The GE IC693ADC311 Alphanumeric Display Coprocessor is a dedicated text-based operator interface module designed for the Series 90-30 PLC system. It provides a simple yet effective method for displaying process information, alarms, and operational messages directly at the control cabinet. This module is intended for users who require local, real-time feedback without the need for external HMIs or complex s/tware.
Featuring a 2-line, 16-character alphanumeric LCD display, this coprocessor allows PLC data to be read and written interactively through user-configurable menus and keystrokes. With integrated push-button keys, plant operators can navigate menus, acknowledge alarms, or trigger basic commands, making it a cost-effective alternative to traditional HMIs for basic monitoring and control.
Technical Specifications
| Parameter | Details |
|---|---|
| モデル Number | IC693ADC311 |
| メーカー | GE Automation (GE Fanuc) |
| Product Type | Alphanumeric Display Coprocessor Module |
| Display Type | Alphanumeric LCD |
| Display Size | 2 lines x 16 characters |
| Keypad | 6 s/t-touch keys (programmable for user input/navigation) |
| Functionality | Read/write PLC data, message display, user menu control |
| Compatible PLC Series | GE Fanuc Series 90-30 |
| Slot Requirement | Occupies one I/O slot |
| Communication | Interfaces directly with CPU and I/O modules via PLC backplane |
| Power Source | Supplied via baseplate backplane |
| Program Memory | Configured through programming s/tware (e.g., Pr/icy Machine Edition) |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity Range | 5% to 95% non-condensing |
| Material | Industrial ABS plastic with shock-resistant bezel |
| Dimensions (H × W × D) | 130 × 40 × 110 mm |
| 重量 | 0.308 kg |
| Mounting | Mounted directly into a GE 90-30 baseplate slot |
| Certifications | UL, CE, CSA, RoHS compliant |
Product Applications
The IC693ADC311 coprocessor is tailored for environments where real-time visibility / PLC activity is required but a full-fledged HMI is unnecessary or impractical. It is ideal for:
-
Factory Floor Monitoring – Enables operators to monitor machine status or process parameters without leaving the cabinet.
-
Alarm Notification Systems – Displays real-time alarms and allows acknowledgement via keypad interaction.
-
Simple User Input Interfaces – Accepts numeric or menu-based input from users to influence control logic.
-
Remote or Compact Installations – Suitable for small enclosures or mobile skids where full screens are impractical.
-
Maintenance Panels – Technicians can quickly inspect values or messages for troubleshooting.
-
Educational or Training ユニットs – Provides a visible interface for teaching PLC logic flow and human interaction.
Product Advantages
-
Compact and Cost-Effective: Delivers basic display and control functions at a fraction / the cost / touch HMIs.
-
Plug-and-Play Integration: Installs directly into the PLC rack, minimizing wiring and setup time.
-
Customizable Display: メッセージs and data points are fully programmable via ladder logic or function blocks.
-
Onboard Keypad: Built-in keys allow direct user input, acknowledgment, or navigation through menus.
-
No External Power Needed: Powered via the backplane, reducing wiring complexity.
-
Increased System Transparency: Provides immediate feedback from control processes, aiding operators and engineers.
-
Robust Design: Suitable for harsh industrial conditions, certified for reliability and safety.
よくある質問 (FAQ)
-
What does the IC693ADC311 display module do?
It provides a 2-line alphanumeric display for real-time messages, data monitoring, and basic operator interaction. -
Can I input values through the keypad?
Yes, the keypad allows users to input values, navigate menus, and acknowledge events. -
Is this compatible with newer GE PLCs like RX3i?
No, it is designed specifically for the Series 90-30 platform. -
How is this different from a traditional HMI?
It’s a simplified, embedded operator interface meant for basic display and input tasks, without graphics or touchscreen features. -
Do I need additional s/tware to program it?
It is configured through the same logic s/tware used for the PLC (e.g., Pr/icy Machine Edition). -
What kind / messages can it show?
You can program it to show alarms, process values, setpoints, status messages, or operator instructions. -
Does it occupy a CPU slot?
No, it uses a regular I/O slot in the Series 90-30 rack. -
Can I use this in a remote I/O rack?
It is best used in the local rack for real-time interaction and minimal latency. -
Is there backlight support on the LCD?
Yes, the screen includes a backlight for visibility in dim environments. -
How is the durability for industrial use?
It’s built with rugged industrial materials and certified for operation in harsh environments.
Recommended モデルs – Same Series or Related Modules
| モデル | 説明 |
|---|---|
| IC693PWR321 | Standard Power Supply for Series 90-30 |
| IC693CPU331 | Entry-Level CPU with basic memory and I/O capabilities |
| IC693MDL930 | 120VAC Input Module, 16 points |
| IC693ALG391 | Analog Input Module, 2-channel, 4–20 mA or voltage |
| IC693BEM331 | Genius Bus Controller for 90-30 |
| IC693CHS391 | 10-slot Baseplate for Series 90-30 |
Popular GE Automation モデルs Across Product Lines
| モデル | Function | Key Feature |
|---|---|---|
| IC695CPE330 | RX3i High-Performance CPU | サポートs PROFINET and multitasking |
| IC695ETM001 | Ethernet Interface Module | Enables Ethernet communication for RX3i |
| IC200ALG260 | VersaMax Analog Input Module | 8-channel, current/voltage input |
| IC200MDL640 | VersaMax Digital Input Module | 16-point, 24VDC |
| IC693APU300 | High-Speed Counter Module for 90-30 | 2-channel pulse counting |
| IC695PSD140 | RX3i Power Supply Module | 40W universal input with diagnostics |
