Product Overview
The Bently Nevada 3500/05-01-01-01-00-01 system rack is an integral component / the 3500 Series machinery protection system. This model is designed to house and interconnect up to 14 modules including monitoring, relay, communication, and power supply 台s, providing a flexible and modular framework for continuous machinery monitoring in critical industrial applications.
As a 19-inch standard rack with rear I/O access, this configuration supports optimized cabling and enhanced serviceability. It features robust construction, passive cooling, and reliable electrical backplane connectivity, ensuring stable operation in demanding environments such as oil & gas production, power plants, and chemical processing facilities. The rack’s design simplifies installation, minimizes footprint, and ensures system longevity.
Technical Specifications
| Parameter | Specification |
|---|---|
| モデル | 3500/05-01-01-01-00-01 |
| ブランド | Bently Nevada |
| Product Type | 3500 Series System Rack |
| Rack Size | 19-inch (14 module slots) |
| 重量 | 4.5 kg |
| Mounting Style | 19-inch standard rack-mount |
| Module Compatibility | All 3500 Series modules |
| Backplane | Integrated signal and power backplane |
| Rear I/O Access | Yes |
| Cooling Method | Passive (fanless) |
| Construction Material | Anodized aluminum with stainless steel hardware |
| Grounding | Built-in system grounding plane |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 0% to 95% RH (non-condensing) |
| Compliance | CE, UL, CSA (as part / full system) |
Applications
The 3500/05-01-01-01-00-01 system rack is essential for advanced machine condition monitoring and is widely used in:
-
Turbomachinery Monitoring
サポートs vibration and position sensors for turbines and compressors. -
Rotating Equipment Protection
Integrates with proximity probes and temperature sensors on motors, pumps, and fans. -
Oil & Gas Facilities
Enables real-time diagnostics and protection for critical rotating assets. -
Power Generation Plants
Deployed in gas, steam, and hydroelectric plants for continuous equipment assessment. -
Petrochemical Plants
サポートs hazardous area installations for compressors, blowers, and expanders. -
Industrial Manufacturing
Applied in automated production systems to monitor and protect mechanical components.
Advantages
-
Modular and Scalable Architecture
Accommodates up to 14 monitoring and communication modules with easy expansion. -
Rear I/O Configuration
Allows cleaner cable routing and simplified system serviceability. -
Durable Industrial Design
Constructed with corrosion-resistant metals for harsh environments. -
Fanless Cooling Design
Enhances reliability by reducing moving parts that require maintenance. -
Integrated Grounding Bus
Protects against electrical interference and ensures system safety. -
Standard 19-inch Rack Compatibility
Easily mounts into common cabinet enclosures and panels. -
Low Footprint and Lightweight
Weighs only 4.5 kg, minimizing structural support requirements. -
Universal Module サポート
Fully supports all 3500 Series cards for monitoring, diagnostics, and control.
よくある質問 (FAQ)
Q1: How many slots are available in this system rack?
A1: This rack provides 14 module slots.
Q2: Does this rack support rear I/O access?
A2: Yes, it is designed with rear I/O access for improved cable organization.
Q3: What kind / modules can be installed?
A3: It supports all 3500 Series modules, including monitors, relays, TDI, and power supplies.
Q4: Is active cooling required?
A4: No, the rack uses passive cooling and does not require fans.
Q5: What is the rack’s construction material?
A5: It is built from anodized aluminum with stainless steel fasteners.
Q6: Can it be mounted in standard control cabinets?
A6: Yes, it is a 19-inch standard rack-mount design.
Q7: How much does the rack weigh?
A7: Approximately 4.5 kg.
Q8: Is grounding integrated into the rack design?
A8: Yes, it features a built-in grounding plane.
Q9: Is this model CE certified?
A9: Yes, when configured as part / a complete certified 3500 system.
Q10: Can the rack be used in high-vibration environments?
A10: Yes, when installed properly, it is suitable for high-vibration industrial settings.
Related モデルs (Same Series)
| モデル | 説明 | Function | 重量 | Rack Size |
|---|---|---|---|---|
| 3500/05-01-01-00-00 | Standard rack, front I/O only | Base model system rack | 4.5 kg | 19-inch (14 slots) |
| 3500/05-02-01-00-00 | Rack with dual TDI support | Enhanced communication redundancy | 4.8 kg | 19-inch |
| 3500/05-01-02-01-00 | Rear I/O + redundant power support | Redundancy & service access | 5.0 kg | 19-inch |
| 3500/05-03-01-00-00 | High-temp rugged rack | Harsh environment compatibility | 4.9 kg | 19-inch |
| 3500/05-04-01-00-00 | Rack with field enclosure capability | Outdoor or field-ready applications | 6.0 kg | 19-inch |
| 3500/05-01-01-01-01 | Rear access with EMI shielding | Ideal for noise-sensitive installs | 4.6 kg | 19-inch |
Popular Bently Nevada モデルs (Same ブランド)
| モデル | 説明 | Dimensions (mm) |
|---|---|---|
| 3500/05-01-02-00-00-01 | 3500 System Rack, 19″, basic model with standard backplane | 483 x 266 x 249 |
| 3500/05-01-02-01-00-00 | 3500 System Rack, standard version, full-height slots | 483 x 266 x 249 |
| 3500/05-01-02-01-00-01 | 3500 System Rack, standard version with revision ID | 483 x 266 x 249 |
| 3500/05-01-02-00-00-00 | 3500 System Rack, basic version, no revision mark | 483 x 266 x 249 |
| 3500/05-01-02-02-00-00 | 3500 System Rack, extended airflow support, standard layout | 483 x 266 x 249 |
| 3500/05-01-02-02-00-01 | 3500 System Rack, same as above with configuration ID | 483 x 266 x 249 |
