it is fully compatible within the Mark VIe I/O framework.
Q4: How are the input channels isolated?
A4: Each input channel is optically isolated to prevent cross-talk and electrical faults.
Q5: What kind / field devices can be connected?
A5: It supports limit switches, pushbuttons, relay contacts, and similar digital devices.
Q6: Does it provide diagnostic feedback?
A6: Yes, it includes built-in diagnostics and individual input status LEDs.
Q7: What is the communication method with the controller?
A7: It uses dual Ethernet ports (RJ45 or fiber) for communication.
Q8: Can it be mounted on standard DIN rails?
A8: Yes, the design allows DIN rail mounting in control panels.
Q9: What protection class does it have?
A9: The module is rated IP20 for standard control cabinet environments.
Q10: What are the power requirements?
A10: It typically operates with 28 VDC input from the system power bus.
Related モデルs (Same Series or Compatible)
| モデル | 説明 | Channels | Voltage | Dimensions (mm) | 重量 |
|---|---|---|---|---|---|
| IS220PAICH1B | Analog Input I/O Pack | 8 AI | ±5 V, ±10 V | 226 × 107 × 30 | 0.8 kg |
| IS220PDAIH1B | Discrete Output I/O Pack | 24 DO | 24 VDC | 226 × 107 × 30 | 0.8 kg |
| IS220PAOCH1B | Analog Output I/O Pack | 6 AO | 4-20 mA | 226 × 107 × 30 | 0.8 kg |
| IS220PSVOH1B | Servo Output I/O Pack | 2 SO | 28 VDC | 226 × 107 × 30 | 0.8 kg |
| IS220PDOAH1B | Discrete Output with High Capacity | 16 DO | 125 VDC | 226 × 107 × 30 | 0.8 kg |
| IS220PTCCH1B | Thermocouple Input I/O Pack | 12 TC | mV range | 226 × 107 × 30 | 0.8 kg |
Popular GE モデルs (Same ブランド)
| モデル | 説明 | Channels | Voltage | Dimensions (mm) | 重量 |
|---|---|---|---|---|---|
| IS200STAIH2AC | Analog Input Terminal Board | 20 AI | ±5 V | 234 × 100 × 35 | 0.75 kg |
| IS200TREGH1B | Trip Emergency I/O Pack | 3 channels | 125 VDC | 210 × 100 × 30 | 0.7 kg |
| IS200VAICH1C | Vibration/Position Input Pack | 8 channels | ±10 V | 226 × 107 × 30 | 0.8 kg |
| IS200BPPBH2BR1 | Backplane Power Supply Board | — | — | 250 × 100 × 35 | 0.85 kg |
| IS200TBTCH1CBB | Thermocouple Terminal Board | 24 TC | mV range | 226 × 107 × 30 | 0.8 kg |
| IS200DRLYH1A | Relay Output Module | 6 relays | 125 VDC | 226 × 107 × 30 | 0.8 kg |
