製品紹介
The Epro PR6480/391-000 Eddy Current Sensor is a high-precision, non-contact vibration and displacement probe engineered for demanding industrial environments. It belongs to the Epro PR6480 series, which is renowned for its robust construction, precise linearity, and long-term operational stability. This model is optimized for accurate measurement / shaft vibration, axial displacement, and relative motion in rotating machinery such as turbines, compressors, pumps, and generators.
The PR6480/391-000 operates based on the eddy current measurement principle, using electromagnetic induction to detect the proximity / a conductive surface. When installed near a rotating shaft or metallic target, the sensor produces a voltage signal proportional to the distance or vibration amplitude. When paired with compatible Epro converter 台s like CON011, CON021, or CON031, it provides a calibrated linear output that can be directly used for machinery protection or condition monitoring systems.
This sensor is designed to meet the stringent requirements / API 670 and ISO 10817 standards. Built with a stainless-steel body and rated IP67 for environmental protection, it is capable / withstanding exposure to oil, dust, and moisture. It is widely used in heavy industries including power generation, petrochemical processing, and mechanical manufacturing, where reliability and accuracy are essential.
Technical Specifications
| Parameter | 説明 |
|---|---|
| モデル Number | PR6480/391-000 |
| Product Type | Eddy Current Displacement and Vibration Sensor |
| Measurement Principle | Electromagnetic Inductive (Eddy Current) |
| Measurement Range | 0–2 mm typical |
| Linearity | ≤ ±1% / full-scale |
| Sensitivity | 4 mV/μm (typical, depending on converter) |
| Frequency Response | DC to 10 kHz |
| Probe Material | Stainless Steel (AISI 304/316) |
| Target Material | Conductive materials such as steel or aluminum |
| Sensor Head Diameter | Optional |
| Operating Temperature Range | -35°C to +200°C |
| Storage Temperature Range | -50°C to +220°C |
| Pressure Resistance | Up to 10 bar |
| Mounting Thread | M14 × 1.5 |
| Output Signal (via converter) | ±10 V or 4–20 mA |
| Power Supply (via converter) | ±15 VDC nominal |
| Insulation Resistance | ≥10 MΩ at 500 VDC |
| EMC Compliance | EN 61326-1 Industrial Environment |
| Vibration Resistance | 20 g (10–2000 Hz) |
| Shock Resistance | 50 g for 6 ms |
| Protection Class | IP67 |
| Housing Material | Stainless Steel |
| 配送 重量 | 3 kg |
| Connection Type | Coaxial connector or integrated cable |
| Compliance Standards | API 670, ISO 10817, CE, RoHS |
Product Applications
The Epro PR6480/391-000 is designed for precision vibration and displacement measurement in industrial machinery. Its non-contact operation and high-frequency response make it ideal for real-time monitoring / critical components in rotating equipment.
Typical applications include:
-
Turbomachinery monitoring: Shaft vibration and displacement detection in steam and gas turbines.
-
Compressor condition monitoring: Continuous tracking / bearing and shaft movement to prevent mechanical failure.
-
Pump systems: Measurement / rotor position and early detection / imbalance or misalignment.
-
Electric motors and generators: Monitoring axial and radial shaft displacement during startup, operation, and shutdown.
-
Petrochemical equipment: Integration into API 670-compliant machine protection systems for critical rotating assets.
-
Industrial test benches: Used in R&D facilities for performance analysis / rotating components.
Its rugged build and broad environmental tolerance make it suitable for continuous operation in harsh industrial environments, even in the presence / oil mist, dust, or high vibration levels.
Product Advantages
-
Non-contact operation: Ensures zero mechanical wear and long-term reliability.
-
High measurement precision: Accurate displacement detection with excellent repeatability.
-
API 670 compliant: Suitable for use in critical rotating machinery protection systems.
-
Stainless-steel construction: Provides superior resistance to corrosion and harsh environments.
-
Wide operating range: Performs reliably in temperatures from -35°C to +200°C.
-
High imm台y to electromagnetic interference: Shielded coaxial design minimizes signal distortion.
-
Fast response time: Suitable for both static displacement and dynamic vibration measurements.
-
Simple integration: Fully compatible with Epro CON-series converter modules.
-
Stable linear output: Maintains consistent sensitivity over long-term operation.
-
Proven field reliability: Extensively used in turbines, compressors, and large industrial drives worldwide.
FAQ
-
What measurement principle is used by the PR6480/391-000?
It uses the eddy current principle, generating an electromagnetic field that varies with the proximity / a conductive target surface. -
Which converter 台s are compatible with this sensor?
It is compatible with Epro CON011, CON021, and CON031 converters for calibrated voltage or current output. -
Can the PR6480/391-000 measure both vibration and displacement?
Yes, it can measure static displacement and dynamic vibration simultaneously, depending on the signal conditioning setup. -
What type / targets does the sensor require?
The sensor requires a conductive metallic target, preferably steel, for accurate operation. -
What is the maximum frequency response supported by this model?
It provides a wide frequency response from DC up to 10 kHz, ideal for high-speed machinery. -
How does the sensor maintain measurement stability under temperature variations?
The PR6480/391-000 incorporates temperature compensation and precision calibration to ensure stable output over a wide temperature range. -
Can this sensor be used in high-pressure environments?
Yes, it is pressure rated up to 10 bar, suitable for industrial applications involving sealed housings or high mechanical stress. -
Is the PR6480/391-000 resistant to electromagnetic noise?
Yes, it is designed with advanced EMI shielding and complies with EN 61326-1 for industrial electromagnetic compatibility. -
Does the sensor need regular calibration?
Calibration is only required if the sensor is installed on a new target material or when used for precision-critical measurements. -
What is the typical insulation resistance / the probe?
The insulation resistance exceeds 10 MΩ at 500 VDC, ensuring excellent electrical isolation and measurement reliability.
Related モデルs (Same Series or Family)
| モデル Number | 説明 | Measurement Range | Operating Temperature | 重量 |
|---|---|---|---|---|
| PR6480/011-000 | Eddy Current Sensor | 0–1 mm | -35°C to +180°C | 3 kg |
| PR6480/021-000 | Eddy Current Sensor | 0–2 mm | -35°C to +180°C | 3 kg |
| PR6480/051-000 | Eddy Current Sensor | 0–5 mm | -35°C to +200°C | 3 kg |
| PR6480/071-000 | Eddy Current Sensor | 0–7 mm | -35°C to +200°C | 3 kg |
| PR6480/2K1-000 | Eddy Current Sensor | 0–2 mm | -35°C to +200°C | 3 kg |
| PR6480/361-000 | Eddy Current Sensor | 0–2 mm | -35°C to +200°C | 3 kg |
Popular EPRO モデルs
| モデル Number | 説明 | Type | Application |
|---|---|---|---|
| PR6423/002-030 | Eddy Current Sensor | Displacement Probe | Shaft vibration and clearance measurement |
| PR6423/005-010+CON021 | Eddy Current Sensor System | Integrated Sensor + Converter | Machine protection and monitoring |
| PR6480/051-100 | Eddy Current Sensor | Displacement Probe | Turbine and compressor vibration measurement |
| MMS3120/022-100 | Monitoring Module | 状態 Monitoring | Vibration and rotational speed monitoring |
| MMS3125/022-020 | Monitoring Module | 状態 Monitoring | Multi-channel vibration and displacement analysis |
| CON021 | Converter Module | Signal 状態er | Interface 台 for PR6480 and PR6423 series sensors |
