The Emerson VE4001S2T1B3 Discrete Input Card is a high-reliability digital input module designed for mission-critical process control and industrial automation. This card captures discrete (on//f) field signals from sensors, switches, and relay contacts, converting them into precise digital data for Emerson DeltaV™ and Ovation™ control systems. Engineered for continuous operation in demanding environments, it provides fast signal response, robust isolation, and hot-swappable functionality. Its rugged build and advanced diagnostics help ensure uninterrupted monitoring / equipment status in industries such as power generation, chemical processing, oil & gas, and water treatment.
Product Parameters
| Parameter | Specification |
|---|---|
| モデル Number | VE4001S2T1B3 |
| Product Type | Discrete (Digital) Input Card |
| Input Channels | 16 individually isolated channels |
| Input Voltage Range | 18–32 VDC nominal |
| Input Signal Type | Dry contact or DC voltage input |
| Channel-to-Bus Isolation | 1500 V RMS |
| Input Response Time | <5 ms typical |
| Power Consumption | 6 W maximum |
| Communication Interface | Redundant DeltaV™ I/O bus |
| Operating Temperature | –20 °C to +60 °C |
| Storage Temperature | –40 °C to +85 °C |
| Relative Humidity | 5–95% non-condensing |
| Dimensions | 107 x 41 x 105 mm |
| 重量 | 0.36 kg |
| Certifications | CE, ATEX Zone 2, UL, CSA |
Applications
-
Process Automation – Monitors on//f status / valves, pumps, and interlocks in chemical and pharmaceutical plants.
-
Power Generation – Captures turbine trip signals, boiler safeties, and auxiliary equipment status.
-
Oil & Gas – Interfaces with field switches on pipelines, drilling rigs, and /fshore platforms.
-
Water & Wastewater – Tracks pump station alarms, gate positions, and treatment plant processes.
-
Manufacturing – Detects machine states, conveyor sensors, and robotic cell triggers.
-
Building Automation – Integrates HVAC, lighting, and fire-safety signal monitoring into central control.
Advantages
-
High Channel Density – Sixteen isolated inputs reduce cabinet space requirements.
-
Fast Response – <5 ms input recognition supports real-time control and safety interlocks.
-
Robust Isolation – 1500 V RMS channel-to-bus isolation protects against electrical noise and ground loops.
-
Redundant Communication – Dual DeltaV™ I/O bus ensures continuous data flow even if one path fails.
-
Wide Environmental Range – Operates reliably from –20 °C to +60 °C for harsh industrial conditions.
-
Low Power Consumption – Requires only 6 W, minimizing heat generation and energy use.
-
Hot-Swappable Design – Allows replacement or maintenance without system shutdown, improving uptime.
FAQ
-
What signal types can each input channel accept?
Each channel supports dry contact closures or 18–32 VDC voltage inputs, /fering flexibility for various field devices. -
How many input channels are provided?
The VE4001S2T1B3 /fers 16 isolated input channels, each configurable for different discrete signal sources. -
What is the typical input response time?
Input changes are detected in less than 5 milliseconds, enabling rapid control and protective actions. -
Is redundant communication supported?
Yes, the card communicates through a redundant DeltaV™ I/O bus, ensuring data integrity even during network interruptions. -
What level / electrical isolation is available?
Each channel is isolated from the I/O bus with 1500 V RMS protection, guarding against ground loops and electrical interference. -
Can the card be hot-swapped during operation?
Yes, it can be inserted or removed without powering down the system, simplifying maintenance and reducing downtime. -
What is the maximum power requirement?
The module consumes up to 6 W under full load, optimizing energy efficiency and thermal performance. -
Is the module certified for hazardous environments?
It carries ATEX Zone 2, CE, UL, and CSA certifications, making it suitable for industrial hazardous areas. -
What environmental limits does it tolerate?
The card operates reliably from –20 °C to +60 °C and can be stored between –40 °C and +85 °C with 5–95% non-condensing humidity. -
Which control systems are compatible with this card?
It integrates seamlessly with Emerson DeltaV™ and Ovation™ distributed control systems for process automation.
