製品紹介
The Epro PR6426/000-110 32mm Eddy Current Sensor is a high-precision, non-contact measurement device specifically designed for industrial machinery monitoring and condition assessment. It accurately detects shaft vibration, axial displacement, and rotational movement in critical rotating equipment, making it an essential tool for predictive maintenance and machinery protection.
Operating on the eddy current principle, this sensor generates an electromagnetic field at the probe tip. When a conductive target, such as a steel shaft, enters this field, eddy currents are induced in the target, altering the electromagnetic field. The resulting voltage is proportional to the distance between the sensor and the target. This non-contact measurement eliminates mechanical wear, ensures long-term reliability, and maintains stable performance in harsh industrial environments.
The PR6426/000-110 features a 32mm sensor head diameter, making it suitable for larger shafts or broader target surfaces. It integrates seamlessly with Epro signal conditioning converters, providing linear output for continuous monitoring systems in turbines, compressors, generators, and other rotating machinery.
Technical Specifications
| Parameter | 説明 |
|---|---|
| モデル | PR6426/000-110 |
| Sensor Type | Eddy Current Proximity Probe |
| Measuring Principle | Non-contact electromagnetic induction (eddy current) |
| Sensor Head Diameter | 32 mm |
| Measuring Range | 0.25 mm – 4.0 mm (depending on target material) |
| Linearity | ≤ ±1% / full scale |
| Frequency Response | DC to 10 kHz (-3 dB) |
| Sensitivity | 4–8 mV/µm (depending on converter) |
| Target Material | Ferromagnetic and conductive materials (e.g., steel, nickel alloys) |
| Operating Temperature | -35 °C to +180 °C |
| Storage Temperature | -40 °C to +200 °C |
| Housing Material | Stainless steel (AISI 316L) |
| Protection Class | IP67 |
| Mounting Thread | M32 × 1.5 |
| Output Signal | Compatible with Epro signal conditioning converters |
| 重量 | 0.8 kg |
| Compliance | CE, RoHS, optional ATEX Zone 2 |
Product Applications
The PR6426/000-110 is widely utilized in industrial machinery monitoring, providing real-time data for predictive maintenance and operational safety. Key applications include:
-
Steam and gas turbines – Monitoring axial displacement and shaft vibration for early fault detection.
-
Compressors and pumps – Assessing rotor alignment and bearing conditions.
-
Generators and motors – Detecting abnormal shaft movement and vibration.
-
Gearboxes and turboexpanders – Monitoring eccentric motion and mechanical stress.
-
Industrial plants – Integrating with predictive maintenance systems for continuous machinery protection.
Its rugged construction and IP67-rated housing make it suitable for operation in environments exposed to dust, oil, vibration, and high temperatures.
Product Advantages
-
Non-お問い合わせ Measurement – Eliminates mechanical wear, ensuring long-term operational reliability.
-
High Accuracy and Sensitivity – Provides precise displacement and vibration readings.
-
Wide Frequency Response – Captures both low and high-frequency vibration events effectively.
-
Industrial-Grade Housing – Stainless steel casing with IP67 protection ensures durability in harsh conditions.
-
Large Sensor Head Diameter – 32 mm head ensures consistent performance on large shafts or wide surfaces.
-
Easy Integration – Compatible with Epro signal conditioning converters for linear output.
-
Temperature Compensation – Maintains accuracy over a broad temperature range.
-
Proven Industrial Reliability – Extensively used in turbines, compressors, and generators globally.
FAQ
-
What is the operating principle / the PR6426/000-110?
It uses the eddy current principle to detect changes in an electromagnetic field caused by conductive targets. -
Which materials are suitable for measurement with this sensor?
Ferromagnetic and conductive materials, including steel and nickel alloys. -
Can the sensor detect both radial and axial displacement?
Yes, depending on installation orientation and system configuration. -
What is the frequency response range / the sensor?
DC to 10 kHz (-3 dB), allowing for detection / both low and high-frequency shaft vibrations. -
How is the sensor integrated into monitoring systems?
Via Epro signal conditioning converters, providing a linear voltage or current output to monitoring systems. -
Does temperature affect measurement accuracy?
Temperature compensation maintains stable and accurate readings across -35 °C to +180 °C. -
Is the sensor suitable for harsh industrial environments?
Yes, the IP67-rated housing ensures reliable operation in high vibration, dust, and oil exposure conditions. -
Does the sensor require field calibration?
It is factory-calibrated; however, fine-tuning can be performed with Epro configuration tools if needed. -
Can this sensor be used in dual-channel or redundant monitoring systems?
Yes, it supports integration into dual-channel and redundant monitoring architectures. -
What type / signal output does the sensor provide?
Through Epro converters, it provides a linear voltage or current signal proportional to target displacement.
Related モデルs (Same Series)
| モデル | 説明 | Sensor Head Diameter | 重量 |
|---|---|---|---|
| PR6426/000-000 | Standard eddy current probe | 32 mm | 0.8 kg |
| PR6426/000-010 | High-temperature variant | 32 mm | 0.8 kg |
| PR6426/000-030 | Converter-compatible version | 32 mm | 0.92 kg |
| PR6426/000-031 | Standard high-precision probe | 32 mm | 0.8 kg |
| PR6426/000-041 | Industrial grade sensor | 32 mm | 0.8 kg |
| PR6426/000-100 | High-performance probe | 32 mm | 0.8 kg |
Popular モデルs from the Same ブランド (Epro)
| モデル | 説明 | Measurement Type | 重量 |
|---|---|---|---|
| PR6423/002-030 | Standard eddy current sensor | Vibration/Displacement | 0.6 kg |
| PR6424/014-040 | Proximity probe | Axial displacement | 0.7 kg |
| PR6425/010-030 | Shaft vibration sensor | Vibration | 0.8 kg |
| PR6422/010-030 | Compact displacement sensor | Bearing displacement | 0.5 kg |
| MMS3120/022-100 | Vibration monitoring module | 状態 monitoring | 1.2 kg |
| MMS6822 | Dual-channel vibration monitor | Shaft and casing vibration | 1.5 kg |
