The Bently Nevada 330703-000-050-10-01-CN is a high-precision 11 mm proximity probe from the 3300 XL series, designed for reliable monitoring / rotating machinery. This probe provides accurate measurements / shaft displacement and vibration, ensuring the operational safety and efficiency / critical equipment such as turbines, compressors, generators, and pumps. The 3300 XL series is renowned for its signal stability, robustness, and reliability in harsh industrial environments. The 330703-000-050-10-01-CN model features a durable stainless-steel construction and advanced signal fidelity, making it suitable for applications where precise condition monitoring is essential.
Technical Specifications
| Parameter | Specification |
|---|---|
| モデル Number | 330703-000-050-10-01-CN |
| Series | 3300 XL |
| Probe Diameter | 11 mm |
| Measurement Type | Proximity / Vibration |
| Operating Temperature | -40°C to 120°C |
| Frequency Response | DC to 10 kHz |
| Sensitivity | 50 mV/mil nominal |
| Housing Material | Stainless Steel |
| Cable Type | Shielded |
| Connector Type | 2-pin connector |
| Total Length | 1.0 meter |
| 重量 | 0.07 kg |
| Maximum Gap | 0.25 mm |
| Electrical Configuration | Differential / Single-ended |
Applications
The 330703-000-050-10-01-CN proximity probe is widely used in:
-
Monitoring turbine, generator, and compressor shafts for vibration and position
-
Detecting misalignment, imbalance, and eccentricity in rotating machinery
-
状態 monitoring / pumps, motors, and industrial drives
-
Integration with Bently Nevada 3300 XL monitoring systems for real-time diagnostics
-
サポートing predictive maintenance and early fault detection strategies in industrial plants
Advantages
The 3300 XL 11 mm proximity probe /fers several key benefits:
-
High reliability in harsh environments, resistant to temperature fluctuations and contamination
-
優良 signal stability and low noise, ensuring precise measurement / shaft movements
-
Robust stainless-steel housing provides mechanical strength and corrosion resistance
-
Compact 11 mm design allows installation in tight spaces
-
Full compatibility with 3300 XL monitoring systems enables seamless integration
-
Accurate measurement / both low-frequency shaft displacements and high-frequency vibrations
-
サポートs proactive maintenance, helping prevent unexpected machinery failures
FAQ
-
What is the maximum operating temperature / this probe?
The 330703-000-050-10-01-CN probe operates reliably between -40°C and 120°C, making it suitable for extreme industrial conditions. -
What is the maximum probe-to-shaft gap that can be measured?
The probe can accurately measure shaft displacements up to 0.25 mm. Exceeding this limit may reduce measurement accuracy. -
Is this probe compatible with all 3300 XL series monitoring modules?
Yes, it is fully compatible with standard 3300 XL monitoring modules, ensuring proper integration for vibration and displacement monitoring. -
What type / signal output does this probe provide?
It provides a differential or single-ended voltage output proportional to shaft movement, suitable for direct connection to 3300 XL systems. -
What is the frequency response / the probe?
The probe supports a frequency range from DC up to 10 kHz, allowing accurate measurement / both low- and high-frequency vibrations. -
Can this probe detect both axial and radial vibration?
Yes, when installed properly, it can measure both radial and axial shaft movements for comprehensive monitoring. -
What materials are used in the probe housing?
The housing is constructed from stainless steel, /fering high durability and resistance to corrosion and mechanical damage. -
Is the probe resistant to electrical noise?
Yes, the shielded cable minimizes the effects / electromagnetic interference, ensuring stable and accurate signal transmission. -
What is the nominal sensitivity / the probe?
The nominal sensitivity is 50 mV/mil, allowing precise detection / small displacements critical for early fault detection. -
Can this probe be used in hazardous areas?
While suitable for standard industrial environments, its use in explosive or hazardous areas should comply with applicable safety regulations.
Related モデルs (3300 XL Series or Compatible)
| モデル Number | Diameter | Frequency Response | Operating Temperature |
|---|---|---|---|
| 330703-000-040-10-02-CN | 11 mm | DC to 10 kHz | -40°C to 120°C |
| 330703-000-040-50-12-00 | 11 mm | DC to 10 kHz | -40°C to 120°C |
| 330703-000-040-05 | 11 mm | DC to 10 kHz | -40°C to 120°C |
| 330703-000-040-15 | 11 mm | DC to 10 kHz | -40°C to 120°C |
| 330703-000-050-10 | 12 mm | DC to 10 kHz | -40°C to 120°C |
| 330703-000-060-10 | 14 mm | DC to 10 kHz | -40°C to 120°C |
Popular Bently Nevada モデルs
| モデル Number | Series | Diameter | Application |
|---|---|---|---|
| 3300 XL 330703-000-010-10 | 3300 XL | 11 mm | Turbine monitoring |
| 3300 XL 330703-000-020-10 | 3300 XL | 11 mm | Generator monitoring |
| 3300 XL 330703-000-030-10 | 3300 XL | 11 mm | Compressor monitoring |
| 3300 XL 330703-000-040-10 | 3300 XL | 11 mm | Pump monitoring |
| 3300 XL 330703-000-050-10 | 3300 XL | 12 mm | High-speed shaft monitoring |
| 3300 XL 330703-000-060-10 | 3300 XL | 14 mm | Industrial machinery monitoring |
