Product 説明
The Bently Nevada 330103-00-14-10-01-00 is part / the 3300 XL 8 mm Proximity Transducer System. It delivers highly accurate static (position) and dynamic (vibration) measurements in critical rotating machinery. The probe provides a robust and reliable eddy-current-based measurement with full interchangeability and compliance with API 670 standards. Typical uses include monitoring fluid-film bearing machines, Keyphasor reference, and speed detection.
Technical Specifications
| Parameter | Value |
|---|---|
| Total Length | 1.0 meter |
| 重量 | 0.323 kg |
| Probe Tip Diameter | 8.0 mm |
| Probe Material | Stainless steel (AISI 303/304) |
| Cable Type | 75Ω triaxial, FEP insulated |
| Linear Range | 2 mm (80 mils) |
| Recommended Gap Setting | Approx. 1.27 mm (50 mils) |
| Frequency Response | 0 to 10 kHz, ±3 dB |
| Operating Temperature (Probe) | -52°C to +177°C (standard) |
| Extended Temperature Option | Up to +218°C (probe tip) |
| Humidity Tolerance | ≤3% scale factor change at 93% RH |
| Minimum Shaft Diameter | 50.8 mm (recommended 76.2 mm) |
Applications
-
Vibration monitoring / fluid-film bearing machinery
-
Shaft position measurement
-
Keyphasor signal generation
-
Overspeed and tachometer feedback in turbines and compressors
-
High-density DIN-rail or panel-mounted installations
Advantages
-
Fully interchangeable probes, cables, and Proximitor sensors
-
API 670 compliance for performance and reliability
-
Ruggedized design with improved RFI/EMI imm台y
-
Patented TipLoc and CableLoc for enhanced mechanical robustness
-
Optional extended temperature range versions
-
ClickLoc connectors for secure and tool-free installation
FAQs
Q1: What is the linear measurement range / this probe?
A1: It provides a linear range / approximately 2 mm (80 mils).
Q2: Is the probe compliant with API 670 standards?
A2: Yes, it fully meets API 670 standards.
Q3: Can I mix XL and non-XL system components?
A3: Yes, but system performance will be limited to the non-XL components’ specifications.
Q4: What is the recommended shaft diameter for accurate readings?
A4: At least 50.8 mm, with 76.2 mm recommended for optimal accuracy.
Q5: Does it support extended temperature applications?
A5: Yes, extended temperature probes can operate up to +218°C at the tip.
Q6: How is the probe connected to the system?
A6: It uses corrosion-resistant ClickLoc connectors, requiring no special tools.
Q7: Is the probe suitable for humid environments?
A7: Yes, it can withstand 93% humidity with minimal impact on accuracy.
Q8: What type / signal does the probe output?
A8: It outputs a voltage proportional to the gap between the probe tip and the target.
Q9: Can the probe be mounted in tight spaces?
A9: Yes, it is available in metric threads (M10 x 1) and compact sizes for limited space.
Q10: What materials is the probe constructed from?
A10: It features a PPS plastic tip, stainless steel housing, and gold-plated connectors.
Related モデルs in the Same Series
| モデル Number | Thread Type | Length | 重量 |
|---|---|---|---|
| 330101-00-10-10-02-00 | 3/8-24 UNF | 1.0 m | 0.323 kg |
| 330102-00-10-10-02-05 | 3/8-24 UNF, armored | 1.0 m | 0.350 kg |
| 330103-00-10-10-02-00 | M10 x 1 | 1.0 m | 0.323 kg |
| 330104-00-10-10-02-05 | M10 x 1, armored | 1.0 m | 0.350 kg |
| 330105-02-12-10-02-00 | 3/8-24 UNF, reverse mount | 1.0 m | 0.330 kg |
| 330106-05-30-10-02-00 | M10 x 1, reverse mount | 1.0 m | 0.330 kg |
Popular モデルs from Bently Nevada
| モデル Number | Product Type | Length | 重量 |
|---|---|---|---|
| 330180-50-05 | 3300 XL Proximitor Sensor | 5.0 m | 0.7 kg |
| 330130-030-00-00 | 3300 XL Extension Cable | 3.0 m | 0.034 kg |
| 3300/42M-01-00 | Proximitor Seismic Monitor | — | 1.2 kg |
| 3500/42M-01-00 | Proximitor Seismic Monitor I/O | — | 1.2 kg |
| 3500/44M-01-00 | Aeroderivitive Vibration Monitor | — | 1.3 kg |
| 3500/22M-01-01-00 | Transient Data Interface | — | 1.5 kg |
