製品紹介
The Bently Nevada 330104-00-25-50-02-05 3300 XL 8 mm Proximity Probe is a precision eddy current sensor designed for real-time monitoring / rotating machinery. As part / the 3300 XL series, this probe provides accurate measurements / shaft displacement and vibration, enabling predictive maintenance and early fault detection in critical industrial applications.
With an 8 mm probe diameter and a total cable length / 5 meters, this probe /fers flexibility for installation in large machinery setups or complex plant layouts. The stainless steel probe and mineral-insulated cable ensure durability and reliable performance under extreme vibration, temperature, and electromagnetic interference conditions. It is compatible with Bently Nevada 3300 XL monitoring systems, providing continuous, high-fidelity signals for machine protection and condition monitoring systems.
製品仕様
| Parameter | Specification |
|---|---|
| モデル Number | 330104-00-25-50-02-05 |
| Product Type | 8 mm Eddy Current Proximity Probe |
| Series | 3300 XL |
| Probe Diameter | 8 mm |
| Total Length | 5 meters |
| Measurement Range | Up to 1.27 mm (depending on system configuration) |
| Linear Range | ±10% / calibrated gap |
| Frequency Response | DC to 10 kHz |
| Sensitivity | 20 mV/µm (typical with 3300 XL monitoring system) |
| Resolution | <0.5 µm |
| Operating Temperature | -40°C to +120°C (probe head) |
| Storage Temperature | -50°C to +150°C |
| Probe Material | Stainless steel housing with mineral-insulated cable |
| Humidity | 0–95% non-condensing |
| Certifications | CE, UL, CSA |
| 重量 | 1.615 kg |
| Mounting | Threaded sleeve or custom machinery mounting |
| Compatibility | Bently Nevada 3300 XL Series Monitoring Systems |
Applications
The 330104-00-25-50-02-05 probe is used for accurate monitoring / industrial machinery where reliable shaft position and vibration data are critical:
-
Steam and Gas Turbines – Monitors shaft displacement to detect imbalance, misalignment, and rotor instability.
-
Compressors – Tracks rotor position and vibration to ensure safe and efficient operation.
-
Pumps – Detects cavitation, bearing wear, and shaft deflection.
-
Generators and Electric Motors – サポートs smooth operation and early anomaly detection.
-
Refineries and Petrochemical Plants – Reliable in harsh, high-vibration environments.
-
Machine Protection Systems – API 670-compliant integration for condition monitoring.
Advantages
The Bently Nevada 330104-00-25-50-02-05 8 mm Probe /fers several technical benefits:
-
High Accuracy – Precise measurement / displacement and vibration with excellent linearity.
-
Rugged Construction – Stainless steel probe and mineral-insulated cable withstand harsh industrial conditions.
-
Wide Frequency Response – Detects both low-speed and high-speed shaft vibrations.
-
Seamless Integration – Works directly with Bently Nevada 3300 XL monitoring systems.
-
Maintenance-Free Operation – Non-contact design minimizes wear and reduces maintenance requirements.
-
Temperature and Vibration Resistance – Performs reliably under extreme conditions.
-
Predictive Maintenance サポート – Early detection / anomalies helps prevent unplanned downtime.
-
Flexible Installation – 5-meter cable allows installation across large machinery or complex layouts.
よくある質問 (FAQ)
-
Which monitoring systems is this probe compatible with?
The probe is fully compatible with Bently Nevada 3300 XL monitoring systems, providing linearized displacement and vibration signals. -
What is the nominal sensitivity / the probe?
Nominal sensitivity is approximately 20 mV/µm when used with a 3300 XL monitoring system. -
What frequency range does this probe support?
The probe operates from DC to 10 kHz, covering both low-speed and high-speed machinery vibration detection. -
What is the operating temperature range for the probe head?
The probe functions reliably between -40°C and +120°C while maintaining linearity and signal fidelity. -
Can this probe be used in high-humidity or industrial environments?
Yes, it is designed to operate in 0–95% non-condensing humidity and withstand harsh industrial conditions. -
What is the linear measurement range / the probe?
±10% / the calibrated gap ensures accurate and proportional output. -
Does the probe require external power?
No, it is powered and conditioned through the 3300 XL monitoring system. -
Is the probe suitable for API 670-compliant systems?
Yes, it integrates seamlessly into API 670-compliant protection and monitoring platforms. -
Does cable length affect measurement accuracy?
Yes, the probe is calibrated for a 5-meter cable. Using the recommended length ensures precise measurement and signal fidelity. -
What type / mounting is recommended?
Threaded sleeve or custom machinery mounting is recommended to maintain proper alignment and calibration.
Related モデルs (Same Series)
| モデル Number | Probe Type | 説明 |
|---|---|---|
| 330104-00-25-50-02-04 | 8 mm Proximity Probe | Standard 3300 XL probe with 3-meter cable |
| 330104-00-25-50-02-06 | 8 mm Proximity Probe | High-temperature version |
| 330104-00-25-50-02-07 | 8 mm Proximity Probe | Extra-flexible cable variant |
| 330105-00-25-50-02-05 | 8 mm Proximity Probe | High-sensitivity version |
| 330106-00-25-50-02-05 | 8 mm Proximity Probe | API 670-compliant configuration |
| 330104-00-25-50-02-08 | 8 mm Proximity Probe | Extended linear range version |
Popular モデルs from the Same ブランド (Bently Nevada)
| モデル Number | Product Type | 説明 |
|---|---|---|
| 330104-00-25-50-01 | 8 mm Proximity Probe | Standard 3300 XL probe for turbines and compressors |
| 330104-00-25-50-03 | 8 mm Proximity Probe | High-accuracy probe for critical machinery |
| 330105-00-25-50-01 | 8 mm Proximity Probe | High-sensitivity version for vibration monitoring |
| 330130-00-25 | 3300 XL Proximity Probe | Compact probe for smaller machinery |
| 330140-00-25 | 3300 XL Proximity Probe | Extended range probe for large turbines |
| 330150-00-25 | 3300 XL Proximity Probe | API 670-compliant probe for generators |
