The GE IC694ALG222-DB is a 16-channel analog voltage input module designed for the PACSystems RX3i series. It provides high-precision voltage measurements, supporting both single-ended and differential input configurations. This module is ideal for applications requiring accurate analog signal acquisition, such as process control, data acquisition, and industrial automation systems.
Technical Specifications
| Parameter | Specification |
| モデル Number | IC694ALG222-DB |
| メーカー | GE Fanuc / Emerson |
| Input Channels | 16 single-ended or 8 differential |
| Input Voltage Range | 0 to 10 V (unipolar), -10 to +10 V (bipolar) |
| Resolution | 12-bit |
| Update Rate | 6 ms (16 channels), 3 ms (8 channels) |
| Input Filter Response | 41 Hz, 82 Hz |
| Calibration | Factory calibrated |
| Power Consumption | 112 mA @ +5 VDC, 41 mA @ +24 VDC |
| Operating Temperature | 0°C to 60°C |
| Humidity Range | 5% to 95% RH (non-condensing) |
| Dimensions (W x H x D) | 132 x 118 x 70 mm |
| 重量 | 0.29 kg |
| Mounting Type | DIN Rail or Panel Mount |
| Certifications | UL, CE, ATEX, CSA |
| Country / Origin | USA |
Applications
The IC694ALG222-DB module is utilized in various industrial applications, including:
-
Process Control: Monitoring and controlling variables such as temperature, pressure, and flow in manufacturing processes.
-
Data Acquisition Systems: Collecting analog signals from sensors and transducers for analysis and monitoring.
-
Industrial Automation: Integrating with PLCs and SCADA systems for automated control / machinery and processes.
-
Energy Management: Measuring voltage levels in power distribution systems for efficient energy utilization.
-
Environmental Monitoring: Recording analog signals from environmental sensors for compliance and reporting.
Advantages
-
High Accuracy: Provides precise voltage measurements with 12-bit resolution.
-
Flexible Configuration: サポートs both single-ended and differential input modes.
-
Fast Update Rate: Ensures timely data acquisition for real-time monitoring.
-
Robust Design: Built to withstand industrial environments with wide temperature and humidity ranges.
-
Easy Integration: Seamlessly integrates with GE’s PACSystems RX3i series and other compatible systems.
-
Certified Compliance: Meets international standards for safety and performance.
