The GE IC660TBD022 Terminal Assembly is a high-performance component from the Genius I/O series manufactured by GE Intelligent Platforms (formerly GE Fanuc). This 台 is designed to function within distributed control systems and industrial automation networks, specifically to interface field devices with control processors through Genius I/O communication.
The IC660TBD022 is a 32-circuit Terminal Assembly designed for use with discrete I/O blocks. It supports either sourcing or sinking I/O and is engineered for robust operation in harsh industrial environments. The Terminal Assembly serves as the point / field wiring connection and integrates tightly with the block electronics to form a complete Genius I/O block assembly.
Its rugged design, ease / wiring, and solid compatibility with GE’s automation infrastructure make it a reliable component for complex and mission-critical industrial automation systems.
製品仕様
| Parameter | Details |
|---|---|
| モデル | IC660TBD022 |
| Series | Genius I/O |
| Type | Terminal Assembly for Discrete I/O |
| Number / Circuits | 32 |
| I/O Type | Discrete |
| Wiring Type | Sourcing or Sinking |
| Mounting | Panel or DIN Rail |
| Operating Voltage | 10–30 VDC |
| Current Rating | 2 Amps per circuit (max) |
| Ambient Operating Temp. | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5%–95% non-condensing |
| Shock Resistance | 15g peak |
| Vibration Resistance | 1.0g from 5–200 Hz |
| Ingress Protection | IP20 (when properly installed) |
| Connector Type | Removable screw-terminal blocks |
| Compatible Electronics | GE IC660 series I/O Blocks |
| Dimensions (H x W x D) | 150 x 145 x 60 mm |
| 重量 | 0.59 kg |
| Certifications | UL, CE, CSA, RoHS |
Applications
-
Factory Automation: Used in manufacturing lines for process monitoring, equipment control, and inter-device communication.
-
Material Handling Systems: Interfaces with sensors, switches, and actuators in conveyor or sorting systems.
-
Utilities and Power Plants: Ensures reliable I/O communication in demanding utility control environments.
-
Oil and Gas Facilities: Robust enough for deployment in upstream and downstream automation.
-
Automotive Assembly Lines: Coordinates I/O between robotic equipment and PLCs.
-
Food and Beverage Plants: Withstands wash-down and sanitary requirements when installed in protective enclosures.
Product Advantages
-
High Reliability: Designed to operate reliably in harsh industrial environments with wide temperature and humidity ranges.
-
Ease / Maintenance: Removable wiring terminal blocks allow easy field service and installation.
-
Modular Compatibility: Easily integrates with other GE Genius I/O components and programmable automation controllers.
-
Cost-Efficient: Lowers wiring complexity and installation time through streamlined terminal connections.
-
Versatile Mounting: Can be mounted in various configurations (panel or DIN rail) to fit control cabinet layouts.
-
Field-Proven: Time-tested component in industrial settings with a long service life.
-
Redundancy Options: サポートs fault-tolerant configurations when used with redundant I/O setups.
-
Safety Features: Overload and short-circuit protection designed into connected I/O blocks.
-
Interoperability: Compatible with a wide range / GE PLCs and automation systems.
-
Scalability: サポートs a large number / discrete input/output points, ideal for scaling complex systems.
よくある質問 (FAQ)
-
What is the function / the IC660TBD022 Terminal Assembly?
It serves as the field wiring interface for GE Genius I/O blocks, allowing 32 discrete I/O connections. -
Is the IC660TBD022 compatible with other Genius I/O blocks?
Yes, it is designed to work with GE’s IC660 series discrete I/O blocks. -
Can this terminal assembly be used in outdoor environments?
Only if it’s housed in a properly rated enclosure; the terminal itself is rated IP20. -
What type / wiring does it support—sourcing or sinking?
It supports both sourcing and sinking configurations depending on the I/O block used. -
What is the maximum current capacity per circuit?
Each circuit can handle up to 2 Amps / current. -
How is the IC660TBD022 mounted?
It can be mounted on DIN rails or panels using standard hardware. -
What are the dimensions / this terminal assembly?
150 mm (H) x 145 mm (W) x 60 mm (D). -
Does the terminal assembly include protection against electrical faults?
Protection is built into the I/O blocks, not the terminal assembly itself. -
What certifications does the IC660TBD022 have?
It is UL-listed, CE-marked, CSA-certified, and RoHS compliant. -
Is the terminal assembly hot-swappable?
No, field wiring should only be connected or disconnected when the power is /f.
