製品紹介
The Bently Nevada 330708-00-24-10-01-CN 3300 XL 11 mm Proximity Probe is a high-precision eddy-current sensor designed to deliver continuous, accurate vibration and shaft position measurements for critical rotating equipment. As part / the proven 3300 XL series, this probe provides exceptional stability in demanding industrial environments where heat, oil film, and electromagnetic noise can compromise measurement quality. The “CN” suffix designates a variant manufactured and certified for specific regional standards, while retaining full compatibility with the global 3300 XL platform. Its 11 mm sensing tip /fers an extended linear range, making it ideal for large-shaft applications across power generation, petrochemical, and heavy-process industries.
製品仕様
| Parameter | 説明 |
|---|---|
| モデル Number | 330708-00-24-10-01-CN |
| Probe Type | Eddy-current proximity probe |
| Tip Diameter | 11 mm |
| Total Length | 1 meter |
| 重量 | 0.17 kg |
| Sensing Range | 0.25 mm to 2.0 mm |
| Linear Range | 0.25 mm to 2.0 mm (±0.05 mm typical accuracy) |
| Frequency Response | DC to 10 kHz |
| Operating Temperature Range | –35 °C to +177 °C |
| Storage Temperature Range | –50 °C to +200 °C |
| Body Material | Stainless steel with high-temperature polymer tip |
| Mounting Thread | M10 × 1 or compatible sleeve |
| Compatible Extension Cable | 330130 or 330131 series |
| Compatible Proximitor Driver | 3300 XL series |
| Insulation Resistance | >100 MΩ at 500 V DC |
| Maximum Vibration | 100 g peak, 10–2000 Hz |
| Relative Humidity | Up to 95 % non-condensing |
Applications
The 330708-00-24-10-01-CN probe supports continuous monitoring and protection / essential rotating machinery:
-
Steam and Gas Turbines – Provides accurate shaft vibration and thrust measurements to prevent catastrophic failures.
-
Compressors and Pumps – Detects bearing wear and rotor instability for early fault detection.
-
Generators and Motors – Monitors shaft alignment and dynamic balance to improve operational reliability.
-
Industrial Fans and Gearboxes – Maintains stable performance under mechanical and thermal stress.
-
Petrochemical and Refinery Equipment – Withstands corrosive environments while maintaining measurement precision.
Advantages
-
High Measurement Accuracy
Maintains precise displacement and vibration readings over a wide linear range, ensuring dependable condition monitoring. -
Robust Environmental Resistance
Performs reliably in high temperature, high humidity, and oil-contaminated conditions typical / industrial plants. -
優良 EMI/RFI Imm台y
Built-in shielding provides stable operation even in electrically noisy environments. -
Seamless System Compatibility
Fully compatible with Bently Nevada 3300 XL Proximitor drivers and standard extension cables for simplified integration. -
Long-Term Durability
Stainless steel housing and a rugged polymer sensing tip ensure a long service life with minimal maintenance.
FAQ
-
How does the 3300 XL 11 mm Proximity Probe sense shaft movement?
It operates on the eddy-current principle, producing a magnetic field and detecting changes in impedance as the shaft moves, converting these variations into a proportional electrical signal. -
What is the recommended gap voltage for correct operation?
A typical operating gap voltage / around –8 V DC ensures linear output and accurate displacement measurement. -
Which Proximitor drivers are compatible with this probe?
It is fully compatible with Bently Nevada 3300 XL Proximitor drivers, ensuring accurate signal conditioning and calibration. -
What vibration levels can the probe withstand?
The probe endures vibration up to 100 g peak within the 10–2000 Hz range without affecting measurement accuracy. -
Is the measurement affected by an oil film on the shaft?
No, the eddy-current technology maintains accuracy even when a thin oil film is present between the probe and target surface. -
What is the frequency response / the probe-driver system?
The system provides a flat frequency response from DC to 10 kHz, suitable for monitoring high-speed rotating equipment. -
Does the probe require extra shielding for electromagnetic interference?
No additional shielding is necessary; the probe’s design includes integrated EMI/RFI protection for stable operation. -
How is calibration maintained over time?
Calibration remains stable as long as the probe, extension cable, and Proximitor driver remain a matched set and are installed per Bently Nevada guidelines. -
Can the probe measure both radial and axial displacement?
Yes, it is suitable for both radial shaft vibration monitoring and axial (thrust) position measurement when installed correctly. -
What insulation resistance is required for reliable performance?
The probe maintains insulation resistance greater than 100 MΩ at 500 V DC, ensuring dependable electrical isolation.
Related モデルs – Same Series
| モデル Number | 説明 |
|---|---|
| 330708-00-12-10-01-05 | 3300 XL 11 mm Proximity Probe, 0.5 m length |
| 330708-00-36-10-01-05 | 3300 XL 11 mm Proximity Probe, 1.5 m length |
| 330706-05-046-10-02-00 | 3300 XL 11 mm Reverse Mount Probe, 1.0 m length |
| 330706-05-080-10-02-00 | 3300 XL 11 mm Reverse Mount Probe, 0.8 m length |
| 330705-02-020-10-02-00 | 3300 XL 8 mm Reverse Mount Probe, 0.2 m length |
| 330705-02-080-10-02-00 | 3300 XL 8 mm Reverse Mount Probe, 0.8 m length |
Popular Bently Nevada モデルs
| モデル Number | 説明 |
|---|---|
| 3500/42M | Proximitor Monitor for vibration and position measurement |
| 3500/22M | Transient Data Interface Module for 3500 series racks |
| 3500/32M | 4-Channel Relay Module for system shutdown control |
| 330103-00-12-10-02-05 | 3300 XL 8 mm Proximity Probe |
| 330180-90-00 | Extension Cable for 3300 XL Proximity Probes |
| 3701/40 | Machinery Protection System with integrated diagnostics |
