製品紹介
Emerson’s KJ2231X1-EB1 Voltage Monitor is a precision monitoring module designed to measure and report voltage levels in DeltaV control systems and industrial power distribution networks. It is a critical component in process control and safety systems, ensuring voltage stability and providing diagnostic data to prevent electrical faults.
The KJ2231X1-EB1 is part / Emerson’s robust I/O and monitoring portfolio, designed for real-time measurement and fault detection. Its high accuracy combined with industrial-grade isolation makes it an ideal solution for applications requiring continuous voltage monitoring in harsh environments.
製品仕様
| scope | value |
|---|---|
| model | KJ2231X1-EB1 |
| メーカー | Emerson Electric Company |
| Product Type | Voltage monitoring module |
| System compatibility | DeltaV Control System |
| Measuring range | 0–250 VAC / 0–300 VDC |
| Measurement accuracy | ±0.1% / full scale |
| Input Channel | 2 independent voltage monitoring channels |
| Input impedance | >1 megohm |
| Sampling rate | Typical value 100 milliseconds |
| isolation | Channel-to-channel isolation and channel-to-ground isolation |
| Diagnostic features | Overvoltage detection, line fault monitoring, self-test |
| Communication interface | DeltaV I/O Bus |
| Power consumption | Typical value 2.5 watts |
| Operating temperature | -20°C to +55°C |
| Storage temperature | -40°C to +85°C |
| Humidity range | 5%–95% non-condensing |
| Protection Rating | IP20 |
| Certifications | UL, CE, ATEX, IECEx |
| Compliance Standards | IEC 61010-1, EN 61326, IEC 61131-2 |
| Mounting Type | Plug-in module for DeltaV carriers |
| Dimensions (W × H × D) | 127 × 52 × 130 mm |
| 重量 | 0.45 kg |
Product Applications
-
Power Distribution Monitoring: Ensures voltage levels in industrial power networks remain within safe limits.
-
Process Automation Systems: Monitors control voltage for critical equipment in chemical and petrochemical plants.
-
Safety Instrumented Systems: Provides voltage supervision to prevent overvoltage-related failures.
-
Energy Management: Collects real-time data for optimizing power usage and load balancing.
-
Electrical Testing: Integrates into test benches and diagnostics systems for voltage verification.
-
Remote Monitoring: サポートs supervisory control and data acquisition (SCADA) integration.
Product Advantages
-
High Measurement Accuracy: Ensures reliable voltage monitoring for sensitive control applications.
-
Dual Channel Design: Monitors two independent voltage sources simultaneously.
-
Industrial-Grade Isolation: Protects control systems from electrical noise and transients.
-
Advanced Diagnostics: Built-in fault detection helps prevent system failures.
-
DeltaV Integration: Seamless communication with Emerson’s control network.
-
Compact and Modular: Space-saving design fits standard DeltaV carriers.
-
Robust Construction: Suitable for harsh industrial environments and extended operation.
-
Real-Time Response: Fast sampling rate for critical protection applications.
FAQ
-
What voltage ranges can the KJ2231X1-EB1 monitor?
It can measure up to 250 VAC or 300 VDC on its input channels. -
How many channels does this module support?
The KJ2231X1-EB1 provides two independent voltage monitoring channels. -
What is the typical measurement accuracy?
It /fers ±0.1% full-scale accuracy for precise voltage measurement. -
Does the module provide channel isolation?
Yes, each channel is isolated from others and from ground to ensure safe operation. -
Can the module detect overvoltage conditions?
Yes, it includes built-in overvoltage detection and alarms. -
Is the KJ2231X1-EB1 compatible with all DeltaV carriers?
Yes, it is designed to plug directly into DeltaV Series 2 I/O carriers. -
What is the sampling rate / this voltage monitor?
The typical sampling rate is 100 ms for continuous monitoring. -
Does the module support DC voltage measurement?
Yes, it supports both AC and DC voltage monitoring. -
Can this module be used in hazardous locations?
Yes, it complies with ATEX and IECEx certifications when installed correctly. -
Does the module support remote diagnostics?
Yes, full diagnostics and monitoring are available via the DeltaV network.
