The GE IS200ICIAH1ABB Innovation I/O Board is a high-performance input/output interface module engineered for GE Mark VI and Mark VIe control platforms.
It acts as a critical communication bridge between field devices and the main control processor, managing high-speed digital and analog signals with superior accuracy.
Built with a multilayer FR-4 PCB and industrial-grade components, the IS200ICIAH1ABB ensures precise signal conditioning, noise suppression, and galvanic isolation, all essential for stable turbine, generator, and large-scale industrial automation systems.
Its modular design supports rapid installation and replacement, making it a reliable choice for continuous operation in mission-critical environments such as power generation, petrochemical plants, and marine propulsion systems.
製品仕様
| Parameter | Value |
|---|---|
| モデル Number | IS200ICIAH1ABB |
| Product Type | Innovation I/O Board |
| Function | High-speed analog & digital input/output processing |
| Compatible System | GE Mark VI / Mark VIe Control Systems |
| Power Supply | 24 V DC nominal (18–30 V DC tolerance) |
| Analog Input Range | 0–10 V or 4–20 mA (s/tware configurable) |
| Analog Output Range | 0–10 V, ±10 V, or 4–20 mA |
| Digital I/O Channels | 16 optically isolated inputs / 16 relay outputs |
| Signal Isolation | 1500 V RMS between field and logic circuits |
| Conversion Resolution | 16-bit A/D and D/A |
| Update Rate | 1 kHz per channel (typical) |
| Communication Interface | Redundant proprietary backplane bus |
| Operating Temperature | –20 °C to +65 °C |
| Storage Temperature | –40 °C to +85 °C |
| Humidity | 5 %–95 % non-condensing |
| PCB Material | High-temperature FR-4, multilayer |
| Diagnostic Indicators | Dual LED (Power / Channel Status) |
| Mounting Method | Rack-mounted, four-point stand/f |
| Dimensions (L × W × H) | 270 × 190 × 30 mm |
| 重量 | 0.454 kg |
| Compliance | CE, UL recognized, RoHS compliant |
Applications
The IS200ICIAH1ABB is designed for diverse high-reliability control and monitoring tasks, including:
-
Steam and Gas Turbine Control – high-speed feedback and command signal handling for Mark VI/VIe controllers.
-
Power Generation Plants – interfaces analog sensors and digital actuators for generator protection and regulation.
-
Industrial Automation – integrates with process instrumentation in chemical, pharmaceutical, and steel industries.
-
Marine Propulsion Systems – provides robust I/O for engine and generator monitoring in marine environments.
-
Renewable Energy Facilities – coordinates sensor networks and actuator control in wind or hydro installations.
-
Grid Stabilization Equipment – enables precise I/O management for frequency and voltage regulation systems.
Advantages
-
High-Speed Processing – 1 kHz per-channel update rate for real-time control loops.
-
Accurate Signal Conversion – 16-bit resolution ensures precise analog measurement and output.
-
Robust Isolation – 1500 V RMS galvanic isolation safeguards sensitive logic circuits.
-
Flexible I/O Configuration – s/tware-selectable analog ranges and mixed digital/analog channels.
-
Industrial Durability – wide operating temperature and vibration-resistant design.
-
Easy Maintenance – modular rack mounting and diagnostic LEDs simplify installation and troubleshooting.
-
Low Noise Design – multilayer PCB with integrated filtering provides superior EMI imm台y.
-
System Compatibility – seamless integration with GE Mark VI/VIe redundant control networks.
FAQ
-
What control systems support the IS200ICIAH1ABB?
It is fully compatible with GE Mark VI and Mark VIe control platforms. -
What is the analog input range?
0–10 V or 4–20 mA, selectable through s/tware configuration. -
How many digital input channels are available?
Sixteen optically isolated digital inputs. -
Does the board provide analog output capability?
Yes, it /fers 0–10 V, ±10 V, or 4–20 mA outputs. -
What is the resolution / the A/D and D/A converters?
16-bit resolution for both analog-to-digital and digital-to-analog conversion. -
What is the maximum per-channel update rate?
Approximately 1 kHz per channel under typical conditions. -
Is galvanic isolation provided between field and logic circuits?
Yes, with 1500 V RMS isolation. -
What diagnostic features are present?
Dual LEDs display power and per-channel status for rapid troubleshooting. -
What is the recommended power supply specification?
24 V DC nominal with an acceptable range / 18–30 V DC. -
How does the board communicate with the main controller?
Through a redundant proprietary GE backplane bus for high reliability.
Related モデルs – Same Series or Similar
| モデル | Function | I/O Type | Dimensions (mm) | 重量 |
|---|---|---|---|---|
| IS200ICIAH1A | Innovation I/O Board, base revision | Mixed analog/digital | 270×190×30 | 1.6 kg |
| IS200ICIAH1B | Enhanced isolation version | Mixed analog/digital | 270×190×30 | 1.6 kg |
| IS200ICIAH1C | High-speed analog specialization | Analog-intensive | 270×190×30 | 1.6 kg |
| IS200ICIAH1D | Digital-dominant I/O configuration | 32 digital I/O | 270×190×30 | 1.6 kg |
| IS200ICIAH1E | Redundant communication backplane variant | Mixed analog/digital | 270×190×30 | 1.6 kg |
| IS200ICIAH2A | Dual-channel high-density analog I/O | 32 analog channels | 280×195×30 | 1.7 kg |
Popular GE モデルs – Same ブランド
| モデル | Function | Key Feature | Dimensions (mm) | 重量 |
|---|---|---|---|---|
| IS200EPSMG2RED | Exciter Power Supply Module | High-efficiency DC supply | 250×125×50 | 2.1 kg |
| IS200EBKPG1A | Exciter Backplane Board | Central backplane for exciter racks | 300×200×30 | 1.8 kg |
| IS200EBKPG1C | Exciter Backplane Control Board | Advanced signal routing | 300×200×30 | 1.9 kg |
| IS200EXCSG1A | Exciter Conduction Sensor Board | Precision conduction monitoring | 260×180×25 | 1.4 kg |
| IS200AECPH1CCB | Mark VI Series Control Board | Core control processor | 280×190×35 | 1.7 kg |
| IS200EDEXG1A | Exciter Driver Board | Field voltage drive control | 270×185×28 | 1.6 kg |
