The Bently Nevada 3500/42-09-00-00 176449-02 Proximitor Seismic Monitor is a high-performance vibration and position monitoring module designed for critical rotating machinery. It is part / the 3500 Series Machinery Protection System, engineered to provide continuous, online monitoring / shaft vibration, position, and seismic parameters. Using advanced proximity sensing and signal conditioning, this monitor delivers precise measurement and diagnostics, enabling operators to detect machinery faults at an early stage. Its robust design ensures reliable operation in demanding industrial environments such as power generation, petrochemical plants, and oil & gas facilities.
Product Parameters
| Parameter | Specification |
|---|---|
| Module Type | Proximitor Seismic Monitor |
| 型番 | 3500/42-09-00-00 |
| Firmware Compatibility | Compatible with 3500 Rack Configuration S/tware |
| Input Channels | 4 channels |
| Sensor Compatibility | Proximity probes, seismic transducers |
| Input Signal Range | ±200 mV to ±20 V (depending on sensor type) |
| Signal Processing | Digital signal conditioning with configurable filters |
| Measurement Modes | Radial vibration, thrust position, case vibration |
| Alarm Types | Alert and Danger setpoints per channel |
| Power Supply | Powered via 3500 rack backplane |
| Operating Temperature | -30°C to +65°C (-22°F to +149°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Humidity | 95% non-condensing |
| Shock & Vibration Resistance | Meets IEC 60068 standards |
| Dimensions | 241.3 x 24.4 x 241.8 mm |
| 重量 | 0.91 kg |
| Compliance | CE, CSA, ATEX, IECEx |
Product Applications
The 3500/42-09-00-00 Proximitor Seismic Monitor is used in industrial machinery protection systems where continuous vibration and position monitoring is essential.
Key applications include:
-
Gas and steam turbines – Monitoring shaft vibration to prevent catastrophic failures.
-
Compressors – Detecting imbalance, misalignment, and bearing wear.
-
Pumps and fans – Identifying early-stage mechanical faults.
-
Hydroelectric generators – Tracking shaft movement and casing vibration.
-
Petrochemical process equipment – Ensuring compliance with API 670 protection standards.
Product Advantages
-
High Measurement Accuracy – Advanced signal conditioning ensures precise and repeatable data.
-
Multi-Channel Monitoring – サポートs four independent channels, reducing rack space usage.
-
Configurable Parameters – Flexible setup for various machine types and sensor configurations.
-
Robust Industrial Design – Built to withstand harsh operating conditions and temperature extremes.
-
Early Fault Detection – Helps avoid unplanned shutdowns by detecting mechanical issues early.
-
Seamless System Integration – Fully compatible with other 3500 Series modules and Bently Nevada s/tware.
FAQ
-
What types / sensors can be connected to this monitor?
It supports proximity probes and seismic transducers compatible with Bently Nevada specifications. -
Can this module measure both radial vibration and thrust position?
Yes, it can measure radial vibration, thrust position, and case vibration based on configuration. -
How are alarm setpoints configured?
Alert and Danger setpoints are configured through the 3500 Rack Configuration S/tware. -
Does the monitor support redundant configurations?
Yes, it can be used in redundant monitoring systems for critical applications. -
What is the signal filtering capability / the module?
It /fers programmable bandpass filtering to isolate relevant vibration frequencies. -
Can I mix different sensor types on the same module?
Yes, but each channel must be configured according to the specific sensor type. -
Is the module hot-swappable?
Yes, it can be replaced without shutting down the entire rack, provided the system is configured accordingly. -
How is the module powered?
It is powered through the 3500 rack backplane and does not require a separate power source. -
Does it store historical vibration data?
The module provides real-time data to the system, and historical data storage is handled by connected s/tware systems. -
What standards does this product comply with?
It complies with CE, CSA, ATEX, and IECEx standards for industrial monitoring equipment.
Related モデルs from the Same Series
| モデル | 説明 |
|---|---|
| 3500/40M | Proximitor Monitor, general vibration and position monitoring |
| 3500/42M | Enhanced Proximitor/Seismic Monitor |
| 3500/45 | Position Monitor for displacement measurement |
| 3500/46M | Hydro Monitor for hydro turbine applications |
| 3500/50 | Keyphasor Module |
| 3500/60 | Temperature Monitor |
Popular モデルs from the Same ブランド
| モデル | 説明 |
|---|---|
| 3500/22M | Transient Data Interface |
| 3500/25 | Keyphasor I/O Module |
| 3500/32M | 4-Channel Relay Module |
| 3500/53 | Overspeed Detection Module |
| 3500/77M | Aeroderivative Gas Turbine Monitor |
| 3500/92 | Communication Gateway Module |
