Product Overview
The Emerson KL4201X1-BA1 CHARM Baseplate is an integral component / the DeltaV™ Electronic Marshalling system, designed to streamline the integration / field devices into the DeltaV control system. This baseplate facilitates the connection / up to 12 CHARM (Characterization Module) I/O cards, enabling flexible and efficient field wiring without the need for traditional marshalling panels.
製品仕様
The following table outlines the key specifications / the KL4201X1-BA1 CHARM Baseplate:
| Specification | Details |
|---|---|
| モデル Number | KL4201X1-BA1 |
| メーカー | Emerson Process Management |
| Product Type | CHARM Baseplate |
| CHARM Bus Power Rating | +6.3 VDC at 4 A |
| Field Circuit Power | +24 VDC at 10 A |
| Input Voltage Range | 18 to 32 VDC |
| Power Consumption | 50 W |
| Isolation Voltage | 1500 V AC |
| Ambient Temperature | -40 °C to +70 °C |
| Shock | 10 g ½ Sinewave for 11 msec |
| Vibration | 1 mm Peak to Peak from 2 to 13.2 Hz; 0.7 g from 13.2 to 150 Hz |
| Airborne Contaminants | ISA-S71.04 –1985 Airborne Contaminants Class G3 |
| Relative Humidity | 5 to 95% Non-Condensing |
| Dimensions (H x W x D) | 200 x 120 x 60 mm |
| 重量 | 0.499 kg |
Product Applications
The KL4201X1-BA1 CHARM Baseplate is utilized across various industries for:
- Process Automation: Facilitating seamless integration / field instruments into the DeltaV control system, enhancing process efficiency.
- Hazardous Environments: Certified for use in Zone 2 hazardous areas, making it suitable for industries like oil and gas, chemical processing, and pharmaceuticals.
- Flexible I/O Management: Allowing for late-stage design changes and expansions without extensive re-wiring, thereby reducing project risks and costs.
Product Advantages
The KL4201X1-BA1 /fers several benefits:
- Simplified Wiring: Eliminates the need for traditional marshalling, reducing wiring complexity and potential for errors.
- Scalability: サポートs up to 12 CHARM I/O cards, providing flexibility to scale I/O as needed.
- Enhanced Safety: Designed for use in hazardous areas, ensuring reliable operation under challenging conditions.
- Cost Efficiency: Reduces installation and maintenance costs through streamlined design and easy integration.
Recent News
As / the latest available information, there are no specific news articles or reports exclusively covering the KL4201X1-BA1 CHARM Baseplate. For the most recent updates and developments, it is advisable to consult Emerson’s /ficial website or contact their authorized distributors.
よくある質問 (FAQs)
-
What is the primary function / the KL4201X1-BA1 CHARM Baseplate?
- It serves as a mounting platform for CHARM I/O cards, facilitating the integration / field devices into the DeltaV control system.
-
How many CHARM I/O cards can the baseplate accommodate?
- It can accommodate up to 12 CHARM I/O cards.
-
Is the KL4201X1-BA1 suitable for hazardous environments?
- Yes, it is certified for use in Zone 2 hazardous areas.
-
What are the power requirements for the baseplate?
- CHARM Bus Power: +6.3 VDC at 4 A; Field Circuit Power: +24 VDC at 10 A.
-
What is the operating temperature range?
- The baseplate operates within a temperature range / -40 °C to +70 °C.
-
Does it support redundant configurations?
- Yes, the DeltaV Electronic Marshalling system supports fully redundant architectures.
-
What are the dimensions and weight / the baseplate?
- Dimensions: 200 x 120 x 60 mm; 重量: 0.499 kg.
-
Can the baseplate be used in field-mounted installations?
- Yes, it is designed to be field-mounted, reducing system design and installation costs.
-
What type / field devices can be connected?
- Various field instruments, including sensors and actuators, can be connected through appropriate CHARM modules.
-
Is the KL4201X1-BA1 compatible with all CHARM I/O modules?
- Yes, it is designed to support a wide range / CHARM I/O modules, ensuring flexible configuration and seamless integration with DeltaV systems.
