The Bently Nevada TK-3E 177313-01-02 Proximity System Test Kit is a specialized instrument designed for testing, verification, and calibration / proximity probe systems used in industrial machinery protection and monitoring. It enables technicians to simulate, measure, and validate the output / proximity sensors, ensuring reliable performance in turbines, compressors, pumps, and other critical rotating equipment. Engineered for both field and laboratory environments, the TK-3E 177313-01-02 /fers precise signal generation, intuitive operation, and rugged construction. By using this test kit, maintenance teams can confirm system accuracy, prevent false alarms, and enhance the safety and efficiency / industrial machinery.
Technical Specifications
| Parameter | 説明 |
|---|---|
| モデル | TK-3E 177313-01-02 |
| Type | Proximity System Test Kit |
| Input Power | 110–240 VAC, 50/60 Hz |
| Output Signal Types | AC and DC simulated proximity signals |
| Output Amplitude | 0–10 V peak-to-peak adjustable |
| Frequency Range | 0.1 Hz – 10 kHz |
| Accuracy | ±0.05 % full-scale |
| Load Capability | Minimum 600 Ω impedance |
| Control Interface | Front-panel rotary knobs and push-buttons |
| Display | Digital readout for amplitude and frequency |
| Calibration Functions | Proximity probe testing, loop verification, system simulation |
| Indicators | LEDs for power, signal output, and fault detection |
| Operating Temperature | 0 °C to +50 °C |
| Storage Temperature | –20 °C to +60 °C |
| Protection | Over-voltage, short-circuit, and thermal protection |
| Mounting | Portable bench-top 台 with handle |
| Dimensions | 195 × 299 × 248 mm |
| 重量 | 5.22 kg |
| Certifications | CE, UL, RoHS compliant |
Applications
The TK-3E 177313-01-02 is widely applied across industrial machinery maintenance and monitoring:
-
Turbomachinery Systems: Calibrates and tests proximity probes on turbines, compressors, and pumps.
-
Power Plants: Validates proximity sensor outputs for generators, motors, and auxiliary equipment.
-
Oil & Gas Facilities: Ensures accurate proximity measurements in pumps, compressors, and drilling systems.
-
Petrochemical and Chemical Plants: Confirms sensor and system performance in reactors, distillation 台s, and mixers.
-
Manufacturing Automation: サポートs predictive maintenance by verifying sensor output in automated machinery.
-
Field and Laboratory Use: Portable design allows convenient testing in both controlled and industrial environments.
Advantages
-
High Accuracy: ±0.05 % full-scale output ensures precise proximity system verification.
-
Comprehensive Signal Simulation: Provides both AC and DC signals to emulate sensor behavior.
-
Wide Frequency Range: 0.1 Hz to 10 kHz accommodates slow and fast-rotating machinery.
-
Portable and Durable: Bench-top design with handle allows field deployment with rugged construction.
-
Digital Readout: Real-time display / amplitude and frequency simplifies calibration and testing.
-
User-Friendly Controls: Front-panel knobs and push-buttons enable fast adjustments without s/tware.
-
Integrated Protection: Over-voltage, short-circuit, and thermal safeguards protect the kit and connected systems.
-
Efficient Maintenance: Facilitates fast verification, reduces false alarms, and minimizes downtime.
FAQ
-
What types / signals does the TK-3E 177313-01-02 generate?
It provides both AC and DC simulated proximity signals to accurately replicate the behavior / real sensors. -
What is the frequency range / the output signals?
The kit supports 0.1 Hz to 10 kHz, covering a wide range / low-speed and high-speed machinery. -
How accurate are the signals produced by this test kit?
Outputs have ±0.05 % full-scale accuracy, ensuring reliable sensor and system validation. -
Can the kit test multiple proximity probes at once?
Yes, it can drive sensors with a minimum load impedance / 600 Ω, allowing single or multi-channel testing. -
What input power is required to operate this kit?
The device operates on 110–240 VAC, 50/60 Hz, compatible with most industrial environments. -
Is the TK-3E 177313-01-02 suitable for field testing?
Yes, the portable bench-top design with handle and a weight / 5.3 kg makes it easy to transport and use in the field. -
Does it include protective features?
Yes, it has built-in over-voltage, short-circuit, and thermal protection to safeguard both the kit and connected sensors. -
How are output signals adjusted?
Signal amplitude and frequency are controlled via front-panel rotary knobs and push-buttons for precise tuning. -
Can it verify the integrity / a proximity sensor loop?
Yes, the kit supports loop verification to check system continuity and sensor response. -
Does it provide a display to monitor output signals?
Yes, the digital readout indicates both signal amplitude and frequency, allowing accurate calibration and verification.
Related モデルs (Same Series or Similar)
| モデル | Function | Input Power | Output Type | 重量 |
|---|---|---|---|---|
| TK-3E 177313-01-01 | Proximity System Test Kit | 110–240 VAC | AC/DC Signals | 5.2 kg |
| TK3-2E 177313-02-02 | Calibration Instrument | 110–240 VAC | Sine, Square, Pulse | 4.6 kg |
| TK3-2E 14700-01 | Calibration Instrument | 110–240 VAC | Sine, Square, Pulse | 4.5 kg |
| TK3-2D 14701-01 | Vibration Calibrator | 110–240 VAC | Sine, Square, Pulse | 4.6 kg |
| TK3-2C 14702-01 | Multi-channel Calibration | 110–240 VAC | Sine & Pulse | 4.7 kg |
| TK3-2B 14703-01 | Proximity Sensor Calibrator | 110–240 VAC | Sine & Square | 4.4 kg |
Popular Bently Nevada モデルs
| モデル | Type | Key Feature | 重量 | Typical Application |
|---|---|---|---|---|
| 3500/42M | Vibration Monitor | Multi-channel high-speed vibration detection | 0.85 kg | Turbomachinery protection |
| 3500/22M | Transient Data Interface | High-speed transient capture | 1.0 kg | Machinery diagnostics |
| 3500/32M | Relay Module | Alarm and shutdown relay control | 0.70 kg | Critical system safety |
| 330500 | Proximity Probe | High-resolution shaft vibration measurement | 0.25 kg | Turbine monitoring |
| 330400 | Proximity Probe | Wide temperature operating range | 0.28 kg | General industrial monitoring |
| 190501 | Accelerometer | Rugged design for harsh conditions | 0.15 kg | Pump and motor vibration analysis |
