The Bently Nevada 330193-09-20-10-00 3300 XL 8 mm Probe is a high-precision, non-contact proximity sensor designed for real-time monitoring / rotor vibration, shaft displacement, and overall machinery dynamics. Part / the 3300 XL series, this probe delivers accurate, reliable measurements in demanding industrial environments. Its robust construction, eddy-current sensing technology, and high linearity make it an essential component for predictive maintenance, machinery protection, and diagnostic systems in power generation, petrochemical, and heavy industrial applications.
Product Parameters
| Parameter | Specification |
|---|---|
| モデル | 330193-09-20-10-00 |
| Probe Type | 3300 XL 8 mm Proximity Probe |
| Measurement Range | 2 mm (80 mil) linear range |
| Sensitivity | 7.87 mV/µm (200 mV/mil) |
| Tip Diameter | 8 mm |
| Thread Type | M10 × 1 mm |
| Operating Temperature (Probe) | –35 °C to +200 °C |
| Operating Temperature (Cable/Conn.) | –51 °C to +177 °C |
| Frequency Response | 0 to 10 kHz |
| Vibration Tolerance | Up to 20 g, 10–2000 Hz |
| Shock Tolerance | Up to 200 g peak |
| Environmental Protection | IP67 |
| Total Length | 1 meter |
| 重量 | 0.323 kg |
Product Applications
-
Turbines: Provides continuous rotor vibration and displacement monitoring in gas and steam turbines.
-
Compressors & Pumps: Detects rotor imbalance, misalignment, and bearing wear for proactive maintenance.
-
Motors & Generators: Supplies accurate vibration and displacement data to support operational reliability.
-
Industrial Machinery: Applicable for petrochemical, power generation, and other heavy industrial equipment requiring precise shaft monitoring.
Product Advantages
-
High Accuracy: Ensures stable and linear output across the full measurement range.
-
Wide Operating Temperature: Functions reliably from –35 °C to +200 °C.
-
Robust and Durable: IP67-rated housing protects against dust, moisture, and harsh environments.
-
Electromagnetic Shielding: Minimizes signal interference for consistent measurements.
-
Shock & Vibration Resistant: Can withstand high mechanical shock and vibration up to 200 g peak.
-
System Compatibility: Fully compatible with Bently Nevada 3300 XL Proximitor® sensors and 3500 series monitoring modules.
FAQ
-
What is the nominal sensitivity / the 330193-09-20-10-00 probe?
The probe has a nominal sensitivity / 7.87 mV/µm (200 mV/mil), providing accurate detection / shaft vibration and displacement. -
Which monitoring systems support this probe?
It integrates with Bently Nevada 3300 XL Proximitor® sensors and 3500 series monitoring modules for full compatibility. -
What is the operating temperature range for the probe and cable assembly?
The probe operates from –35 °C to +200 °C, while the cable and connector are rated from –51 °C to +177 °C. -
How is the probe securely mounted on machinery?
It uses an M10 × 1 mm threaded body and locknut to ensure stable placement near the rotating shaft. -
What sensing principle does the probe employ?
The probe uses eddy-current technology, generating a voltage proportional to the gap between the probe tip and shaft surface. -
What level / vibration can the probe tolerate continuously?
The probe tolerates up to 20 g continuous vibration within a 10–2000 Hz frequency range. -
Is the probe protected against environmental factors?
Yes, it is IP67-rated, providing protection against dust and temporary water exposure. -
What is the mechanical shock tolerance / this probe?
The probe can withstand shocks up to 200 g peak without performance degradation. -
How is signal integrity maintained in electrically noisy environments?
The shielded design minimizes electromagnetic interference and temperature-related drift, ensuring stable signal output. -
Can this probe measure both radial and axial shaft displacement?
Yes, it measures both radial vibration and axial displacement for comprehensive machinery diagnostics.
Related モデルs (Same Series or Similar)
| モデル Number | 説明 |
|---|---|
| 330192-00-30-10-00 | 3300 XL 8 mm ETR Probe for standard vibration monitoring |
| 330192-00-70-05-CN | 3300 XL 8 mm ETR Probe with enhanced temperature tolerance |
| 330192-10-80-90-05 | 3300 XL 8 mm ETR Probe for extended industrial use |
| 330192-10-95-90-05 | 3300 XL 8 mm ETR Probe for heavy-duty equipment |
| 330193-00-02-10-00 | 3300 XL 8 mm Probe with alternate length configuration |
| 330193-09-20-05-00 | 3300 XL 8 mm Probe, 0.5 m length |
Popular Bently Nevada モデルs
| モデル Number | 説明 |
|---|---|
| 3500/22M | Transient Data Interface Module |
| 3300 XL 5 mm | Proximity Probe for compact installation |
| 3500/42M | Proximitor®/Seismic Monitor |
| 330130-040-00 | Standard Proximitor® Sensor |
| 3500/50 | Tachometer Module |
| 330180-90-05 | 3300 XL 11 mm Proximity Probe for large shaft targets |
