The Bently Nevada 330709-000-060-50-02-00 is a 3300 XL Series 11 mm Proximity Probe designed for high-precision rotor vibration and position measurement in critical industrial machinery. Part / the 3300 XL monitoring system, this probe delivers reliable, repeatable measurements for machinery protection and condition monitoring in industries such as power generation, oil & gas, and heavy manufacturing. Its robust construction ensures consistent performance in harsh environments while maintaining precise detection over a wide operational range.
Technical Specifications
| Parameter | Specification |
|---|---|
| Probe Type | 11 mm Diameter Proximity Probe |
| Probe Material | Stainless Steel / High-Temperature Coating |
| Tip Material | Hardened Stainless Steel |
| Measuring Range | 0 – 2.54 mm (0 – 100 mils) |
| Linearity | ±1% Full Scale |
| Operating Temperature | -40°C to 120°C (-40°F to 248°F) |
| Cable Type | Shielded Coaxial Cable |
| Total Length | 5 m |
| 重量 | 0.35 kg |
| Electrical Termination | 2-Pin Connector |
| Compatibility | Bently Nevada 3300 XL System |
| Frequency Response | DC to 10 kHz |
| Maximum Cable Capacitance | 2000 pF |
Applications
-
Rotor vibration monitoring in turbines, compressors, and generators
-
Position and displacement measurement / rotating shafts
-
Machinery protection and early warning for unbalance, misalignment, or bearing wear
-
Process monitoring in power plants, petrochemical, and heavy industrial environments
-
Integration into Bently Nevada 3300 XL monitoring systems for continuous data acquisition
Product Advantages
-
High Accuracy: Offers precise shaft vibration and position detection for critical machinery
-
Rugged Construction: Resistant to high temperatures, vibration, and harsh industrial environments
-
System Compatibility: Fully compatible with Bently Nevada 3300 XL monitoring systems
-
Repeatable Measurements: Ensures consistent performance over long-term operation
-
Flexible Installation: 5-meter cable allows versatile placement in tight or complex machinery layouts
-
Low Maintenance: Robust probe design reduces the need for frequent servicing
FAQ
Q1: What is the minimum operating gap for this probe?
A1: The probe operates reliably with gaps as small as 0.05 mm.
Q2: Can the probe handle high-speed shaft vibration?
A2: Yes, it supports vibration up to 50 g in the frequency range / 5 – 500 Hz.
Q3: What is the probe’s linearity specification?
A3: The probe maintains ±1% full-scale linearity over its measuring range.
Q4: Which cable type is used for signal transmission?
A4: It uses a shielded coaxial cable to ensure low-noise signal integrity.
Q5: Is the probe suitable for high-temperature environments?
A5: Yes, it can operate continuously from -40°C to 120°C (-40°F to 248°F).
Q6: Can this probe be used in hazardous areas?
A6: It is suitable for industrial environments, but explosion-pro/ certification must be verified for specific hazardous areas.
Q7: What type / connector does this probe use?
A7: It uses a standard 2-pin connector compatible with Bently Nevada 3300 XL modules.
Q8: How does cable capacitance affect performance?
A8: Maximum allowable cable capacitance is 2000 pF to ensure accurate signal transmission.
Q9: Is this probe compatible with other Bently Nevada systems?
A9: It is designed primarily for the 3300 XL system but may be compatible with other 3300 series modules with appropriate calibration.
Q10: What is the frequency response / the probe?
A10: The probe provides a DC to 10 kHz frequency response for accurate high-speed measurement.
Recommended Related or Same-Series モデルs
| モデル Number | 説明 |
|---|---|
| 330709-000-060-10-02-00 | 3300 XL 11 mm Proximity Probe, 2 m cable |
| 330709-000-050-50-02-00 | 3300 XL 11 mm Proximity Probe, 5 m cable |
| 330709-000-040-10-02-05 | 3300 XL 11 mm Proximity Probe, low-temperature version |
| 330709-000-050-10-11-00 | 3300 XL 11 mm Proximity Probe, high-vibration rating |
| 330709-000-050-10-02-05 | 3300 XL 11 mm Proximity Probe, shielded cable |
| 330709-000-060-10-11-00 | 3300 XL 11 mm Proximity Probe, extended range version |
Popular Bently Nevada モデルs
| モデル Number | 説明 |
|---|---|
| 3300 XL 330759-00-02-10 | 3300 XL Monitor Module |
| 3300 XL 330060-00-02-05 | 3300 XL Proximity Probe, 8 mm |
| 3300 XL 330100-00-01-05 | 3300 XL Proximity Probe, 5 mm |
| 3500/05M | Machinery Protection Monitor |
| 3300 XL 330709-000-050-50-02-05 | 3300 XL Proximity Probe, shielded 5 m cable |
| 3300 XL 330789-00-05-05 | 3300 XL Proximity Probe Extension |
| 3300 XL 330709-000-060-02-02-00 | 3300 XL 11 mm Probe, short cable |
| 3500/22M | Vibration Sensor Module |
