The GE IC698ETM001 is an Ethernet Interface Module specifically designed for use with the GE Fanuc PACSystems RX7i programmable automation controller. It enables high-speed communication between programmable logic controllers (PLCs) and external devices over Ethernet networks using standard industrial protocols such as SRTP (Service Request Transfer Protocol), Modbus TCP/IP, and EGD (Ethernet Global Data). With its robust design, high throughput capabilities, and easy integration features, the IC698ETM001 is ideal for real-time industrial communication in manufacturing and process automation environments.
Product Features
-
High-Speed Ethernet Connectivity: サポートs 10/100 Mbps data rates with auto-negotiation.
-
Protocol サポート: Compatible with SRTP, Modbus TCP/IP, and EGD protocols.
-
Dual RJ-45 Ports: Offers network redundancy and daisy-chaining capabilities.
-
Integrated Web Server: Enables remote diagnostics and monitoring.
-
Status LEDs: Provide visual feedback for link, activity, and module status.
-
Backplane Compatibility: Easily integrates into the RX7i backplane.
-
Security Capabilities: サポートs password-protected web access and secure configurations.
-
Hot-Swappable: Can be replaced without shutting down the system (with supported configurations).
Technical Specifications
| Parameter | Details |
|---|---|
| モデル | GE IC698ETM001 |
| Product Type | Ethernet Interface Module |
| Communication Ports | 2 x RJ-45 Ethernet (10/100 Mbps) |
| サポートed Protocols | SRTP, Modbus TCP/IP, EGD |
| Backplane Type | RX7i Series Backplane |
| Data Rate | 10/100 Mbps auto-sensing |
| Module Status Indicators | LEDs for Link, Activity, and Status |
| Configuration | Via Pr/icy Machine Edition or Web |
| Power Consumption | 6.0 Watts (typical) |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity | 5% to 95%, non-condensing |
| Dimensions | 125 x 125 x 28 mm |
| 重量 | 0.3 kg |
| Mounting | Rack-mounted in RX7i chassis |
Applications
-
Industrial Automation: Facilitates real-time data exchange between PLCs and SCADA systems.
-
Manufacturing Systems: Used in discrete and batch processing to integrate machine controllers.
-
Process Control: Allows for data sharing across distributed control systems.
-
Energy & Utilities: Used in power plants for supervisory control and monitoring.
-
Material Handling: Integrates conveyor control systems with plant-level networks.
-
OEM Solutions: Embedded in customized equipment for reliable Ethernet communication.
Product Advantages
-
Robust Network Integration: サポートs multiple protocols, enabling seamless integration across diverse systems.
-
Flexible Configuration: Web interface and Pr/icy Machine Edition provide intuitive configuration.
-
System Redundancy: Dual Ethernet ports provide high availability and fault tolerance.
-
Diagnostic Capability: Integrated web server enables quick remote diagnostics.
-
Modular Design: Easily installable into existing RX7i racks with minimal disruption.
-
Secure Communication: Access control and secure settings protect critical industrial data.
よくある質問 (FAQs)
Q1: What is the primary function / the IC698ETM001 module?
A1: It serves as an Ethernet communication interface for GE PACSystems RX7i controllers.
Q2: What communication protocols does it support?
A2: It supports SRTP, Modbus TCP/IP, and Ethernet Global Data (EGD).
Q3: Can it be configured remotely?
A3: Yes, the module includes a built-in web server for remote configuration and diagnostics.
Q4: What type / backplane is required for installation?
A4: It is designed for use with the RX7i controller backplane.
Q5: Is it hot-swappable?
A5: Yes, with the appropriate configuration, the module can be replaced without powering down the system.
Q6: How do I know if the module is functioning correctly?
A6: Status LEDs on the module indicate power, network link, and activity status.
Q7: Does it support redundant Ethernet connections?
A7: Yes, its dual RJ-45 ports can be used for redundant or daisy-chained configurations.
Q8: What s/tware is used for configuration?
A8: GE Pr/icy Machine Edition or standard web browsers via the module’s IP address.
Q9: What environments is it suitable for?
A9: It is suitable for industrial environments with temperatures from 0°C to 60°C.
Q10: Can it communicate with third-party devices?
A10: Yes, using open protocols like Modbus TCP/IP, it can interface with third-party systems.
Related モデルs (Same Series or Functionally Similar)
| モデル Number | 説明 |
|---|---|
| IC698CPE010 | RX7i CPU with Ethernet and Serial ports |
| IC698CPE020 | High-performance CPU for RX7i systems |
| IC698CRE020 | Redundant CPU with Ethernet |
| IC698ETM002 | Enhanced Ethernet Module for RX7i |
| IC698CHS009 | RX7i 9-slot rack chassis |
| IC698PSA100 | RX7i power supply module |
Popular GE Fanuc モデルs (Different Series, High Demand)
| モデル Number | 説明 | Dimensions (mm) | 重量 |
|---|---|---|---|
| IC693CPU374 | Ethernet-enabled CPU module for Series 90-30 | 130 x 100 x 50 | 0.45 kg |
| IC695CPU320 | RX3i CPU module with high-speed processing | 136 x 132 x 44 | 0.6 kg |
| IC200CHS002 | VersaMax 7-slot I/O carrier | 120 x 115 x 65 | 0.4 kg |
| IC693MDL930 | 120/240VAC discrete input module | 120 x 100 x 50 | 0.45 kg |
| IC200ALG264 | VersaMax 15-bit analog output module | 120 x 105 x 45 | 0.38 kg |
| IC695CPE330 | RX3i CPE with dual Ethernet and USB ports | 150 x 140 x 60 | 0.72 kg |
